Mr Handsfree Blue Butterfly II: TRANSFERRING / SWITCHING CALLS / PUTTING CALLS ON HOLD

4

Redial:

Press and hold the MF-button (3) for 3 seconds to redial the last number you called.

ANSWERING / ENDING CALLS

When the Blue Butterfly headset is turned on and there is an incoming call, you will hear a musical tone and the

blue indicator (4) will change to a quick-flashing mode.  Press the MF-button (3) to answer the call or press

and hold the MF-button (3) for 3 seconds to reject the call.  Adjust the headset volume by pressing the volume

button (2). The volume will increase to a maximum so that you will hear a beep. If you press this button (2) once

again, the volume will decrease until it reaches a minimum. There are 10 different volume levels.  End the

call by pressing the MF-button (3).

When the headset is turned off, press and hold the MF-button (3) for 3 seconds to turn the headset on.  The

call will automatically be transferred to the headset.

Note:

Due to the different design of some mobile phones, an auto-disconnect may happen even when the Blue

Butterfly headset is turned on. In that case, the headset won’t ring when there is an incoming call. Press the MF-

button (3) for 3 sec. to reconnect the headset with your mobile phone for an incoming call.

MUTE FUNCTION

During conversation, it is possible to mute the microphone.

Press and hold the MF-button (3) until you hear a beep to activate the Mute function.  To disable the Mute

function, press the MF-button (3) once again until you hear a beep.

TRANSFERRING / SWITCHING CALLS / PUTTING CALLS

ON HOLD

To transfer a call:

Press and hold the MF-button (3) until you hear a series of 4 tones (from high to low) to transfer the call to the

mobile phone while talking on the headset. The headset will be turned off.  If you want to transfer the call back

to the headset, press the MF-button (3) again for 3 seconds.

To switch to a second call:

Press and hold the MF-button (3) for 3 seconds to switch to a second call during a call. This function only works

when your mobile phone service provider provides this service (check with your network provider).

To put a call on hold:

Press and hold the MF-button (3) for 3 seconds to put a call on hold.  Press and hold this button (3) once

again for 3 seconds to continue the conversation.

CONNECTING WITH A PC OR PDA

You are allowed to connect the Blue Butterfly headset with a Bluetooth enabled PC or PDA that is supported

with Audio Gateway Profiles. Please refer to the user manual of your Bluetooth enabled PC or PDA for setup

information.

English
