NAD T 977: REFERENCE

OVERALL SPECIFICATIONS

Continuous output power

into 8 ohms and 4 ohms

≥7 x 140 W (ref. rated THD,

20 Hz – 20 kHz, all channels driven)

Rated THD (250 mW to rated power,

CCIF IMD, DIM 100)

≤0.03 % (ref. 20 Hz - 20 kHz)

Clipping power

≥185 W (ref. 1 kHz, 1% THD)

IHF dynamic power - 8 ohms

230 W

IHF dynamic power - 4 ohms

390 W

IHF dynamic power - 2 ohms

450 W

Damping factor

>300 (ref. 8 ohms, 50 Hz and 1 kHz)

Input sensitivity

1.1 V (ref. rated power)

Voltage gain

29 dB

Signal-to-noise ratio, A- weighted

>96 dB (ref. 1 W)

>125 dB (ref. 140W)

Frequency response

±0.2 dB (ref. 20 Hz - 20 kHz)

-3 dB at 3 Hz and 100 kHz

Time to go to Standby mode at no input

signal

<30 minutes

POWER CONSUMPTION

Rated Power

800 W (120V 60Hz, 230V 50Hz)

Standby power

<0.5 W

Idle power

 <300W

DIMENSION AND WEIGHT

Unit Dimensions (W x H x D)

435 x 194 x 476 mm (Gross)*

17 ¹/₈ x 7 ¹¹/₁₆ x 18 ³/₄ inches

Net Weight

32.3 kg (71.2 lbs)

Shipping Weight

36.5 kg (80.5 lbs)

* - Gross dimensions include feet, front panel button and extended speaker

terminals.

Specifications are subject to change without notice. For updated

documentation and features, please log on to www.NADelectronics.com for

the latest information about T 977.
