Troubleshooting

Most difficulties in audio systems are the result of

poor or wrong connections, or improper control

settings. If you encounter problems, isolate the

area of the difficulty, check the control settings,

determine the cause of the fault and make the

necessary changes. If you are unable to get

sound from the RMB-1077, refer to the sug-

gestions for the following conditions:

Front Panel Power Indicator Is

Not Lit

No main power to the RMB-1077. Check AC

power connections at the amplifier and the

AC outlet. Check the front panel power switch.

Make sure that it is set to the ON position. If

using 12V trigger power-on, make sure that

a trigger signal is present at rear panel 12V

TRIG IN jack.

No Sound

If the amp is getting AC power, but is producing

no sound, check the PROTECTION INDICATOR

on the front panel. If lit, see below. If not, check

all of your connections and control settings on

associated components. Make sure that your

input connections and speaker connections

match your system configuration.

Protection Indicator Is Lit

The front panel PROTECTION INDICATOR

light when the RMB-1077 protection circuits

have shut off the amplifier. Typically, this oc-

curs only when the amplifier has overheated,

when there is faulty speaker wiring, or after

a period of extreme use. Turn off the system

and wait for the amp to cool. Then push the

front panel power switch in and out to reset

the protection devices. If the problem is not

corrected or reoccurs, there is a problem with

the system or the amplifier itself.

Specifications

Power Configurations

(FTC)

7 x 100 Watts

Watts/Channel

100 watts, all channels driven, with 20KHz filter,

8 ohm load, 20-20 kHz, 0.03% THD

Total Harmonic Distortion

(20Hz-20kHz, 8 ohms)

Continuous Rated Power

< 0.03%

One-Half Rated Power

< 0.03%

One Watt per Channel

< 0.03%

Power Output

 (4 Ohms, 0.09% THD)

200 watts

Intermodulation Distortion

60 Hz:7 kHz, 4:1

< 0.03%

Damping Factor

 (8 ohms)

400

Amp Gain

27.4dB

Input Sensitivity/Impedance

1.2 V / 8.3 k ohms

Frequency Response

10 - 80 KHz (±3dB)

Signal to Noise Ratio (IHF A)

105 dB

Power Requirements

USA

120 Volts, 60 Hz

Europe

230 Volts, 50 Hz

Power Consumption

400 Watts

70 Watts - Idling

3 Watts - Standby

Dimensions

 (W x H x D)

432 x 72 x 415 mm

17

1

/

8

 x 2

7

/

8

 x 16

3

/

8

 in

Panel Height

(for rack mounting)

60 mm, 2

3

/

8

 in

Weight

 (net)

7.8 kg, 17.2 lb.

All specifications are accurate at the time of printing.

Rotel reserves the right to make improvements without notice.
