Defrosting
A) Fridge compartment
The fridge compartment defrosts
automatically. The defrost water runs to the
drain tube via a collection container at the
back of the appliance (Item 6).
During defrosting, water droplets may form at
the back of the fridge compartment where a
concealed evaporator is located. Some
droplets may remain on the liner and refreeze
when defrosting is completed. Do not use
pointed or sharp-edged objects such as
knives or forks to remove the droplets which
have refrozen.
If, at any time, the defrost water does not
drain from the collection channel, check that
no food particles have blocked the drain tube.
The drain tube can be cleared with a pipe-
cleaner or similar implement.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor
to prevent the water spilling on the electric
installation or on the floor (Item 7).
B) Freezer compartment
The NO FROST type defrost is compleetly
automatic. No intervention from your side is
requiered. The water is colected on the
compressor tray. Due the heat of the
compressor the water is evaporated
Never use hairdryers, electrical heaters or
other such electrical appliances for defrosting.
Sponge out the defrost water collected in the
bottom of the freezer compartment. After
defrosting, dry the interior thoroughly (Item 8
& 9). Insert the plug into the wall socket and
switch on the electricity supply.
1
Warnings!
The fan inside the freezer compartment
circulates cold air. Never insert any object
through the guard. Do not allow children to
play with the freezer fan.
Never store products that contain inflammable
propellant gas (eg dispensers, spray cans
etc.) or explosive substances.
Don’t cover the shelves with any protective
materials, which may obstruct air circulation.
Do not allow children to play with the
appliance or tamper with the controls.
Do not obstruct the freezer fan guard to
ensure that you obtain the best possible
performance from your appliance.
(Item 10)
Warning!
Your appliance is fitted with a circulating fan
which is essential for the performance of the
freezer. Please ensure the fan is not blocked
(stopped) or impaired by food or packaging.
Blocking (stopping) or impairing the fan can
result in an increase of the internal freezer
temperature (Thawing).
Replacing the interior light bulb
(Item 11)
In case that the light bulb is out of function it is
easily to replace. First make sure that the
refrigerator / freezer is disconnected from the
power supply by removing the plug. Take a flat
screwdriver and keep it carefully without force
into the left gap between lamp cover and
internal cabinet. Then press the handle of the
screwdriver carefully to the left side until you
notice that the left pin of the cover is
disengaged . Repeat this procedure on the right
gap, however now press the handle of the
screwdriver carefully to the right side. If both
sides are loosened the cover can be removed
easily.
Ensure that bulb is screwed securely in the bulb
holder. Plug the appliance into the power
supply. If the light still fails, replace E14 screw-
cap type 15 Watt (Max) bulb from your local
electrical store and then fit it. Carefully dispose
of the burnt-out light bulb immediately.
If you have changed the light bulb please fix the
cover again in it’s former position. Take care
that the cover snaps-in correctly.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or
abrasive substances, soap, household
cleaner, detergent or wax polish for cleaning.
3. Use luke warm water to clean the cabinet
of the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution
of one teaspoon of bicarbonate of soda to one
pint of water to clean the interior and wipe it
dry.
5. Make sure that no water enters the
5
GB Instruction for use
5. Make sure that no water enters the
temperature control box.
6. If the appliance is not going to be used for
a long period of time, switch it off, remove all
food, clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to
protect the high quality paint finish.
8. Any dust that gathers on the condenser,
which is located at the back of the appliance,
should be removed once a year with a
vacuum cleaner.
9. Check door seals regularly to ensure they
areclean and free from food particles.
10. Never:
• Clean the appliance with unsuitable material;
Do’s and don’ts
Do- Clean and defrost your appliance
regularly (See "Defrosting")
Do- Keep raw meat and poultry below
cooked food and dairy products.
Do- Take off any unusable leaves on
vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and
cauliflower on the stem.
Do- Wrap cheese firstly in greaseproof paper
and then in a polythene bag, excluding
eg petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Removal of dairy cover and door tray :
• To remove the dairy cover, first lift the cover
up by about an inch and pull it off from the
side where there is an opening on the cover.
• To remove a door tray, remove all the
contents and then simply push the door tray
upwards from the base.
12. Make sure that the special plastic
container at the back of the appliance which
collects defrost water is clean at all times. If
you want to remove the tray to clean it, follow
the instructions below:
• Switch off at the socket outlet and pull out
the mains plug
• Gently uncrimp the stud on the compressor,
using a pair of pliers, so that the tray can be
removed
• Lift it up.
• Clean and wipe it dry
• Reassemble, reversing the sequence and
operations
13. To remove a drawer, pull it as far as
possible, tilt it upwards and then pull it out
completely.
Repositioning the door
Proceed in numerical order (Item 12).
as much air as possible. For best results,
take out of the fridge compartment an
hour before eating.
Do- Wrap raw meat and poultry loosely in
polythene or aluminium foil. This
prevents drying.
Do- Wrap fish and offal in polythene bags.
Do- Wrap food with a strong odour or which
may dry out, in polythene bags, or
aluminium foil or place in airtight
container.
Do- Wrap bread well to keep it fresh.
Do-
Chill white wines, beer, lager and mineral
water before serving.
Do- Check contents of the freezer every so
often.
Do- Keep food for as short a time as possible
and adhere to "Best Before" and "Use
by" etc. dates.
Do- Store commercially frozen food in
accordance with the instructions given on
the packets.
Do- Always choose high quality fresh food
and be sure it is thoroughly clean before
you freeze it.
Do- Prepare fresh food for freezing in small
portions to ensure rapid freezing.
Do- Wrap all food in aluminium foil or freezer
quality polythene bags and make sure
any air is excluded.
Do- Wrap frozen food immediately after
purchasing and put it in to the freezer as
soon as possible.
Do- Defrost food in the fridge compartment.
6
Don’t
-
Store bananas in your fridge
compartment.
Don’t- Store melon in your fridge. It can be
chilled for short periods as long as it
is wrapped to prevent it flavouring
other food.
Don’t- Cover the shelves with any protective
materials which may obstruct air
circulation.
Don’t- Store poisonous or any dangerous
substances in your appliance. It has
been designed for the storage of
edible foodstuffs only.
Don’t- Consume food which has been
refrigerated for an excessive length of
time.
Don’t- Store cooked and fresh food together
in the same container. They should
be packaged and stored separately.
Don’t- Let defrosting food or food juices drip
onto food.
Don’t- Leave the door open for long periods,
as this will make the appliance more
costly to run and cause excessive ice
formation.
Don’t- Use sharp edged objects such as
knives or forks to remove the ice.
Don’t- Put hot food into the appliance. Let it
cool down first.
Don’t- Put liquid-filled bottles or sealed cans
containing carbonated liquids into the
freezer, as they may burst.
Don’t- Exceed the maximum freezing loads
when freezing fresh food.
Don’t- Give children ice-cream and water
ices direct from the freezer. The low
temperature may cause 'freezer
burns' on lips.
Don’t- Freeze fizzy drinks.
Don’t- Try to keep frozen food which has
thawed; it should be eaten within 24
hours or cooked and refrozen.
Don’t- Remove items from the freezer with
wet hands.
GB Instruction for use
Information about operating noises
To keep the selected temperature constant,
your appliance occasionally switches ON the
compressor.
The resulting noises are quite normal.
As soon as the appliance has reached the
operating temperature, the noises
automatically reduce in volume.
The humming noise is emitted by the motor
(compressor). When the motor switches ON,
the noise may briefly increase in volume.
An sudden click can be heares some times
due to the timer changing position
The bubbling, gurgling or whirring noise is
emitted by the refrigerant as it flows through
the pipes.
The clicking noise can always be heard when
the setting knob ON/OFF the motor.
A clicking noise may occur when
- the automatic defrosting system is active.
- the appliance is cooling down or warming up
(material expansion).
If these noises are excessively loud, the
causes are probably not serious and are
usually very easy to eliminate.
- The appliance is not level - Use the height-
adjustable feet or place packing under the
feet.
- The appliance is not free-standing - Please
move the appliance away from kitchen units
or other appliances.
- Drawers, baskets or shelves are loose or
stick - Please check the detachable
components and, if required, refit them.
-
7
Bottles and/or receptacles are touching each
other - Please move bottles and/or
receptacles away from each other.
Trouble - shooting
If the appliance does not operate when
switched on, check;
• That the plug is inserted properly in the
socket and that the power supply is on. (To
check the power supply to the socket, plug
in another appliance)
• Whether the fuse has blown/circuit breaker
has tripped/main distribution switch has
been turned off.
Technical data
Brand
Model CHA28021S
Appliance type COMBI NO FROST
Total gross volume (l.) 294
Total usable volume (l.) 265
Freezer usable volume (l.) 61
Refrigerator useful volume 204
Freezing capacity (kg/24 h) 4
Energy class (1) A+
Power consumption (kWh/year) (2) 256
Autonomy (h) 18
Noise [dB(A) re 1 pW] 40
Ecological refrigerating agent R600a
(1) Energy class : A . . . G (A = economical . . . G = less economical)
(2) The real power consumption depends on using conditions and appliance location.
GB Instruction for use
• That the temperature control has been set
correctly.
• That the new plug is wired correctly, if you
have changed the fitted, moulded plug.
If the appliance is still not operating at all after
above checks, contact the dealer from whom
you purchased the unit.
Please ensure that above checks have been
done, as a charge will be made if no fault is
found.
8
The symbol on the product or on packaging indicates that this product may not be
treated as household waste. Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negatyve consequences for the
environment and humann health, which could otherwise be otherwise be caused by
inappropriate waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, you household waste
disposal service or the shop where you purchased the product.
Оглавление
- Руководство по эксплуатации
- GB Instruction for use
- GB Instruction for use
- GB Instruction for use
- GB Instruction for use
- D Gebrauchsanweisung
- D Gebrauchsanweisung
- D Gebrauchsanweisung
- D Gebrauchsanweisung
- NL Gebruiksaanwijzing
- NL Gebruiksaanwijzing
- NL Gebruiksaanwijzing
- RUS Инструкция по эксплуатации
