Elta 2322USB: TROUBLESHOOTING

23.

TROUBLESHOOTING

If you experience any problem with this system, first check this list before contacting the customer service.

WARNING: Never open the unit but always refer repairs and maintenance to an authorized customer

service.

CLEANING AND CARE

Cleaning the enclosure

• Use a soft cloth. If the surfaces are extremely dirty, use a soft cloth slightly moistened with a mild cleaning

  lotion.

• Do not use strong solvents like alcohol, benzene or thinner, as those can damage the surface of the unit.

• You can remove the grills of both speakers for cleaning by carefully pulling them.

PROBLEM

POSSIBLE CAUSE

SUGGESTION

GENERAL

No sound

Volume is too low.

Earphones are connected.

Batteries are exhausted.

Batteries are not inserted

correctly.

Power cord is not connected

correctly.

Adjust the volume.

Disconnect the earphones.

Insert new batteries.

Observe the polarity.

Connect the power cord

correctly.

RADIO

Poor reception

CD skips

Poor signal.Interference by

other electronic devices

(video recorder, computer,

etc.)

Direct the antenna:

FM: wire antenna.

AM: direct the unit.

Keep distance to other

electronic devices.

CASSETTE RECORDER

Poor sound quality

Sound head, drive mechanism

or pin rollers are dirty.

Clean the sound head, drive

mechanism or pin rollers.

CD/MP3

CD/MP3 is damaged or dirty.

Replace or clean the disc.

Recording is not possible

The recording interlocks in

the cassette tape are

quarried out.

Cover the position with some

adhesive tape.

Buttons do not respond.

Electrostatic charge.

Disconnect the mains plug for a

few seconds and then turn the

Sunit on again.

24.

Handling and care of CD´s

Handling of audio cassette tapes

1. Loose tape bands can cause problems. Use a pencil to carefully tighten the tape band (see fig. 1).

2. To avoid unintentional deleting of a tape, please quarry out the recording interlock (see fig. 2). If you want

    to record the tape later on, put adhesive tape on the gap (see fig. 3).

3. Storing cassette tapes:

    Do not store cassette tapes in direct sunlight or near radiating devices. Keep cassette tapes away from

    magnets.

4. 120-minutes-tapes:

    120-minutes-tapes have a very thin tape band that can easily tear or be damaged.

5. Infinite cassette tapes:

    Please do not use infinite cassette tapes; these can damage the unit.

6. Cleaning the sound head:

Always keep the sound head, drive mechanism and pin rollers clean to

guarantee best operation of the unit.

Clean those components as follows:

1. Open the cassette deck.

2. Immerse a Q-tip in some cleaning alcohol and carefully clean sound

    head, drive mechanism and pin rollers.

• Only hold CD´s on their edges to protect the surface from finger prints. Finger prints, dirt

  and scratches can cause skipping and distortion.

• Do not write on the printed CD side using a ball pen or any other pen.

• Do not use benzene, thinner or liquids against electrostatic charge.

• Do not drop or bend CD´s.

• Only insert one CD into the CD drive.

• Do not close the CD drive when the CD is not correctly inserted.

Cleaning CD´s

• Clean CD´s with a soft cloth.

• Clean CD´s from center to edges.

Storage

Store CD´s in their cover after playback.

(Fig.1)

Q-TIP

SOUND

HEAD

TRACK

PIN ROLLER

DRIVE

MECHANISM

TIGHTEN THE TAPE BAND WITH A PENCIL

(Fig.2)

Side A

Side B

Adhesive tape

Recording interlock B

Recording interlock A

(Fig.3)
