V. SPECIFICATIONS

MAIN UNIT

Model EY7411

Machine screw M2.5 – M5

Screw driving

Capacity

Wood screw ø 3.8 × 38 mm (5/32

"

× 1-29/64

"

)

Drilling For metal ø 5 mm (13/64

"

) spc t = 1.6 mm

Motor 3.6 V DC

-1

LOW: 200 min

(rpm)

No load speed

-1

HIGH: 600 min

(rpm)

LOW: 4.4 N·m (45 kgf-cm, 39 in-lbs)

Maximum torque

HIGH: 1.5 N·m (15 kgf-cm, 13 in-lbs)

Maximum clutch torque 3.0 N·m (30 kgf-cm, 26 in-lbs)

Overall length 283 mm (11-5/32

"

)

Weight (with battery pack) 0.5 kg (1.1 lbs)

BATTERY PACK

Model EY9L10

Storage battery Li-ion Battery

Battery voltage 3.6 V DC (3.6 V × 1 cell)

Capacity 1.5 Ah

BATTERY CHARGER

Model EY0L10

Weight 0.6 kg (1.3 lbs)

Electrical rating See the rating plate on the bottom of the charger.

2.4 V

3.6 V

EY9021

EY9025

1.2 Ah

Full: 15 min.

Full: 15 min.

Charging time

EY9L10

Usable: 15 min.

1.5 Ah

Full: 30 min.

NOTE:

• For applicable battery packs to this charger, see the label on the charger or the

latest general catalog.

The instruction label on the battery packs also shows the applicable charger.

-
