Bebe Confort No touch thermometer: NO TOUCH MEDICAL THERMOMETER

NO TOUCH MEDICAL THERMOMETER

Bébé Confort’s no touch medical thermometer uses the latest technology to pick up infrared rays emitted

by a body so that its temperature can be measured. The benefit of this technology is that you can take a

temperature from a distance, without direct contact, and obtain an instant result. It means you can follow

the progress of a baby or child’s temperature without disturbing them - even when they’re asleep.

However the fact that this thermometer is easy to use, quick and also allows you to take the temperature

of surrounding objects does not mean that you should forget that it is primarily a medical measuring device.

When using it, please ensure you follow the general recommendations and specific precautions detailed

in these instructions.

Please familiarise yourself with these instructions before using the device and keep them in a safe place.

Lastly we would like to remind you that if you are in any doubt about the health of a member of your family

or if someone has a fever, you should consult a doctor quickly.

1 - DESCRIPTION OF THE THERMOMETER AND ITS SCREEN

1/ Liquid crystal display

2/ Start/measure button

3/ Memory button

4/ Operating mode selection button

5/ Fever signal

6/ Sensor

7/ Radar

8/ Battery housing lid

9/ Temperatures measured in degrees

10/ Measurement in progress

11/ Smiling face indicating a temperature below 38°C

12/ Sad face indicating a temperature equal to or above 38°C

13/ Unit of measurement

14/ Forehead mode

15/ Household mode

16/ Low battery signal

17/ Memory and number of recording

2 - INSERTING BATTERIES

1. Gently press the lid of the battery housing outwards to remove it (8).

2. Insert two AAA batteries, taking care to position them correctly and observing the polarity indicated on

the base of the housing.

3. Replace the lid by sliding it into the side slots until it clicks into place.

Batteries and electronic instruments must be disposed of in accordance with local regulations, separate

from household rubbish.

3 - OPERATING MODE SELECTION BUTTON

This thermometer can operate in two modes:

• In medical thermometer mode, the device measures the forehead temperature from a distance. The

screen shows a little head and shoulders figure top centre .

• In household thermometer mode, the device measures the temperature of different elements or objects

in the house, again without direct contact. To go to household thermometer mode, switch the thermometer

on by pressing on the MEASURE

button.

When two zeros appear under the head and shoulders, briefly press the selection

button which makes

a small cube

appear in the top right confirming the mode selected.

Please note: whichever mode is used and after switching it off, the thermometer automatically

reverts to medical thermometer mode.

EN

24

4 - FOREHEAD MEDICAL THERMOMETER MODE

A/ Method

• Briey press and release the MEASURE

button. The

device switches on and initially performs an auto test by

displaying all the screen elements, Figure 1, and then

indicates that is ready by briefly being backlit Figure 2.

• Press the MEASURE button again and hold it down, gently

moving the thermometer towards the temporal area

(preferably) or the centre of the forehead. From the right

Figure 1

Figure 2

distance (around 4 to 8cm) the radar automatically initiates

the measurement.

• When you hear a short beep indicating that the

4-8 cm

measurement has been taken, release the MEASURE

button. The temperature is displayed with backlighting for 3

seconds.

B/ Interpretation by the thermometer

• Temperature below 38°C: a little smiling face

is displayed

at the bottom of the screen (figure 3)

• Temperature equal to or above 38°C: fever signal, 1 long

beep / 2 short beeps and red light signal. Then a sad little face

appears (figure 4)

All the values displayed in forehead thermometer mode are

Figure 3

Figure 4

more or less the same as a rectal temperature.

C/ Switch off

The device automatically switches off after 30 seconds.

D/ Advice and specific precautions

To avoid obtaining an inaccurate measurement, please take the following specific precautions:

• Do not use the forehead thermometer in an environment which is damp, excessively hot or cold, draughty

or overly ventilated.

• Ensure the skin of the forehead is completely dry, clean, bare and not covered in sweat or by hair.

• Always take the temperature in the same place and in the areas recommended.

• Please be aware that a physiological phenomenon called vasoconstriction can happen in the early stages

of a fever. It manifests itself externally by relatively cold skin. This means that any forehead thermometer can

give abnormally low readings.

• Finally if the forehead temperature displayed does not appear to match the baby or child’s state, please

use a classic electronic thermometer. Please note that an increase or reduction in rectal temperature often

lags slightly behind the forehead temperature since the forehead is closer to the hypothalamus which

regulates the body’s temperature.

5 - HOUSEHOLD THERMOMETER MODE

A/ Method

• Switch on the thermometer by pressing the MEASURE

button

once

.

• Briey press the selection

button when two zeros appear and ensure

4-8 cm

that you are in object mode confirmed by the little cube at the top

right of the screen.

• Press the MEASURE button and without releasing it, point the

thermometer towards the object from a distance of 4 to 8cm.

• Then release the MEASURE button. A brief beep signals that the temperature has been taken which is

backlit for 3 seconds.

B/ Advice and specific precautions

• The surface temperature can be very different from the temperature in the centre of the bottle, bath or

soup. To avoid any problems, ensure all liquids are stirred thoroughly before being measured.

• For the examples given, take the temperature as quickly as possible to avoid condensation forming on the

sensor or radar. Then wait around 30 minutes before using it again.

25
