Phottix Odin for Sony: The Phottix Odin Receiver
The Phottix Odin Receiver: Phottix Odin for Sony
Using the AF Assist Illuminator
Setting Channels on the receiver
Function
1. The Phottix Odin receiver has 4 channels.
The ash’ s assist lamp will illuminate to aid in
2. Move the Channel Selection Switch to 1, 2, 3,
focusing when the camera shutter button is
or 4 to select a channel.
half-pressed.
3. Ensure the Phottix Odin TCU and receivers
AF Assist Illuminator Functions cannot be set
are set to the same channel.
on the Odin TCU. These functions need to be
set on the camera – consult your camera
Connecting a ash to the Odin
manual for specic menu settings and instruc-
receiver hot shoe
tions.
1. Turn o the ash and the Phottix Odin
Receiver.
The Phottix Odin Receiver
2. Slide the ash into the receiver’ s hot shoe
Setting Groups on the receiver
mount.
1. The Phottix Odin receiver has three group
3. The ash’ s locking mechanism will click
settings.
when engaged, holding the ash in place.
2. Move the Group Selection Switch to A, B or C
4. Turn on the ash and the Phottix Odin
to select a group for each receiver.
receiver.
12
En
INSTRUCTION MANUAL
Connecting the Odin receiver to
studio lights or ashes by cable
1. Turn o the ash/strobe and the Phottix
Odin receiver.
2. Connect a cable to the receiver’ s 3.5 mm
Output Port.
3. Connect the opposite end of the cable to a
ash or studio strobe (A 6.3 mm adapter is
included for studio strobes).
4. Turn on the ash/strobe and the Phottix
Odin receiver.
5. Set the ash to Manual mode – no TTL func-
tions can be used when a compatible ash is
triggered by cable.
13
Technical Specications
Frequency: 2.4 GHz
Distance: 100m+
Channels: 4 channels
Groups: 3 groups – A, B, C
Batteries: 2 x AA batteries (TCU and Receiver), 5V DC on receiver (external power port)
Max sync speed: 1/8000 sec*
Output: Hot shoe, 3.5 mm port (receiver)
Input Port: USB port (transmitter and receiver)
Attachment: 1/4 tripod lug, cold shoe (Receiver)
Input voltage: 2.4-3.2V
Flash port voltage handling: 6V (transmitter) ≤300V(receiver)
Body dimensions: 94(L) x 66(W) x 35(H) mm, (transmitter), 90(L) x 45(W) x 40(H) mm (receiver)
Antenna: built-in PCB antenna
Weight: 94g (transmitter), 63g (receiver) – without batteries
Operating temperature: -15—65℃
Storage temperature: -30—85℃
* On compatible cameras / ashes
14
En
INSTRUCTION MANUAL
Warnings
- This product is a precise electronic instru-
ment. Do not expose to damp environments or
dust.
- Do not drop or crush.
- Do not disassemble.
- Do not use harsh chemical(s) or solvents to
clean the body. Use a soft cloth or lens paper.
- Interference: The Phottix Odin transmits and
receives radio signals at 2.4 GHz. Its perfor-
mance can be aected by electrical current,
magnetic elds, radio signals, wireless routers,
cellular phones, and other electronic devices.
Environmental objects, such as large buildings
or walls, trees, fences, or cars can also aect
performance. If your Phottix Odin receiver will
not trigger, move its location slightly.
15
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
