ASRock Fatal1ty P67 Professional: 1. Introduction

7

Fatal1ty P67 Professional Series Motherboard

1. Introduction

Thank you for purchasing

Fatal1ty P67 Professional Series

 motherboard, a reli-

able motherboard produced under our consistently stringent quality control. It deliv-

ers excellent performance with robust design conforming to our commitment to qual-

ity and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the con

fi

 guration

guide to BIOS setup and information of the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on our website without further notice.

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

1.1 Package Contents

Fatal1ty P67 Professional Series

 Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

Fatal1ty P67 Professional Series

 Quick Installation Guide

Fatal1ty P67 Professional Series

 Support CD

1 x 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable

1 x Ribbon Cable for a 3.5-in Floppy Drive

6 x Serial ATA (SATA) Data Cables (Optional)

2 x Serial ATA (SATA) HDD Power Cables (Optional)

1 x I/O Panel Shield

1 x Front USB 3.0 Panel

4 x HDD Screws

6 x Chassis Screws

1 x Rear USB 3.0 Bracket

1 x SLI_Bridge_2S Card

English

We Remind You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

8

Fatal1ty P67 Professional Series Motherboard

English

1.2 Specifications

 Platform

- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

- All Solid Capacitor design (100% Japan-made high-quality

  Conductive Polymer Capacitors)

 CPU

- Supports 2nd Generation Intel

®

 Core

TM

 i7 / i5 / i3 in

  LGA1155 Package

- Advanced V16 + 2 Power Phase Design

- Supports Intel

®

 Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

- Supports Hyper-Threading Technology (see

CAUTION 1

)

 Chipset

- Intel

®

 P67

 Memory

- Dual Channel DDR3 Memory Technology (see

CAUTION 2

)

- 4 x DDR3 DIMM slots

- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066

  non-ECC, un-buffered memory (see

CAUTION 3

)

- Max. capacity of system memory: 32GB (see

CAUTION 4

)

- Supports Intel

®

 Extreme Memory Pro

fi

 le (XMP)

 Expansion Slot

- 3 x PCI Express 2.0 x16 slots (PCIE2/PCIE4: single at x16

  or dual at x8/x8 mode; PCIE5: x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 2 x PCI slots

 -

Supports

ATI

TM

 Quad CrossFireX

TM

, 3-Way CrossFireX

TM

  and CrossFireX

TM

- Supports NVIDIA

®

 Quad SLI

TM

 and SLI

TM

 Audio

- 7.1 CH HD Audio with Content Protection

  (Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudio Pro

TM

 LAN

- 2 x PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports Dual LAN with Teaming function

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

- 1 x Optical SPDIF Out Port

- 3 x Ready-to-Use USB 2.0 Ports

9

Fatal1ty P67 Professional Series Motherboard

English

- 1 x Fatal1ty Mouse Port (USB 2.0)

- 1 x eSATA3 Connector

- 4 x Ready-to-Use USB 3.0 Ports

- 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

  LED)

- 1 x IEEE 1394 Port

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

  Line in/Front Speaker/Microphone (see

CAUTION 5

)

 SATA3

- 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

  RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ,

  AHCI and "Hot Plug" functions

- 4 x SATA3 6.0 Gb/s connectors by Marvell SE9120,

  support NCQ, AHCI and "Hot Plug" functions

  (SATA3_M4 connector is shared with eSATA3 port)

 USB3.0

- 4 x Rear USB 3.0 ports by Etron EJ168A, support USB 1.0/

  2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by

  Etron EJ168A, supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector

- 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

  RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ,

  AHCI and Hot Plug functions

- 6 x SATA3 6.0Gb/s connectors

- 1 x ATA133 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x IEEE 1394 header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- CD in header

- Front panel audio connector

- 4 x USB 2.0 headers (support 8 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

- 1 x Dr. Debug (7-Segment Debug LED)

Smart Switch

- 1 x Clear CMOS Switch with LED

- 1 x Power Switch with LED

- 1 x Reset Switch with LED

BIOS Feature

- 64Mb AMI BIOS

10

Fatal1ty P67 Professional Series Motherboard

English

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, PCH, CPU PLL, VTT, VCCSA Voltage

  Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version), Software

  Suite (CyberLink DVD Suite - OEM and Trial)

 Unique Feature

- F-Stream (see

CAUTION 6

)

- Instant Boot

- Instant Flash (see

CAUTION 7

)

 -

AIWI

(see

CAUTION 8

)

- APP Charger (see

CAUTION 9

)

- SmartView (see

CAUTION 10

)

- Hybrid Booster:

    - CPU Frequency Stepless Control (see

CAUTION 11

)

    - U-COP (see

CAUTION 12

)

    - Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see

CAUTION 13

)

- Good Night LED

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

  Auto-Adjust by CPU or MB Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-bit

  / XP / XP 64-bit compliant

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 14

)

 WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

11

Fatal1ty P67 Professional Series Motherboard

English

CAUTION!

1.  About the setting of “Hyper Threading Technology”, please check page

70 of “User Manual” in the support CD.

2.  This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 19 for proper installation.

3.  DDR3 frequency options may depend on the processor. Only K-Series

CPU can support DDR3 overclock to 2133 and 1866.

4.  Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

®

 7 /

Vista

TM

 / XP. For Windows

®

 OS with 64-bit CPU, there is no such limita-

tion.

5.  For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 5

for proper connection.

6.  F-Stream is an all-in-one tool to

fi

 ne-tune different system functions in a

user-friendly interface, which currently includes Hardware Monitor, Fan

Control, Overclocking, OC DNA, Mouse Polling and IES. In the Hardware

Monitor mode, F-Stream shows the major readings of your system. In

Fan Control mode, F-Stream shows the fan speed and temperature for

you to adjust. In Overclocking Control mode, F-Stream allows you to

overclock the CPU frequency for optimal system performance. In OC

DNA mode, you can save your OC settings as a pro

fi

 le and share them

with your friends. Your friends can then load the OC pro

fi

 le in to their own

system to get the same OC settings. In Mouse Polling mode, F-Stream

allows you to adjust the mouse polling rate of the Fatal1ty Mouse port to

add a professional level mouse con

fi

 guration. In IES (Intelligent Energy

Saver) mode, the voltage regulator can reduce the number of output

phases to improve ef

fi

 ciency when the CPU cores are idle without sacri-

fi

 cing computing performance.

7.  Instant Flash is a BIOS

fl

 ash utility embedded in Flash ROM. This con-

venient BIOS update tool allows you to update system BIOS without

entering operating systems

fi

 rst like MS-DOS or Windows

®

. With this util-

ity, you can press <F6> key during the POST or press <F2> key to BIOS

setup menu to access Instant Flash. Just launch this tool and save the

new BIOS

fi

 le to your USB

fl

 ash drive,

fl

 oppy disk or hard drive, then you

can update your BIOS only in a few clicks without preparing an additional

fl

 oppy diskette or other complicated

fl

 ash utility. Please be noted that the

USB

fl

 ash drive or hard drive must use FAT32/16/12

fi

 le system.

12

Fatal1ty P67 Professional Series Motherboard

English

8.  To experience intuitive motion controlled games is no longer only avail-

able at Wii. AIWI utility introduces a new way of PC gaming operation.

AIWI is the world's

fi

 rst utility to turn your iPhone/iPod touch as a game

joystick to control your PC games. All you have to do is just to install the

AIWI utility either from our of

fi

 cial website or our software support CD to

your motherboard, and also download the free AIWI Lite from App store

to your iPhone/iPod touch. Connecting your PC and apple devices via

Bluetooth or WiFi networks, then you can start experiencing the exciting

motion controlled games. Also, please do not forget to pay attention to

our of

fi

 cial website regularly, we will continuously provide you the most

up-do-date supported games!

9.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, we have prepared a wonderful solution

for you - APP Charger. Simply installing the APP Charger driver, it makes

your iPhone charged much quickly from your computer and up to 40%

faster than before. APP Charger allows you to quickly charge many Apple

devices simultaneously and even supports continuous charging when

your PC enters into Standby mode (S1), Suspend to RAM (S3), hiberna-

tion mode (S4) or power off (S5). With APP Charger driver installed, you

can easily enjoy the marvelous charging experience than ever.

10.  SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. Our motherboards are exclusively equipped

with the SmartView utility that helps you keep in touch with friends on-

the-go. To use SmartView feature, please make sure your OS version is

Windows

®

 7 / 7 64 bit / Vista

TM

 / Vista

TM

 64 bit, and your browser version

is IE8.

11.  Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU.

12.  When it is detected that the CPU is overheating, the system will automat-

ically shutdown. Before you re-start the system, please check if the CPU

fan on the motherboard functions properly and unplug the power cord,

then plug it back again. To improve heat dissipation, remember to spray

thermal grease between the CPU and the heatsink when you install the

PC sys tem.

13.  Combo Cooler Option (C.C.O.) provides the

fl

 exible option to adopt three

different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.

Please be noticed that not all the 775 and 1156 CPU Fan can be used.

13

Fatal1ty P67 Professional Series Motherboard

English

14.  EuP, stands for Energy Using Product, was a provision regulated by Eu-

ropean Union to de

fi

 ne the power consumption for the completed system.

According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to

Intel’s suggestion, the EuP ready power supply must meet the standard

of 5v standby power ef

fi

 ciency is higher than 50% under 100 mA current

consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.

14

Fatal1ty P67 Professional Series Motherboard

English

1.3 Two

SLI

TM

 Graphics Card Support List

 (for

Windows

®

 XP / XP 64-bit / Vista

TM

 / Vista

TM

 64-bit / 7 / 7 64-bit)

* For the latest updates of the supported PCI Express VGA card list for SLI

TM

 Mode,

   please visit our website for details.

Chipset     Model Name

Chipset Name             Driver

Vendor

NVIDIA

ASUS EN9800GT TDP/HTDP/512M

GeForce 9800GT         257.21

Chaintech GES96GT-A1512P

GeForce 9600 GT        257.21

Gigabyte GV-NX88T256H

GeForce 8800 GT        257.21

GIGABYTE GV- N295-18I-B

GeForce GTX295        257.21

GIGABYTE GV-N26-896H-B

GeForce GTX 260       257.21

LEADTEK PX9800 GTX+

GeForce 9800GTX+    257.21

LEADTEK PX9800GTX

GeForce 9800GTX      257.21

LEADTEK PX8800 GTX TDH

GeForce 8800 GTX     257.21

LEADTEK GTX275/896M-DDR3

GeForce GTX275        257.21

MSI NX8600GT-T2D256E

GeForce 8600 GT       257.21

MSI N465GTX-M2D1G-B

GeForce GTX465        257.21

MSI N250GTS-2D512-OC

GeForce GTS 250       257.21

SPARKLE SF-PX98GX221024D3-NHM  GeForce 9800GTX2    257.21

15

Fatal1ty P67 Professional Series Motherboard

English

1.4 Two

CrossFireX

TM

 Graphics Card Support List

 (for

Windows

®

 XP / XP 64-bit / Vista

TM

 / Vista

TM

 64-bit / 7 / 7 64-bit)

* For the latest updates of the supported PCI Express VGA card list for CrossFireX

TM

   Mode, please visit our website for details.

1.5 Three

CrossFireX

TM

 Graphics Card Support List

 (for

Windows

®

 Vista

TM

 / Vista

TM

 64-bit / 7 / 7 64-bit)

* For the latest updates of the supported PCI Express VGA card list for CrossFireX

TM

   Mode, please visit our website for details.

Chipset     Model Name                                       Chipset Name           Driver

Vendor

ATI

ASUS EAH5850/G/2DIS/1GD5/A      Radeon HD 5850

Catalyst 10.9

MSI R5770-PM2D1G

    Radeon HD 5770

Catalyst 10.9

Powercolor AX4670 512MD3-P

    Radeon HD 4670

Catalyst 10.9

Powercolor AX3870 512MD4-H

    Radeon HD 3870

Catalyst 10.9

Chipset     Model Name                                       Chipset Name           Driver

Vendor

ATI

ASUS EAH5850/G/2DIS/1GD5/A      Radeon HD 5850

Catalyst 10.9

ASUS EAH5750/2DIS/1GD5/A

    Radeon HD 5750

Catalyst 10.9

ASUS EAH4350 SILENT/DI/

    Radeon HD 4350   Catalyst 10.9

512M D2/A

MSI R5770-PM2D1G

    Radeon HD 5770

Catalyst 10.9

MSI R5570-MD1G/1G-DDR3

    Radeon HD 5570

Catalyst 10.9

Powercolor HD5670-HDMI/1G-       Radeon HD 5670

Catalyst 10.9

DDR5

Powercolor AX5450-512MK3-

    Radeon HD 5450

Catalyst 10.9

SH/512M-DDR3

Powercolor HD4890-HDMI/1G-       Radeon HD 4890

Catalyst 10.9

DDR5

Powercolor HD4830-HDMI/512M-      Radeon HD 4830  Catalyst 10.9

DDR3

Powercolor AX4670 512MD3-P

    Radeon HD 4670

Catalyst 10.9

Powercolor HD4550-HDMI/

    Radeon HD 4550

Catalyst 10.9

512M-DDR3

Powercolor AX3870 512MD4-H

    Radeon HD 3870

Catalyst 10.9

Powercolor AX3650 512MMD3-XP     Radeon HD 3650

Catalyst 10.9
