Levenhuk 2L NG Microscope: Package

Package

Levenhuk 2L NG

Microscope unit with stage, revolving head for three objectives, focusing mecha-

1 Pc

nism, two illuminations

Monocular nosepiece 1 Pc

Objectives: 4x, 10x and 40x 1 Pc each

Eyepieces: 10x; 16x 1 Pc each

AC adapter 1 Pc

User manual and warranty slip 1 Pc each

Levenhuk D2L NG

In addition to Levenhuk 2L NG: Levenhuk® DEM 135 digital camera:

Digital camera 1 Pc

USB cable 1 Pc

2 adapters for dierent microscopes 1 Pc

SETUP CD MiniSee ScopePhoto (auto setup guide, drivers, software for image

1 Pc

visualization, xation and processing)

Levenhuk 3L NG

In addition to Levenhuk 2L NG: Levenhuk® K50 experiments kit:

Prepared slides 5 Pcs

Clean slides 5 Pcs

Flasks: with pitch, sea salt, yeast, brine shrimp 1 Pc each

Brine shrimp hatchery 1 Pc

Microtome 1 Pc

Forceps 1 Pc

"Attractive microscope. Scrutinizing the microcosm" user guide 1 Pc

Modules description and usage

Focusing mechanism located on the stand allows vertical movement of the stage. The stage is moved by

focusing knob. The total focusing value is at least 15 mm.

Slide holders are xed on the stage surface. Diaphragm disk is attached to the lower part of the stage.

Revolving head holds the objectives; the objectives can be replaced by rotating the ring until it reaches the

xed position.

The objectives included in the package are designed for tube length 160 mm.

Objectives:

Linear magnication Numerical aperture

4 0,1

10 0,25

40 0,65
