HEIDENHAIN ND 2100G Installation: 3 Mounting

Installation Instructions

en

ND 2100G GAGE-CHEK

16

3 Mounting

The following steps are only to be performed by

qualified personnel!

For more information: see "Personnel

qualification", page 14.

Unpacking

Open the top lid of the box.

Remove the packaging materials.

Unpack the contents.

Check the delivery for completeness.

Check the delivery for damage.

If any components were damaged in transit,

keep the packaging materials for inspection and

contact your HEIDENHAIN distributor or OEM.

This applies also if you need replacement parts.

In case of damage in transit

Have the shipping agent confirm the damage.

Keep the packaging materials for inspection.

Notify the sender of the damage.

If necessary, contact your distributor for mediation.

Contact your HEIDENHAIN distributor or OEM for

replacement parts.

Items supplied

The following items are included in the shipment:

Unit with pre-installed mounting adapter

or

Unit with separate mounting stand for assembly on site

Protective cover for the unit

Power cord

Connector for relay contacts

Installation Instructions

Addendum (optional, for more information see "Notes on

reading the documentation", page 13)

Accessories

The following items are optionally available and can be

ordered from HEIDENHAIN as additional accessories:

Optional accessories

ID number

Mounting adapter

682419-01

Mounting stand

382892-02

Foot switch

681041-01

Remote keypad

681043-01

QUADRA-CHEK Wedge

communication software

709141-01

Protective cover

681051-03

3.2

Assembly

If the unit is supplied with pre-installed mounting

adapter, no assembly is required.

If the unit is supplied with separate mounting stand, the

stand needs to be attached. For more information see

"Attaching the mounting stand", page 16

Attaching the mounting stand

See "C" on the front fold-out page.

Mounting the unit with mounting stand on a benchtop

or machine (optional)

Using the mounting holes provided on the underside of

the mounting stand, you can firmly screw the unit to a

benchtop.

Horizontal tilting of the unit in the tilt guides is still possible

after screw-mounting.

If the unit has a pre-installed mounting adapter,

you need to remove the mounting adapter first

and then attach the mounting stand. For more

information see "Attaching the mounting stand",

page 16. The mounting stand is available as

an optional accessory (ID 382892-02).

The mounting adapter is removed in the reverse

order in which the mounting stand is attached.

Dimensions for screw mounting

See "F" in the Appendix.

When mounting the unit on a benchtop or

machine, choose a surface that is flat and stable

and provides sufficient space for installation and

operation.

The surface has to be accessible from the rear to

allow screw mounting of the unit.

Mounting the unit with mounting stand on a

benchtop or machine

Drill four holes at the desired mounting location.

Align the mounting holes of the unit with the holes you

drilled.

To fasten the mounting stand to the mounting location,

insert and tighten the four M5 screws from the rear.

Mounting the unit with mounting adapter on a support

arm or benchtop

Using the mounting holes on the underside of the pre-

installed mounting adapter, you can screw the unit to a

support arm or benchtop.

Dimensions of mounting adapter

See "G" in the Appendix.
