Xoro HTC 1525D: Troubleshooting
Troubleshooting: Xoro HTC 1525D

Troubleshooting
Our custom service will help you. Did you already read the Troubleshooting pages?
Technical custom service of Xoro/MAS:
• Phone: +49 40 77 11 09 17
• Internet: www.xoro.de/support.htm
Symptom Check and Action
No disc, load a disc.
Disc has been loaded upside down. Place the disc with the label side up.
English
Disc’s region code does not match to the player.
Disc’s rating level is higher than the player’s rating level setting.
Does not play
Disc is not correct type for the player.
Disc is damaged or power on for one or two hours.
Moisture may be condensed inside the player. Remove the disc and
leave the unit power on for one or two hours.
Check the system connection is proper and secure.
No Picture
Check if the connection cables are damaged.
Clean the disc.
The disc is dirty or damaged. Clean the disc or try another disc.
noise/distorted
Select the screen format from the player’s SETUP MENU.
Picture not full
See “SETUP MENU” of this manual.
screen
Select the screen format from DVD disc menu.
Following message will display when there is a problem with the loaded
disc”
1. “WRONG REGIONAL DISC
”: Disc’s region code is not match to the
Problem
player.
message dis-
2. “WRONG PASSWORD
”: The player refuse to play a disc with rating
play
level higher than the player’s rating level setting.
on screen
3. “WRONG DISC
”: The player is equipped with automatic disc quality
detection software. When the player detects a problem disc or a
damaged disc, the player may keep playing the disc at lower quality
or stop playing, depending on the damage level of the disc.
38

Troubleshooting
Symptom Check and Action
Cannot SKIP
Some discs are programmed that do not allow users to SKIP or
or SEARCH
SEARCH a some sections, especially at the beginning WARNING
section
Single Chapter disc cannot apply SKIP function.
Remote control
Remove the obstacles between the remote control and the player.
des not function
Point the remote control towards the remote sensor on the player.
English
Check if the batteries of the remote control have been loaded with
correct polarities.
Replace the batteries of the remote control.
Macrovision
U.S. Patens Nos. 4,631,603; 4,577,216; 4,819,098; 4,907,093; 5,315,448 and 6,516,132
"This product incorporates copyright protection technology that is protected by U.S. patents
and other intellectual property rights. Use of this copyright protection technology must be
authorized by Macrovision, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohib-
ited."
39
