Инструкция к Материнской Плате ASRock Fatal1ty Z68 Professional Gen3

Fatal1ty Z68 Professional Gen3 Series Motherboard

2.5 SLI

and Quad SLI

Operation Guide

This motherboard supports NVIDIA

SLI

and Quad SLI

(Scalable Link Interface)

technology that allows you to install up to three identical PCI Express x16 graphics

cards. Currently, NVIDIA

SLI

technology supports Windows

XP / XP 64-bit /

Vista

/ Vista

64-bit / 7 / 7 64-bit OS. NVIDIA

Quad SLI

technology support

Windows

Vista

/ Vista

64-bit / 7 / 7 64-bit OS only. Please follow the installation

procedures in this section.

Requirements

1. For SLI

technology, you should have two identical SLI

-ready graphics

cards that are NVIDIA

certi

ed. For Quad SLI

technology, you should

have two identical Quad SLI

-ready graphics cards that are NVIDIA

certi

ed.

2. Make sure that your graphics card driver supports NVIDIA

SLI

technology. Download the driver from NVIDIA

website

(www.nvidia.com).

3. Make sure that your power supply unit (PSU) can provide at least the

minimum power required by your system. It is recommended to use

NVIDIA

certi

ed PSU. Please refer to NVIDIA

website for details.

2.5.1 Graphics Card Setup

2.5.1.1 Installing Two SLI

-Ready Graphics Cards

Step 1. Install the identical SLI

-ready graphics cards that are NVIDIA

certi

because different types of graphics cards will not work together properly.

(Even the GPU chips version shall be the same.) Insert one graphics card

into PCIE2 slot and the other graphics card to PCIE4 slot. Make sure that

the cards are properly seated on the slots.

Step2. If required, connect the auxiliary power source to the PCI Express

graphics

cards.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

Step4. Connect a VGA cable or a DVI cable to the monitor connector or the DVI

connector of the graphics card that is inserted to PCIE2 slot.

Step3. Align and insert ASRock SLI_Bridge_2S Card to the gold

ngers on each

graphics card. Make sure ASRock SLI_Bridge_2S Card is

rmly in place.

ASRock SLI_Bridge_2S Card

2.5.2 Driver Installation and Setup

Install the graphics card drivers to your system. After that, you can enable the Multi-

Graphics Processing Unit (GPU) feature in the NVIDIA

nView system tray utility.

Please follow the below procedures to enable the multi-GPU feature.

For Windows

XP / XP 64-bit OS:

(For

SLI

mode only)

Double-click

NVIDIA Settings icon

on your Windows

taskbar.

B. From the pop-up menu, select

Set SLI and PhysX con

guration

. In

Set PhysX GPU acceleration

item, please select

Enabled

. In

Select

an SLI con

guration

item, please select

Enable SLI

. And click

Apply

C. Reboot your system.

D. You can freely enjoy the bene

t of SLI

feature.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

* SLI

appearing here is a registered trademark of NVIDIA

Technologies Inc., and is used

only for identi

cation or explanation and to the owners’ bene

t, without intent to infringe.

For

Windows

Vista

/ Vista

64-bit / 7 / 7 64-bit OS:

(For

SLI

and Quad SLI

mode)

A. Click the

Start

icon on your Windows taskbar.

B. From the pop-up menu, select

All Programs

, and then click

NVIDIA

Corporation

Select

NVIDIA Control Panel

tab.

Select

Control Panel

tab.

E. From the pop-up menu, select

Set SLI and PhysX con

guration

. In

Set PhysX GPU acceleration

item, please select

Enabled

. In

Select

an SLI con

guration

item, please select

Enable SLI

. And click

Apply

F. Reboot your system.

G. You can freely enjoy the bene

t of SLI

or Quad SLI

feature.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

1. If a customer incorrectly con

gures their system they will not see the

performance bene

ts of CrossFireX

. All three CrossFireX

components, a

CrossFireX

Ready graphics card, a CrossFireX

Ready motherboard and a

CrossFireX

Edition co-processor graphics card, must be installed correctly to

bene

t from the CrossFireX

multi-GPU platform.

2. If you pair a 12-pipe CrossFireX

Edition card with a 16-pipe card, both cards

will operate as 12-pipe cards while in CrossFireX

mode.

2.6 CrossFireX

, 3-Way CrossFireX

and Quad CrossFireX

Operation Guide

This motherboard supports CrossFireX

, 3-way CrossFireX

and Quad

CrossFireX

feature. CrossFireX

technology offers the most advantageous

means available of combining multiple high performance Graphics Processing

Units (GPU) in a single PC. Combining a range of different operating modes with

intelligent software design and an innovative interconnect mechanism, CrossFireX

enables the highest possible level of performance and image quality in any 3D

application. Currently CrossFireX

feature is supported with Windows

XP with

Service Pack 2 / Vista

/ 7 OS. 3-way CrossFireX

and Quad CrossFireX

feature

are supported with Windows

Vista

/ 7 OS only. Please check AMD website for

ATI

CrossFireX

driver updates.

2.6.1 Graphics Card Setup

2.6.1.1 Installing Two CrossFireX

-Ready Graphics Cards

Different CrossFireX

cards may require different methods to enable CrossFireX

feature. In below procedures, we use Radeon HD 3870 as the example graphics

card. For other CrossFireX

cards that AMD

has released or will release in the

future, please refer to AMD

graphics card manuals for detailed installation guide.

Step 1. Insert one Radeon graphics card into PCIE2 slot and the other Radeon

graphics card to PCIE4 slot. Make sure that the cards are properly seated

on the slots.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

CrossFire Bridge

Step 3. Connect the DVI monitor cable to the DVI connector on the Radeon

graphics card on PCIE2 slot. (You may use the DVI to D-Sub adapter to

convert the DVI connector to D-Sub interface, and then connect the D-Sub

monitor cable to the DVI to D-Sub adapter.)

Step 2. Connect two Radeon graphics cards by installing CrossFire Bridge on

CrossFire Bridge Interconnects on the top of Radeon graphics cards.

(CrossFire Bridge is provided with the graphics card you purchase, not

bundled with this motherboard. Please refer to your graphics card vendor

for details.)

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

2.6.1.2 Installing Three CrossFireX

-Ready Graphics Cards

Step 1. Install one Radeon graphics card to PCIE2 slot. For the proper installation

procedures, please refer to section “Expansion Slots”.

Step 2. Install one Radeon graphics card to PCIE4 slot. For the proper installation

procedures, please refer to section “Expansion Slots”.

Step 3. Install one Radeon graphics card to PCIE5 slot. For the proper installation

procedures, please refer to section “Expansion Slots”.

Step 4. Use one CrossFire

Bridge to connect Radeon graphics cards on PCIE2

and PCIE4 slots, and use the other CrossFire

Bridge to connect Radeon

graphics cards on PCIE4 and PCIE5 slots. (CrossFire

Bridge is provided

with the graphics card you purchase, not bundled with this motherboard.

Please refer to your graphics card vendor for details.)

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

CrossFire

Bridge

Step 5. Connect the DVI monitor cable to the DVI connector on the Radeon graph-

ics card on PCIE2 slot. (You may use the DVI to D-Sub adapter to convert

the DVI connector to D-Sub interface, and then connect the D-Sub monitor

cable to the DVI to D-Sub adapter.)

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

The Catalyst Uninstaller is an optional download. We recommend using this

utility to uninstall any previously installed Catalyst drivers prior to installation.

Please check AMD website for ATI

driver updates.

Step 3. Install the required drivers to your system.

For Windows

XP OS:

AMD

recommends Windows

XP Service Pack 2 or higher to be

installed (If you have Windows

XP Service Pack 2 or higher installed

in your system, there is no need to download it again):

http://www.microsoft.com/windowsxp/sp2/default.mspx

B. You must have Microsoft .NET Framework installed prior to

downloading and installing the CATALYST Control Center. Please

check Microsoft website for details.

For

Windows

7 / Vista

OS:

Install the CATALYST Control Center. Please check AMD website for de-

tails.

Step 4. Restart your computer.

Step 5. Install the VGA card drivers to your system, and restart your computer.

Then you will

nd “ATI Catalyst Control Center” on your Windows

taskbar.

ATI Catalyst Control Center

2.6.2 Driver Installation and Setup

Step 1. Power on your computer and boot into OS.

Step 2. Remove the ATI

driver if you have any VGA driver installed in your

system.

Step 6. Double-click “ATI Catalyst Control Center”. Click “View”, select “CrossFi-

reX

”, and then check the item “Enable CrossFireX

”. Select “2 GPUs”

and click “Apply” (if you install two Radeon graphics cards). Select “3

GPUs” and click “OK” (if you install three Radeon graphics cards).

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

Although you have selected the option “Enable CrossFire

”, the CrossFireX

function may not work actually. Your computer will automatically reboot. After

restarting your computer, please con

rm whether the option “Enable

CrossFire

” in “ATI Catalyst Control Center” is selected or not; if not, please

select it again, and then you are able to enjoy the bene

t of CrossFireX

feature.

Step 7. You can freely enjoy the bene

t of CrossFireX

, 3-Way CrossFireX

Quad CrossFireX

feature.

* CrossFireX

appearing here is a registered trademark of AMD

Technologies Inc., and is

used only for identi

cation or explanation and to the owners’ bene

t, without intent to infringe.

* For further information of AMD

CrossFireX

technology, please check AMD website for

updates and details.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

English

2. If you have installed onboard VGA driver from our support CD to your system

already, you can freely enjoy the bene

ts of dual monitor function after your

system boots. If you haven’t installed onboard VGA driver yet, please install

onboard VGA driver from our support CD to your system and restart your

computer.

2.7 Dual Monitor and Surround Display Features

Dual Monitor Feature

This motherboard supports dual monitor feature. With the internal VGA output sup-

port (D-Sub, HDMI and DVI-D by the bundled HDMI to DVI adapter), you can easily

enjoy the bene

ts of dual monitor feature without installing any add-on VGA card to

this motherboard. This motherboard also provides independent display controllers

for D-Sub, HDMI and DVI-D to support dual VGA output so that D-sub, HDMI and

DVI-D can drive same or different display contents.

To enable dual monitor feature, please follow the steps below:

1. Connect D-Sub monitor cable to VGA/D-Sub port on the I/O panel, connect HDMI

monitor cable HDMI port on the I/O panel, or connect the HDMI to DVI adapter to

the HDMI port on the I/O panel and then connect the DVI-D monitor cable to the

DVI-D connector on the adpater.

D-Sub, HDMI and DVI-D (by the bundled HDMI to DVI adapter) monitors

cannot be enabled at the same time. You can only choose two of them.

HDMI port

VGA/D-Sub port

HDMI port

Fatal1ty Z68 Professional Gen3 Series Motherboard

Surround Display Feature

This motherboard supports surround display upgrade. With the internal VGA output

support (D-Sub, HDMI and DVI-D by the bundled HDMI to DVI adapter) and exter-

nal add-on PCI Express VGA cards, you can easily enjoy the bene

ts of surround

display feature.

Please refer to the following steps to set up a surround display environment:

1. Install the PCI Express VGA cards on PCIE2, PCIE4 and PCIE5 slots. Please

refer to page 24 for proper expansion card installation procedures for details.

2. Connect the D-Sub monitor cable to the VGA/D-Sub port on the I/O panel,

connect HDMI monitor cable to HDMI port on the I/O panel, or connect the HDMI

to DVI adapter to the HDMI port on the I/O panel and then connect the

DVI-D monitor cable to the DVI-D connector on the adpater. Next, connect other

monitor cables to the corresponding connectors of the add-on PCI Express VGA

cards on PCIE2, PCIE4 and PCIE5 slots.

3. Boot your system. Press <F2> or <Del> to enter UEFI setup. Enter “Onboard

VGA Share Memory” option to adjust the memory capability to [32MB], [64MB],

[128MB], [256MB] or [512MB] to enable the function of VGA/D-sub. Please make

sure that the value you select is less than the total capability of the system

memory. If you do not adjust the UEFI setup, the default value of “Onboard VGA

Share Memory”, [Auto], will disable VGA/D-Sub function when the add-on VGA

card is inserted to this motherboard.

4. Install the onboard VGA driver and the add-on PCI Express VGA card driver to

your system. If you have installed the drivers already, there is no need to install

them again.

5. Set up a multi-monitor display.

For Windows

XP / XP 64-bit OS:

Right click the desktop, choose “Properties”, and select the “Settings” tab

so that you can adjust the parameters of the multi-monitor according to

the steps below.

A. Click the “Identify” button to display a large number on each monitor.

B. Right-click the display icon in the Display Properties dialog that you

wish to be your primary monitor, and then select “Primary”. When

you use multiple monitors with your card, one monitor will always be

Primary, and all additional monitors will be designated as Secondary.

C. Select the display icon identi

ed by the number 2.

D. Click “Extend my Windows desktop onto this monitor”.

E. Right-click the display icon and select “Attached”, if necessary.

F. Set the “Screen Resolution” and “Color Quality” as appropriate for the

second monitor. Click “Apply” or “OK” to apply these new values.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

HDCP Function

HDCP function is supported on this motherboard. To use HDCP

function with this motherboard, you need to adopt the monitor

that supports HDCP function as well. Therefore, you can enjoy

the superior display quality with high-de

nition HDCP

encryption contents. Please refer to below instruction for more

details about HDCP function.

What

HDCP?

HDCP stands for High-Bandwidth Digital Content Protection,

speci

cation developed by Intel

for protecting digital

entertainment content that uses the DVI interface. HDCP is a

copy protection scheme to eliminate the possibility of

intercepting digital data midstream between the video source,

or transmitter - such as a computer, DVD player or set-top box -

and the digital display, or receiver - such as a monitor, television

or projector. In other words, HDCP speci

cation is designed to

protect the integrity of content as it is being transmitted.

Products compatible with the HDCP scheme such as DVD

players, satellite and cable HDTV set-top-boxes, as well as few

entertainment PCs requires a secure connection to a compliant

display. Due to the increase in manufacturers employing HDCP

in their equipment, it is highly recommended that the HDTV or

LCD monitor you purchase is compatible.

G. Repeat steps C through E for the diaplay icon identi

ed by the number

one to eight.

For Windows

7 / 7 64-bit / Vista

/ Vista

64-bit OS:

Right click the desktop, choose “Personalize”, and select the “Display

Settings” tab so that you can adjust the parameters of the multi-monitor

according to the steps below.

A. Click the number ”2” icon.

B. Click the items “This is my main monitor” and “Extend the desktop onto

this monitor”.

C. Click “OK” to save your change.

D. Repeat steps A through C for the display icon identi

ed by the number

three to eight.

6. Use Surround Display. Click and drag the display icons to positions representing

the physical setup of your monitors that you would like to use. The placement

of display icons determines how you move items from one monitor to another.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

2.8 Jumpers Setup

The illustration shows how jumpers are

setup. When the jumper cap is placed on

pins, the jumper is “Short”. If no jumper cap

is placed on pins, the jumper is “Open”. The

illustration shows a 3-pin jumper whose

pin1 and pin2 are “Short” when jumper cap

is placed on these 2 pins.

Jumper Setting

Description

Clear CMOS Jumper

(CLRCMOS1)

(see p.4, No. 25)

Note: CLRCMOS1 allows you to clear the data in CMOS. To clear and reset the

system parameters to default setup, please turn off the computer and unplug

the power cord from the power supply. After waiting for 15 seconds, use a

jumper cap to short pin2 and pin3 on CLRCMOS1 for 5 seconds. However,

please do not clear the CMOS right after you update the BIOS. If you need

to clear the CMOS when you just

nish updating the BIOS, you must boot

up the system

rst, and then shut it down before you do the clear-CMOS ac-

tion. Please be noted that the password, date, time, user default pro

le, 1394

GUID and MAC address will be cleared only if the CMOS battery is removed.

Clear CMOS

Default

The Clear CMOS Switch has the same function as the Clear CMOS

jumper.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

the red-striped side to Pin1

2.9 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place

jumper caps over these headers and connectors. Placing jumper caps

over the headers and connectors will cause permanent damage of the

motherboard!

FDD connector

(33-pin FLOPPY1)

(see p.4 No. 31)

Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the

connector.

Primary IDE connector (Black)

(39-pin IDE1, see p.4 No. 8)

Note: Please refer to the instruction of your IDE device vendor for the details.

connect the black end

to the IDE devices

connect the blue end

to the motherboard

80-conductor ATA 66/100/133 cable

English

TA2_2_3 SA

TA2_4_5

TA3_A3_A4 SA

TA3_A1_A2 SA

TA3_0_1

Serial ATAII Connectors

These four Serial ATAII (SATAII)

(SATA2_2_3: see p.4, No. 13)

connectors support SATA data

(SATA2_4_5: see p.4, No. 12)

cables for internal storage

devices. The current SATAII

interface allows up to 3.0 Gb/s

data transfer rate.

Serial ATA3 Connectors

These six Serial ATA3 (SATA3)

(SATA3_0_1: see p.4, No. 14)

connectors support SATA data

(SATA3_A1_A2: see p.4, No. 15)

cables for internal storage

(SATA3_A3_A4: see p.4, No. 16)

devices. The current SATA3

interface allows up to 6.0 Gb/s

data transfer rate. If you install

the HDD on the eSATA port on

the rear I/O, the internal

SATA3_A4 will not function.

Fatal1ty Z68 Professional Gen3 Series Motherboard

USB 2.0 Headers

Besides four default USB 2.0

(9-pin USB6_7)

ports on the I/O panel, there

(see p.4 No. 28)

are two USB 2.0 headers on

this motherboard. Each

USB 2.0 header can support

two USB 2.0 ports.

(9-pin USB8_9)

(see p.4 No. 27)

USB 3.0 Header

Besides four default USB 3.0

(19-pin USB3_4_5)

ports on the I/O panel, there is

(see p.4 No. 9)

one USB 3.0 header on this

motherboard. This USB 3.0

header can support two USB

3.0

ports.

3.5mm Audio Cable

Either end of the 3.5mm audio

(Optional)

cable can be connected to the

portable audio devices, such

as MP3 player and mobile

phone or the Line-in port of

your

PC.

Serial ATA (SATA)

Either end of the SATA data

Data Cable

cable can be connected to the

(Optional)

SATA / SATAII / SATA3 hard

disk or the SATAII / SATA3

connector on this motherboard.

connect to the SATA

HDD power connector

connect to the

power supply

Serial ATA (SATA)

Please connect the black end

Power Cable

of SATA power cable to the

(Optional)

power connector on each drive.

Then connect the white end of

SATA power cable to the power

connector of the power supply.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

Infrared Module Header

This header supports an

(5-pin IR1)

optional wireless transmitting

(see p.4 No. 33)

and receiving infrared module.

Front Panel Audio Header

This is an interface for front

(9-pin HD_AUDIO1)

panel audio cable that allows

(see p.4 No. 34)

convenient connection and

control of audio devices.

1. High De

nition Audio supports Jack Sensing, but the panel wire on

the chassis must support HDA to function correctly. Please follow the

instruction in our manual and chassis manual to install your system.

2. If you use AC’97 audio panel, please install it to the front panel audio

header as below:

A. Connect Mic_IN (MIC) to MIC2_L.

B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.

C. Connect Ground (GND) to Ground (GND).

D. MIC_RET and OUT_RET are for HD audio panel only. You don’t

need to connect them for AC’97 audio panel.

E. To activate the front mic.

For Windows

XP / XP 64-bit OS:

Select “Mixer”. Select “Recorder”. Then click “FrontMic”.

For Windows

7 / 7 64-bit / Vista

/ Vista

64-bit OS:

Go to the "FrontMic" Tab in the Realtek Control panel. Adjust

“Recording Volume”.

System Panel Header

This header accommodates

(9-pin PANEL1)

several system front panel

(see p.4 No. 21)

functions.

Connect the power switch, reset switch and system status indicator on the

chassis to this header according to the pin assignments below. Note the

positive and negative pins before connecting the cables.

CD1

Internal Audio Connectors

This connector allows you

(4-pin CD1)

to receive stereo audio input

(see p.4 No. 38)

from sound sources such as

a CD-ROM, DVD-ROM, TV

tuner card, or MPEG card.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

Chassis and Power Fan Connectors

Please connect the fan cables

(4-pin CHA_FAN1)

to the fan connectors and

(see p.4 No. 22)

match the black wire to the

ground pin. CHA_FAN1/2/3 fan

speed can be controlled through

(3-pin CHA_FAN2)

UEFI or AXTU.

(see p.4 No. 23)

(3-pin CHA_FAN3)

(see p.4 No. 6)

V DUMMY

DUMMY

SPEAKER

Chassis Speaker Header

Please connect the chassis

(4-pin SPEAKER 1)

speaker to this header.

(see p.4 No. 19)

Power LED Header

Please connect the chassis

(3-pin PLED1)

power LED to this header to

(see p.4 No. 20)

indicate system power status.

The LED is on when the system

is operating. The LED keeps

blinking in S1 state. The LED is

off in S3/S4 state or S5 state

(power

off).

PWRBTN (Power Switch):

Connect to the power switch on the chassis front panel. You may con

gure

the way to turn off your system using the power switch.

RESET (Reset Switch):

Connect to the reset switch on the chassis front panel. Press the reset

switch to restart the computer if the computer freezes and fails to perform a

normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel. The LED

is on when the system is operating. The LED keeps blinking when the sys-

tem is in S1 sleep state. The LED is off when the system is in S3/S4 sleep

state or powered off (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel. The LED

is on when the hard drive is reading or writing data.

The front panel design may differ by chassis. A front panel module mainly

consists of power switch, reset switch, power LED, hard drive activity LED,

speaker and etc. When connecting your chassis front panel module to this

header, make sure the wire assignments and the pin assign-ments are

matched correctly.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

CPU Fan Connectors

Please connect the CPU fan

(4-pin CPU_FAN1)

cable to the connector and

(see p.4 No. 3)

match the black wire to the

ground

pin.

ATX Power Connector

Please connect an ATX power

(24-pin ATXPWR1)

supply to this connector.

(see p.4 No. 7)

(3-pin CPU_FAN2)

(see p.4 No. 2)

20-Pin ATX Power Supply Installation

Though this motherboard provides 24-pin ATX power connector,

it can still work if you adopt a traditional 20-pin ATX power supply.

To use the 20-pin ATX power supply, please plug your

power supply along with Pin 1 and Pin 13.

ATX 12V Power Connector

Please connect an ATX 12V

(8-pin ATX12V1)

power supply to this connector.

(see p.4 No. 1)

8 5

4 1

4-Pin ATX 12V Power Supply Installation

Though this motherboard provides 8-pin ATX 12V power connector, it can still work

if you adopt a traditional 4-pin ATX 12V power supply. To use the 4-pin ATX power

supply, please plug your power supply along with Pin 1 and Pin 5.

(3-pin PWR_FAN1)

(see p.4 No. 42)

English

Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin

CPU fan still can work successfully even without the fan speed control function.

If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this

motherboard, please connect it to Pin 1-3.

3-Pin Fan Installation

Pin 1-3 Connected

Fatal1ty Z68 Professional Gen3 Series Motherboard

HDMI_SPDIF Header

HDMI_SPDIF header, providing

(2-pin HDMI_SPDIF1)

SPDIF audio output to HDMI

(see p.4 No. 32)

VGA card, allows the system to

connect HDMI Digital TV/

projector/LCD devices. Please

connect the HDMI_SPDIF

connector of HDMI VGA card to

this

header.

Serial port Header

This COM1 header supports a

(9-pin COM1)

serial port module.

(see p.4 No. 29)

The Installation Guide of Front USB 3.0 Panel

Intall the Front USB 3.0 Panel into

the 2.5” drive bay of the chassis.

Step

Screw the Front USB 3.0 Panel to

the drive bay with six chassis screws.

Prepare the bundled Front USB 3.0

Panel, four HDD screws, and six

chassis screws.

Step

Screw the 2.5” HDD/SSD to the Front

USB 3.0 Panel with four HDD

screws.

IEEE 1394 Header

Besides one default IEEE 1394

(9-pin FRONT_1394)

port on the I/O panel, there

(see p.4 No. 24)

is one IEEE 1394 header

(FRONT_1394) on this

motherboard. This IEEE 1394

header can support one IEEE

1394

port.

English

Fatal1ty Z68 Professional Gen3 Series Motherboard

Reset Switch

Reset Switch is a smart switch,

(RSTBTN)

allowing users to quickly reset

(see p.4 No. 18)

the

system.

Clear CMOS Switch

Clear CMOS Switch is a smart

(CLRCBTN)

switch, allowing users to quickly

(see p.5 No. 17)

clear the CMOS values.

The Installation Guide of Rear USB 3.0 Bracket

2.10 Smart Switches

The motherboard has three smart switches: power switch, reset switch and clear

CMOS switch, allowing users to quickly turn on/off or reset the sytem clear the

CMOS values.

Put the USB 3.0 cable and the rear

USB 3.0 bracket together.

Unscrew the two screws from the

Front USB 3.0 Panel.

Step

Put the rear USB 3.0 bracket into the

chassis.

Screw the two screws into the rear

USB 3.0 bracket.

Step

Power Switch

Power Switch is a smart switch,

(PWRBTN)

allowing users to quickly turn

(see p.4 No. 26)

on/off the system.

The Front USB 3.0 Panel is ready to

use.

Plug the Front USB 3.0 cable into the

USB 3.0 header (USB3_4_5) on the

motherboard.

Step

English

Топ 10 инструкций

100.00

MB QUART DSG 213

99.98

Skil 0790 RA

99.98

Bosch KGN39VW21

99.97

Sony CDX-CA750X RU

99.97

Braun 310 Series 3

99.96

Asus P3-PE5

99.96

Siemens MQ 5 N 298

99.96

YUKON EXTEND LRS-1000

99.96

Bosch GWS 22-230 JH Professional

99.96

Philips Lunettes 3D Active

К рейтингу инструкций и мануалов →

Другие инструкции

Asus Xonar Xense

Asus P4C800 Deluxe

Asus GX1105B

Asus GX1108B
