Levenhuk D2L NG Digital Microscope: English General information

English

General information

The microscope is safe for health, life and property of the consumer and the environment when properly

used; the microscope meets the requirements of international standards. The microscope is designed for

observing transparent objects in the transmitted and reected light using the bright eld method, for

biological use and teaching demonstrations.

Levenhuk DEM 130 digital camera was exclusively designed for use with this microscope. It allows transfer

of the precise image of the observed object to your PC display. ScopePhoto software is included in the

package; it allows viewing and editing of the received images.

Specication

Magnication 64х-640х

Magnication of objective 4x, 10x, 40x

Eyepiece magnication 16х

Linear eld in the images space 18 mm

Tube length 160 mm

Stage dimensions 95х95 mm

Stage moving range 0-15 mm

Power supply AC adapter

Illumination (upper/lower light) LED

Camera model DEM135

MAX resolution (at rest) 640x480

Megapixels 0.3

Sensor 1/4" CMOS

Pixel size 6μm X 6μm

Sensitivity, v/lux-sec @550 nm 2.0

Speed (depends on the PC model) 30 fps

Video recording Yes

Active range 60dB

Location ocular tube (not eyepiece)

Image format BMP, TIFF, JPG, PICT, SFTL etc.

Field of view diameter 18 mm

Spectral range 400-650 nm

Programmable options Image size, brightness, white balance, exposure

control, etc.

Slot USB 2.0, 480 Mb/s

System requirements Windows 2000/XP(SP2)/2003/Vista; USB port

Software USB 2.0 driver, ScopePhoto

Power supply via USB cable

Temperature range -30...70 °C

Legend

1



Eyepiece

2



Monocular nosepiece

3



Revolving head

4



Objectives

5



Focusing knob

6



Stage

7



Lower

illumination

8



Base stand

9



Stand

10



Upper illumination

11



Slide holders

12



Diaphragm disk

13



USB port

14



Digital camera

15



USB cable

16



Adapters

17



Setup CD
