Bebe Confort Natural Comfort Electric Breast Pump: Please read the instructions in full before using the breast pump.

16

NATURAL COMFORT ELECTRIC BREAST PUMP

1- Safety information

Please read the instructions in full before using the breast pump.

When using electrical equipment it is important to comply with safety precautions including those set out below.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical sensory

or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall not be made by children without supervision.

• If the power supply cable is damaged, it must be replaced by a special cable or assembly available from the

manufacturer or its service agent.

Additional recommendations:

• The appliance is only to be used with the power supply unit provided with the appliance.

• Begin by plugging the power cord into the Natural Comfort breast pump, then attach it to the USB power supply.

• Always unplug the device immediately after use.

• The breast pump must be used in a vertical position.

• Never pick up an electrical appliance which has fallen into water. Unplug it immediately.

• Keep the device dry and protect it from direct sunlight.

• Only use genuine Bébé Confort accessories.

• Check the various parts of the breast pump for signs of wear or damage.

• The shield and tube are for personal use only. For hygiene reasons they must never be used by another person.

PRECAUTIONS RELATING TO BATTERIES:

• Use only alkaline or rechargeable (NiMH) batteries.

• DO NOT charge non-rechargeable batteries.

• Do not mix different types of battery and do not mix old and new batteries.

• When inserting the batteries, ensure the polarity is correct.

• Remove discharged or dead batteries from the device, remove the batteries if the device is to remain out of use for an extended period of time.

• Do not short circuit the battery terminals.

• Ensure all contact surfaces are clean before inserting the batteries.

2- Presentation of the breast pump (see appendix I)

A. Breast pump J. Flexible internal shield S. Container for sterilisation

B. Lid K. Charger T. Replacement parts kit

C. Bottle ring L. Power cable U. Transport bag

D. White o-ring M. Nozzle

E. Transparent diaphragm N. Teat + Bottle ring 1. On/Off button

F. One-way valve O. Bottle cover 2. Rinsing button

G. 140ml Natural Comfort bottle P. Sealing disk 3. Stimulation button

H. Tube Q. Top for sterilisation 4. Suction buttons (x4)

I. Rigid external shield R. Lid for sterilisation

3- Cleaning and sterilising

Before use : cleaning.

See the cleaning chart in appendix II.

After use : rinsing and sterilising the tube and nozzle.

See appendix V and VI.

1. Store away the milk you have collected, ensuring you follow the instructions given below.

2. Place an empty bottle (G) assembled with (B + C + D + E + F) in the breast pump.

3. Separate the tube (H) and nozzle (M) from the shield (I + J).

4. Place the free end of the tube (H) in a container of cold water (At least 150ml of drinking water).

5. Press the rinse button (2) on the breast pump (cycle lasts around 30 seconds).

6. Once the automatic rinse cycle is complete, remove the tube (H) and separate all the parts of the breast pump.

7. Throw away the rinse water which has collected in the bottle.

17

NB: The automatic rinse cycle built into the product guarantees the tube is clean and can be reused in total safety within seven hours.

The rinse must be carried out soon after using the device, within a maximum of two hours, to ensure the milk does not dry in the tube.

If seven hours have passed since the tube was last rinsed, we recommend you sterilise it.

To sterilise the tube (H) and the nozzle (M) in a microwave, use the accessories provided and follow the instructions in appendix V:

1. Plug the flexible end of the tube (H) into the reservoir (S) and wrap the tube around it. Check that there are no kinks in the tube!

2. Fill the reservoir (S) with water up to the line inside (1cm from the top).

3. Screw on the lid (R), blocking the tube (H) and nozzle (M) into the notch.

4. Clip the top (Q) over the lid (R).

5. Place in the microwave (top facing up) for the relevant time as shown below:

Power in Watts 900 700 550

Time 6 mins 7 mins 8 mins

Alternatively, you can sterilise the tube (H) and nozzle (M) in boiling water or by using cold water sterilising tablets.

1. In both cases, please ensure no air bubbles remain in the tube (H).

Cleaning other parts of the breast pump, see the appendix II.

The breast pump (A) and cover (B) should be cleaned with a damp cloth. Do not use solvents or alcohol.

4- Assembling the pump before use (see appendix III)

Wash your hands thoroughly before starting to assemble your breast pump.

1. Assemble the lid. Press down firmly on Lid (B) + Transparent diaphragme (E) + Bottle ring (C ) + One-way valve (F).

2. Check that all parts are properly assembled!

3. Connect the lid (B) to the rest of the device (A).

4. Plug in your breast pump:

• Using power cable (K + L) OR

• By connecting it to a USB power source (L) OR

• Using four AA alkaline or rechargeable batteries with a minimum capacity of 1800mAh.

18

NB: If the breast-pump is pluged-in correctly (power, usb, batteries), all buttons will be lighted for 0.5 seconds. The breast pump does not

charge rechargeable batteries when it is plugged into the mains. Mains power automatically overrides battery power when the device is

connected to the mains. There is no need to remove the batteries. Minimum battery life is 3 hours with new batteries.

5. Assemble the shields with the tube and nozzle (cf photos).

5- How your breast pump works (see appendix IV)

1. Place the shield (I + J) on the breast around the nipple so that it forms a perfect seal, preventing air from entering.

2. Put your bra over the shield (I + J). You can pass the tube under your clothes and out at the bottom of the garment (photo 2a) or the collar

(photo 2b), ensuring the tube is not kinked or squashed at any point.

3. Ensure the device is vertical, straight and lower than your breast.

4. Connect the tube (H + M) to the bottle ring (C). The tube (H) is very flexible, which can make it difficult to fit.

5. Ensure it is pushed in properly before turning the breast pump on.

6. Press the On button (1). The stimulation button (3) will light up automatically. It is programmed to last 2 minutes.

NB: The stimulation mode mimics the rapid sucking movements your baby makes at the beginning of a feed to let down the milk.

7. After 2 minutes, the breast pump automatically switches to suction mode, on the lowest setting.

NB: The expression mode mimics the deeper, slower sucking movements your baby makes once the milk starts to flow. You can choose to

switch to suction mode before the two minutes are up by pressing the level 1 button.

8. If you wish to use a higher suction mode, press level 2 and so on. The higher the suction the quicker your milk will be expressed. Try out

the various levels of suction to work out which one is the most efficient and comfortable for you.

9. Once you have found the level of suction that works for you, you can move straight from stimulation mode to your chosen level of

suction (without working through the levels in between).

10. Once you have finished expressing your milk, press the On/Off button (1) to switch off the device. Remove the shield (I + J), place it on

the other breast and repeat the steps above. You may find the second breast needs less stimulation time.

NB: The device turns off automatically once it has been in use for 30 minutes. Always keep an eye on the bottle to avoid overflow.

The breast pump includes 1 Bébé Confort bottle Natural Comfort 140 ml. Other Bébé Confort bottles can be used: plastic Natural

Comfort 240 ml, glass Natural Comfort 130 ml and plastic Maternity 140 ml sold separately.

19

6- Storing your milk

Pour the milk into a clean container which you can seal and date, such as a Bébé Confort storage pot or bag. You can also use a bottle (G) as a

storage container by closing it with a Bébé Confort sealing disk (P).

For milk storage times, refer to the table below.

Storage time at room

Storage time in a refrigerator Storage time in a freezer

Storage time in a freezer

temperature (20°C)

compartment

Freshly expressed milk 6-10h 3-4 days at 4°C 2 weeks at -16°C Around 6 months at-18°C

Defrosted milk 1h 10h at +4°C Do not refreeze once

Do not refreeze once

defrosted

defrosted

When you are ready to use the milk, remove it from the refrigerator or freezer. Defrost the milk in the refrigerator for a few hours, then at room

temperature. You can warm it up if you wish. Roll the bottle between your hands to ensure the temperature is uniform.

Only store milk expressed with a sterilised breast pump for your baby.

NEVER refreeze breast milk once it has been thawed.

Never add freshly expressed milk to frozen milk.

Always throw away any milk your baby leaves at the end of a feed.

Do not keep the milk in the door of the refrigerator (the temperature there is higher than in the rest of the refrigerator).

Do not mix formula milk with breast milk.

7- Instructions for use

You may be new to using a breast pump. It is normal to find it a little difficult to start with. Your Bébé Confort breast pump has been designed

to be easy to use; it will soon become second nature.

The shield was designed to be used under a bra.

Everyone is different and it is up to you to choose the best time for expressing your milk. You may find the best times are:

• When you wake up and your breasts are full, just before or after the first feed of the day.

• After a feed if your baby has not emptied your breasts completely.

• When you feel your breasts are swollen.

20

Tips:

 Express your milk at a time that suits you. Make sure you feel relaxed and not rushed, and are not likely to be

interrupted;

 You can encourage the let-down reflex by looking at a photo of your baby and/or by applying a warm compress

!

!

to your breast;

 Try different positions to see how you feel most comfortable;

 Relaxation and warmth can help. Try expressing your milk after a warm bath or shower.

Do not use the device while sleeping or if you are very tired. If you have any problems or experience pain, speak to your doctor.

8- Guarantee

The device, with the exception of the shields, tube and nozzle, is guaranteed for two years from the date of purchase, on production of the

receipt. The manufacturer is unable to take responsibility for damage or injury caused by incorrect use, dropping the device, inappropriate

use or use by an unauthorised person. Your Natural Comfort breast pump does not contain any user serviceable parts. Do not attempt to

repair it yourself. It is essential that you keep your proof of purchase in order for the warranty to remain valid.

9- Ecodesign

This breast pump has been ecodesigned. Bébé Confort is committed to respecting the environment. To reduce the ecological footprint of

the breast pump during and after use, we recommend you follow the guidelines below:

• Use the power cable wherever possible.

• Use rechargeable batteries rather than alkaline batteries. Do not use more water than necessary when cleaning the tubes.

• Unplug the charger after use, otherwise it will continue to use energy.

NB: In the event of loan, gift or resale, it is essential to provide the packaging and instructions. For reasons of hygiene, the soft shield and tube

must be used only by the same person. These accessories can be bought separately in specialist shops.

At the end of its useful life, the breast pump should be disposed of with electrical, electronic and electrical appliance waste. Follow the

instructions provided by local authorities for recycling the batteries. This device contains various metal and plastic components. Before

disposing of the device, ensure it can no longer be used and that it can be destroyed or recycled in accordance with current local guidelines.

Use your local scrap electrical and electronic equipment collection system. If disposed of incorrectly, this device can be a danger to the

environment and public health.

21

10- Troubleshooting

The motor does not function Check that:

• The USB cable and power cable are plugged in correctly. The buttons should illuminate briefly while plugging in the

power source. If it doesnt happen, try another power source.

• If the breast pump is on, push the button (1) Appendix I.

• If you are using battery power check that the batteries have been fitted correctly or have not run down (a red light

shows continuously for 20 seconds).

There is no suction or the suction is too

• Ensure that the sheild (I + J) is sealed on the breast perfectly and all parts of the breast pump have been assembled

weak.

correctly. The transparent diaphragm (E) is in position between the cover (B) and the bottle ring (C+D). See Annexe III.

• Check that the tube (H) is connected to the shield (I+J), the bottle ring (C) and the white o-ring (D) has been placed

on the bottle ring (B).

• The lid (B) and the bottle ring (C) should be firmly assembled and check that there is no sign of wear or damage.

• Re-start the appliance then press the lid (B). You are in the sittinf position.

The device loses power while running on

Check that:

batteries.

• Whether the red light is flashing as you express your milk. This indicates that you will need to replace the batteries or

recharge them before using the device again. Always keep new or recharged batteries near you.

Breast pain when expressing milk. • Use a lower level of suction. If the pain persists, speak to a breastfeeding adviser.

• Try different positions for shield (I + J).

• You can use a Bébé Confort plastic nipple to decrease the pressure on the nipple.

Little or no milk is produced. • Position the breast pump lower than your breast.

• Depending on the breast, the nipple could block the milk evacuation in the shield: if it happens, pause for several

minutes before recommencing.

• Follow the instructions for use, speak to a breastfeeding advisor if the problem persists.

Take care not to squash or kink the tube.

NB: A replacement parts kit (T) is supplied with the breast pump. The kit includes: a one-way valve (F) and two O-rings (D). We recommend

you replace the flexible internal shield, the tube and the nozzle as soon as you see any signs of wear (cracking, tears, etc.). Replacements are

available from your retailer. You should replace the tube after 6 weeks of use.

If you are unable to resolve a problem with the breast pump using the advice above, please phone the customer service department or email

us by going to the www.bebeconfort.com website, and clicking "Our Services" followed by "Contact us".

Bébé Confort has produced a breastfeeding guide packed with information and tips. It can be downloaded from www.bebeconfort.com.

22
