Xoro HTC 1525D: DVD-Player

DVD-Player: Xoro HTC 1525D

DVD-Player

The DVD Player is activated by repeated printings of the AV/TV key.

The DVD Slot-In loader opens and produces now some noise. The Slot-In loader is on the

left side of the HTC xx25D. Place the disc with the printed side to the rear into the loader

and push very slightly to the right side. You can see the silver side. The loader moves in the

disc automatically and reads the disc information.

Note:

If the disc is inserts with the wrong side, than the

loader tries to read the disc. This procedure needs

more time than in a normal way. The loader can not

English

read the disc content and displays the message “No

disc” and moves out the disc.

NOTE:

To be able to eject a CD or DVD it is necessary to

enable the DVD mode. Otherwise the pressing of the

OPEN/CLOSE button (▲

) will be without function.

Switch on the unit and press the SOURCE button

repeatedly, until “DVD” is displayed right above on the

screen. Now the HTC xx25d is in DVD mode.

Function

An On Screen Display (OSD) indicator will be displayed at the upper part TV screen when

certain functions are executed, or when pressing the OSD button on the remote control.

The OSD indicator is a user friendly interface designed to display the status of play-

back type . When a different disc is loaded (DVD, CD, Music ready); the OSD indicator

bar will be different

The OSD bar will appear automatically if it is activated by pressing the OSD button, Press

the OSD button again and a new status bar will appear. Press OSD button a third time and

the OSD bar will disappear. When OSD indicator bar appears, press other button, the OSD

indicator bar will disappear automatically.

26

DVD-Player

Function

By pressing the OSD button again the following picture is shown by Video –DVD:

1. Active sound track

2. Format of sound track DD 5.1 CH (channel)

3. Subtitle (not included in this example) (OFF)

English

4. More aspects (in this example there are no aspects activate at moment)

By MPEG-4 video files the information is a bit different than with a video DVD.

Important information for a ISO Data disk with MPEG-4 files are:

1. Disc Format (here CDROM)

2. Number of tracks and which one is just played

3. With or without sound

4. Running time

Open/Close

To open and close the disc tray. Press OPEN button on the front panel or the remote.

Notes:

• Player will not skip forward or backward during “WARNING” section of a DVD disc.

• Single chapter DVD or single track CD cannot skip

Play/Pause

Press PLAY button to play the disc. Press PLAYP/AUSE button again to pause (still

picture). Press PLAY/PAUSE button to playback the content.

Stop

Press STOP button to stop in two modes:

• Press STOP button once. Stop memorizes the interrupt position and the

OSD shows PRESTOP. Resume play by pressing PLAY button.

• Press STOP button twice completely stop disc. The OSD shows “STOP” and

the PLAY button will resume disc.

27

DVD-Player

Function

Press this button skip advance DVD chapter or CD track.

Press this button skip backward DVD chapter or CD track.

Fast Backward/Fast Forward

Press this button to fast backward through the disc. Repeatedly press the button.

Press this button to fast forward through the disc. Repeatedly press the button will

increase the search speed.

Notes:

English

• The changes in speed by fast backward or fast forward are from Normal —> x2 —>

x4 —> x8 —> 20 —> Normal

• The player is muted in fast forward or fast backward this mode.

• Player will not fast forward or fast backward during WARNING section of a DVD disc

DVD Menu

While playing a DVD, press the MENU button return to the DVD disc menu.

Numeric Buttons

Numerical key pad (Random Program access)

1. To direct access a DVD chapter or a CD track, input the desired

DVD chapter or CD track number using the numerical key pad.

2. Input data for the DVD disc start menu or the player’s setup menu.

Title

While playing a DVD, press the TITLE button return to the DVD disc title menu.

Audio Track

While playback a DVD disc, press LANG button repeatedly to select the desired

audio sound track. A DVD disc may contains up to 8 selectable audio sound tracks.

28

DVD-Player

Function

Repeat section A-B

To repeat playback a specific section of a disc.

• Press the A-B button at the starting point of the desired section, “REPEAT A-”

display on screen.

• Press the A-B button again, at the end of the desired section, “REPEAT A-B” display on

screen. The desired section A to B until the function is cancelled.

English

• To cancel the function, Press the A-B button again return to normal play.

Note:

Some DVD discs do not allow A-B function

Repeat Mode

Press PEPEAT button repeatedly to select the repeat mode.

In DVD mode In CD mode

REP. CHAPTER Repeat chapter REP. 1 Repeat track

REP. TITLE Repeat title REP. ALL Repeat disc

REP. OFF Repeat off REP. OFF Repeat off

Note:

Some DVD discs do not allow repeat function

.

Angle

While playback a DVD disc, press ANGLE button repeatedly to select the desired

camera angle. A DVD disc may contain up to 9 selectable camera angles.

Subtitle

While play a DVD disc, press SUB-T button repeatedly to select the desired subtitle,

A DVD disc may contains up to 32 selectable subtitles.

Note:

DVD disc start menu may contains set up of angle, Subtitle and Audio soundtrack selection.

You may do the selection in the disc start menu.

Zoom

Press the ZOOM button repeatedly TV Screen display:

ZOOM x2 —> ZOOM x3 —> ZOOM x4 —>ZOOM x1/2 —> ZOOM x1/3 —> ZOOM

x1/4 —> ZOOM OFF

When playback the JPEG. Press the ZOOM button display the zoom x1/2, x1/3, x1/4, press

direction button to rotate picture. While display the zoom x2, x3, x4, press direction button to

move picture position.

29

DVD-Player

Function

Program

Press PROG button to quit the program menu.

In DVD mode

When the program menu appears input the Title and Chapter Number

PLAY: Press PLAY button to start program play.

CLEAR: Press CLEAR button if you want to cancel the wrong information you input. Press

CLEAR again to cancel all the tracks.

In CD mode

English

When the program menu appears, input the Track number, press ENTER, when the

programming is completed.

30

DVD-Player

Data disc with Music, JPEG or Video files

1. Switch on the unit

2. Pressing SOURCE button repeatedly till “DVD” is displayed above left on screen.

3. Insert a disc with Music, JPEG or MPEG-1, MPEG-2 or MPEG-4 video files

Insert the a disc and the player will auto search the directories saved Music/JPEG files. After

searching, it will auto go to the first directory saved Music files (to the disc containing both

Music and JPEG files. To the disc containing single type of files, it will go to the first direc-

tory) and play the first song in the directory (File name is highlighted). The screen displays

English

as the picture below:

Current file name

Current directory name

The slide bars will be

moved down while file

moves

File Switch Re-

gion: Display the

file type of the

playing and the

switching

The playing file is music

The playing file is a video file

The playing file is a JPEG

Note:

• With the arrow key to the right you can change between the catalogue window, the

Chops and Track window and to the file format. File formats are of the order: music

(mark (note)), pictures (camera) and video (arrow).

• The DVD player starts with the playback of Music files.

31

DVD-Player

Data disc with Music, JPEG or Video files

1. Use the Arrow buttons to enter the Directory Region and highlight the desired directory,

then the first track under it starts playback. You also can use the arrow buttons to enter

the File Region and select the file you want to play .

Notes:

• With pressing the Left and Right arrow buttons, you can activate Directory

Region, File Region and File Switch Region separately.

• The highlight in Directory Region and File Region is shown as the picture on

left page; While highlighted, a transparent rectangle appears

• In File Switch Region, you can press the Left and Right arrow buttons to switch

English

the highlight, then press Enter; the ” ” “ ” and “ ”Button is illustrated in

the left side picture. For example, if a disc with Music and JPEG files but with-

out any Video files is loaded, the color of the letter “ ” and “ ” will be

white and “ ” black. If a Music file playing, “ ” turns red.

• When playing a JPEG picture on discs containing WMA, MP3 and JPEG files,

press the Return button to return to JPEG list.

• You can press the Numeric buttons to select the file you want to play. For

th

example, if you desire the 15

track in current list, press the “10+” Button once,

th

then press “5”, the 15

starts playback.

Notes:

• When playing a disc with MP3files, no video can be displayed at the same

time.

• You can press the “PREVIEW” buttons to get helpful message.

• When playing JPEG picture, press the Program button to choose the picture

transition mode. There are 17 transition modes available. Press Program

repeatedly to activate the function and choose the desired switch mode. Fol-

lowing transition modes are available :Spread from Left Up to Down, Spread

from Down to Left, spread from Left to Right, Spread from Right to Left,

Spread from Left Up to Right Down, spread from Right UP to Left Down,

Spread Left Down to Right Up, Spread From Right Down to Left Up, Spread

from Center to Up /Down, Fold from Up /Down to Center, old from Left/ Right

to Center, Horizontal Shutter, Vertical Shutter, Fold from the Corners to the

Center, and Play, Off.

32
