Xoro HTC 1525D: DVB-T Mode

DVB-T Mode

Favorite List

1. Press the DVB MENU on the remote control to

bring up the main menu on the screen and use

▲ / ▼ to select the Favorite List menu.

2. Press the Enter to confirm your selection and

there have a Favorite List menu on screen as

below:

3. Press ► that you can continue add or delete the

favorite channel.

4. Use the ▲ / ▼ to select add item and then press

Enter to confirm it, there have a Channel list

menu display on the right, you can use ▲ / ▼

English

and Enter to select one of them to your favorite

list.

5. Press DVB MENU to return to previous menu,

then press Enter to TV viewing.

System Settings

Press the DVB MENU on the remote control or on the

front panel to bring up the main menu on the screen and

use ▲ / ▼ to select the System Setting menu. Press the

Enter to confirm your selection and there have a System

Setting menu on screen as below:

Time Setting

Use the ▲ / ▼ to select Time Setting item and then

press Enter to confirm it

Time zone

Press ▲ / ▼ to select Time Zone, then press OK to con-

firm it, you can select the option of GMT+0 --- 8.

Banner Time Setting

This function allows you to set the time of banner dis-

play, you can Press ▲ / ▼ to select banner time options:

1secs/ 3 secs / 5 secs/ 7 secs/ 9 secs.

20

DVB-T Mode

System Settings

Language Setting

Use the ▲ / ▼ to select Language Setting item and then

press Enter to confirm it.

Menu language

This function allows you to set the language of OSD

display, you can Press ▲ / ▼ to select the options: Eng-

English

lish / French / German /Spanish / Italian / Portuguese.

Audio language

This function allows you to set the language of audio, you can Press ▲ / ▼ to select the

options: English / French / German / Spanish / Italian / Portuguese.

Parental Setting

Use the ▲ / ▼ to select Parental Setting item and then press Enter to confirm it If the lock

is already set, enter the pin code as requested.

Chang Pin Code

This function allows you to change the pin code, you

should to input a new pin code twice and press OK to

confirm it.

Censorship

You can Press ▲ / ▼ to select an age bracket options:

None Block/ 6/ 10/ 14/ 18.

A/V Setting

Use the ▲ / ▼ to select A/V Setting item and then

press Enter to confirm it.

TV Shape

This function allows you to select the proper picture

proportion to match the source’s image, you can select

one of 4 : 3 and 16: 9.

Conversion Prefer

This function allows you to select the screen conversion

mode options: Full Frame/ Vertical cut/ Pillar Box or Full

Frame/ Pan & Scan/ Letterbox.

Bright & Contrast

Press the ◄ / ► to adjust the value of bright and con-

trast.

21

DVB-T Mode

System Settings

Saturation

Press the ◄ / ► to adjust the value of saturation.

Factory Setting

Use the ▲ / ▼ to select Factory Setting item and then press Enter to confirm it

Restore Default

Press Enter to enter the restore default menu and

use Enter to do it else use Menu to return to previ-

ous menu.

English

Clear Channels

Press Enter to enter the clear menu and use Enter

to do it else use Menu to return to previous menu.

Country Select

Press Enter to enter the country select menu and

use ▲ / ▼ to select country that one of Default.

Timer List

Use the ▲ / ▼ to select Booking List item and

then press Enter to confirm it. This function allows

you booking the TV program, press Enter to enter

the setting menu

Event ID

Press ► and then use ▲ / ▼ to select event id

options: 1/ 2/ 3/ 4/ 5.

Service

Press Enter and then use ▲ / ▼ to select channel

which you want to book from channel list.

Event type

Press ► and then use ▲ / ▼ to select event type options: ONCE/ DAILY/ WEEKLY.

Start Time

Press the ◄ / ► to select the move cursor and input the number directly to set the begin

time of channel which you have booked.

Start date

Press the ◄ / ►

to select the move cursor and input the number directly to set the begin

date of channel which you have booked.

22

DVB-T Mode

System Settings

Duration

Input the number directly to set the last time of the channel which you have booked.

Status

Press ► and then use ▲ / ▼ to select options: ON/ OFF.

System Info

Use the ▲ / ▼ to select System Info item and then

English

press Enter to confirm it.

Software Version

Use the ▲ / ▼ to select Software Version item and

then press Enter to refer to the version of software.

Hardware Version

Use the ▲ / ▼ to select Hardware Version item and

then press Enter to refer to the version of hardware.

Signal Information

Use the ▲ / ▼ to select Signal Information item and then press Enter to refer to the signal

quality and strength of signal.

EPG

The last submenu in the main menu is EPG.

1. Press the DVB MENU on the remote control or

on the front panel to bring up the main menu on

the screen and use ▲ / ▼ to select the EPG

menu.

2. Press the Enter to confirm your selection and

there have a EPG menu on screen as below.

3. This function let you know the detailed informa-

tion of the channel, that can predict the time of

the program playing.

4. You can book channel by pressing Enter, and

the operation of it is the same as Book setting.

23
