We are very pleased that you decided to purchase
Description
this product from SWAROVSKI OPTIK. If you have
Z5/Z3
any questions, please consult your specialist dealer
or contact us directly at WWW.SWAROVSKIOPTIK.COM.
7
3
2
1
1 Dioptric correction
2 Magnification adjustment ring
9
3 Screw-on cap
4 Elevation adjustment turret
4.1. Zero point adjustment
5 Windage adjustment turret
8
5.1. Zero point adjustment
6 Knurled knob
7 Parallax turret (depending on model)
8 Protective cap
9 Coin opener (depending on model)
Elevation and windage adjustment
4.1
4
6
SWAROVSKI OPTIK patents USA:
• Erectorsystemadjustingdevice:
US 5,463,495
• Reticleadjustingsystem:
US 5,513,440
• Zoomsystem:
US 2007/0019289, patent pending
• BallisticTurret:
US 2008/0289239, patent pending
5.1
5
Please find our current product accessories at WWW.SWAROVSKIOPTIK.COM.
