Ardo TLN 105 LB: CONTROL PANEL

8

CONTROL PANEL

LCD DISPLAY: The ample LCD display assures a quick and intuitive use of the

washing machine. The display shows the washing options activated, possible start

delays, selected spin speed and the time remaining until the end of the cycle. The

writing end informs that the top cover has released.

DELAYED START: This function allows the start of the wash cycle to be delayed by

up to 16 hours. Press button B repeatedly until the required delay time appears on

the display. Icon h will fl ash on the display until the wash cycle starts.

SKIN CARE: Pressing the button F activates the skin care function, which carries

out an extra rinsing. The option is recommended for skins particularly sensitive to

the enzymes contained in detergents.

PRE-WASH: To carry out a prewash, press button D and add detergent to the ap-

propriate compartment I. The washing machine will carry out a prewash at 40°C max.

A Prewash is recommended for items soiled with dust, soil, sand or with particularly

resistant stains. See the Programme Table for further information.

ENERGETIC WASH: This function E increases the effi ciency of the detergent and

prolongs the wash time, leaving the set temperature unaltered.

ADJUSTABLE SPIN: Button C can be pressed to change the spin speed in line

with the wash programme selected and the type of fabrics. The selected spin speed

will appear on the LCD display. To disable the end of cycle spin, select value “00”.

N.B.: The maximum spin speed varies according to the model. The spin speed selected

by the programme is that recommended.

Load imbalance check during spinning:

This washing machine is fi tted with a special electronic load balancing control system. Before each

spin, the system makes sure that the clothes are distributed as uniformly as possible in the drum. If

the washing is not distributed uniformly, the fi nal spin speed is reduced for safety reasons, while if

the load is drastically out of balance, the spin is not effected.

GB

SM2741

CONTROL PANEL

9

EASY IRON: Press button G to select the Easy Iron option. The washing machine will

regulate the wash parameters to reduce the formation of creases and make ironing

easier. The spin speed is set automatically at 800 rpm.

START: During the phase for selecting programs and washing options, the start LED

stays off. To confi rm the selections and start the wash cycle, press “Start” button H.

The LED will light up.

EASY LOGIC: The EASY LOGIC system automatically regulates the wash time and water and power

consumption according to the actual amount of washing placed in the drum. The ½ load function

is therefore redundant in that the EASY LOGIC system automatically sets the wash parameters.

PROGRAMME TABLE

Max. spin

Maximum load

speed

depending on

(rpm)

the selected

Programmes

Type of washing

Options

program

TemperatureSymbol

Extra dirty cotton and linen fabrics, even with stains of an organic

nature.

5.0Max

90°

Bleach can be used with this program

For very dirty resistant fabrics which need

75°

an anti-bacterial action.

5.0Max

Bleach can be used with this program.

For normally dirty resistant fabrics and colours.

5.0Max

60°

Bleach can be used with this program

Reference program in compliance with Standard EN60456

For normally dirty delicate fabric and coloured shirts, tablecloths,

towels and under-garments.

40°

5.0Max

Bleach can be used with this program.

Reference program for consumer associations.

Slightly dirty fabrics with delicate colours and linen.

5.0Max

30°-

Bleach can be used with this program

60°

Very dirty synthetic fabrics with resistant colours.

2.5800

The program allows washing different types of synthetic fabrics

2.5800

40°- 30°

all together (cotton, synthetics, mixed) with a perfect result.

40°- 30°

Delicate viscose and mixed fabrics.

2.5500

Cold washing cycle suitable for all delicate fabrics.

2.5500
