Alexika T 25 digital ULTRA-TURRAX: Warranty Technical data

18

Warranty Technical data

The warranty does not cover worn out parts, nor

does it apply to faults resulting from improper

use, insufficient care or maintenance not carried

out in accordance with the instructions in this

operating manual.

In accordance with

IKA

®

 warranty conditions,

the warranty period is 24 months. For claims un-

der the warranty please contact your local dea-

ler. You may also send the machine direct to our

factory, enclosing the delivery invoice and giving

reasons for the claim. You will be liable for freight

costs.

Design voltage

V

AC

200 - 240 ± 10%

or

100 - 120 ± 10%

Nominal voltage

V

AC

 230

or

 115

Frequency

Hz 50/60

Power consumption

W

700

Power output

W

500

Speed range

rpm

3 000 - 25 000

(at nominal voltage

230V / 50Hz

and 115V / 60 Hz)

Speed variation on load change

%

<1

Motor speed display

3-digit LED display,

displayed value x 1000

= motor speed in rpm

Display resolution

rpm

200

Perm. ambient temperature

°C

+ 5 ... + 40

Perm. humidity

%

80

Perm. on time

%

100

Protection to DIN EN 60529

IP 20

Contamination level

2

Protection class

II

Overvoltage category

II

Noise level (without dispersing tool)

dbA

75

Dimensions drive (WxDxH)

mm

65x106x271

(W with knurled screw 87)

Dimensions boom

mm

Ø13/ L160

Weight

kg 2.5

Operation at a terrestrial altitude

m

max. 2000 above sea

level

Subject to technical changes!
