Sharp KC-A40EU W: instruction

R

AIR PURIFIER

KC-A60EU

with Humidifying Function

ENGLISH

OPERATION MANUAL

KC-A50EU

LUFTREINIGER

mit Luftbefeuchtungsfunktion

KC-A40EU

BEDIENUNGSANLEITUNG

DEUTSCH

Purifi cateur d’air avec fonction

d’humidifi cation

MANUEL D’UTILISATION

FRANÇAIS

LUCHTREINIGER

met bevochtigingsfunctie

BEDIENINGSHANDLEIDING

NEDERLANDS

Device of this mark is a trademark

of Sharp Corporation.

OCZYSZCZASZ POWIETRZA

Plasmacluster is a registered trademark

or a trademark of Sharp Corporation.

z funkcją Nawilżania

POLSKI

INSTRUKCJA OBSŁUGI

PURIFICADOR DE AR

com Função Humidifi cadora

MANUAL DE INSTRUÇÕES

PORTUGUÊS

Воздухоочиститель с

функцией увлажнения

РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ

РУССКИЙ

Ылғалдандыру функциясы

бар АУА ТАЗАРТҚЫШ

Free standing type

ПАЙДАЛАНУ НҰСҚАУЛЫҒЫ

ҚАЗАҚША

Freistehendes Modell

Modèle sur pied

* The number in this technology mark indicates an

approximate number of ions supplied into air of 1 cm

3

,

Vrijstaand type

which is measured around the center of a room with

Typ wolnostojący

the “high-density plasmacluster 7000” applicable floor

Tipo autónomo

area (at 1.2 m height above the floor) at the medium

Напольный очиститель воздуха

wind volume in humidifying & air purifying mode, or in

Жеке дара тұратын түрі

air purifying mode, when a humidifi er/air purifi er or an

air purifier using the high-density plasmacluster ion

evolving device is placed close to a wall. This product is

equipped with a device corresponding to this capacity.

SHARP CORPORATION

Printed in China

OSAKA, JAPAN

TINS-A610KKRZ 12K- CN 1

OM_KC-A60EU_EN.indd 1OM_KC-A60EU_EN.indd 1 12/4/12 9:42 AM12/4/12 9:42 AM

Please read before operating your new Air Purifi er

The air purifi er draws in room air from the air intake, passes the air through a Pre-

Filter, a Washable Deodorizing Filter and a HEPA Filter inside of the unit, then

discharges the air through the air outlet. The HEPA Filter can remove 99.97% of dust

particles as small as 0.3 microns that pass through the fi lter and also helps absorb

odours.

The Washable Deodorizing Filter gradually absorbs odours as they pass through the

fi lter.

Some odours absorbed by the fi lters may break down over time, resulting in additional

odour. Depending on the usage environment, especially when the product is used in

extreme environments (significantly more severe than normal household use), this

odour may become strong in a shorter period than expected. If the odour persists, the

fi lters should be replaced.

NOTE

• The air purifi er is designed to remove air-suspended dust and odour, but not harmful gases (for

example, carbon monoxide contained in cigarette smoke). If the source of the odour still exists, the

air purifi er may not completely remove the odour.

HEPA Filter

Deodorizing Filter

Pre-Filter

(Common illustration has used “KC-A60EU”.)

OM_KC-A60EU_EN.indd 2OM_KC-A60EU_EN.indd 2 12/4/12 9:42 AM12/4/12 9:42 AM

ENGLISH

FEATURES

CONTENTS

Unique Combination of Air Treatment

Technologies

IMPORTANT SAFETY INSTRUCTIONS

...

E-2

Triple Filtration System + Plasmacluster

• WARNING

+ Humidifi cation

• CAUTIONS CONCERNING OPERATION

ENGLISH

TRAPS DUST*

• INSTALLATION GUIDELINES

Washable pre-filter traps dust and other

• FILTER GUIDELINES

large airborne particles.

PART NAMES

.............................................

E-4

DECREASES ODOURS

Washable deodorizing fi lter absorbs many

• FRONT / BACK

common household odours.

• MAIN UNIT DISPLAY

REDUCES POLLEN & MOLD*

• ILLUSTRATIVE DIAGRAM

HEPA filter traps 99.97% of particles as

PREPARATION .............................................

E-6

small as 0.3 microns.

• FILTER INSTALLATION

FRESHENS

• REFILLING THE WATER TANK

Plasmacluster treats the air similar to the

way nature cleans the environment by

OPERATION

...............................................

E-8

emitting a balance of positive and negative

• CLEAN AIR & HUMIDIFY

ions.

• CLEAN AIR

HUMIDIFIES

• CLEAN ION SHOWER

Runs up to 10 hours per fi lling.**

• FAN SPEED

*When air is drawn through the filter

• PLASMACLUSTER ION ON/OFF

system.

USEFUL FUNCTION

...............................

E-10

**Room size:

2

• LIGHTS CONTROL

up to 48 m

(KC-A60EU)

2

up to 38 m

(KC-A50EU)

• CHILD LOCK

2

up to 26 m

(KC-A40EU)

• SOUND INDICATOR SETTING

• ADJUSTMENT OF SENSOR

Sensor Technology continuously monitors

air quality, and automatically adjusting

DETECTION SENSITIVITY

operation based on detected air purity and

CARE AND MAINTENANCE

.................

E-11

humidity.

• FILTER INDICATOR

• CARE INDEX

• HUMIDIFYING DISINSTALLATION

• WATER TANK

• HUMIDIFYING FILTER

• HUMIDIFYING TRAY AND COVER

• BACK PANEL

• DEODORIZING FILTER

• UNIT

• FILTER REPLACEMENT

TROUBLESHOOTING

............................

E-16

SPECIFICATIONS

....................................

E-19

Thank you for purchasing this SHARP Air

Purifier. Please read this manual carefully

before using the air purifi er.

After reading, keep the manual in a

convenient location for future reference.

E-1

OM_KC-A60EU_EN.indd Sec1:1OM_KC-A60EU_EN.indd Sec1:1 12/4/12 9:42 AM12/4/12 9:42 AM

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should be followed, including the

following:

WARNING

– To reduce the risk of electrical shock, fi re or injury to persons:

• Read all instructions before using the unit.

• Use only a 220~240 volt outlet.

• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet

is loosened.

• Periodically remove dust from the plug.

• Do not insert fi ngers or foreign objects into the air intake or air outlet.

• When removing the power plug, always hold the plug and never pull on the cord.

Electrical shock and/or fi re from a short circuit may result.

• Be careful not to damage the power cord, it may cause electric shock, excess heat or fi res.

• Do not remove the plug when your hands are wet.

• Do not use this unit near gas appliances or fi replaces.

• When refi lling the Water Tank, cleaning the unit, or when the unit is not in use, be sure to unplug

the unit. Electrical shock and/or fi re from a short circuit may result.

• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a

Sharp authorized Service Centre or similarly qualifi ed person in order to avoid a hazard.

• Only a Sharp Authorized Service Centre should service this air purifi er. Contact the nearest Service

Centre for any problems, adjustments, or repairs.

• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,

sparks from lit cigarettes, chemical fumes in the air, or in locations where the unit may get wet,

such as a bathroom.

• Be cautious when cleaning the unit. Strong corrosive cleansers may damage the exterior.

• When carrying the unit, remove the Water Tank and Humidifying Tray fi rst and hold the unit by

handles on both sides.

• Do not drink the water in the Humidifying Tray or Water Tank.

• Change the water in the Water Tank daily with fresh tap water and regularly clean the Water Tank

and Humidifying Tray. (See E-12 and E-13). When unit is not in use, dispose of the water in the

Water Tank and Humidifying Tray. Leaving water in the Water Tank and/or Humidifying Tray may

result in mold, bacteria, and bad odours.

In rare cases, this bacteria may cause harmful physical effects.

• This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure they do not play with the appliance.

NOTE

– Radio or TV Interference

If this air purifier should cause interference to radio or television reception, try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation distance between the unit and radio/TV receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

E-2

OM_KC-A60EU_EN.indd Sec1:2OM_KC-A60EU_EN.indd Sec1:2 12/4/12 9:42 AM12/4/12 9:42 AM

CAUTIONS CONCERNING OPERATION

• Do not block the intake and/or air outlet.

• Do not use the unit near or on hot objects, such as stoves or heaters, or where it may come into

contact with steam.

• Always operate the unit in an upright position.

ENGLISH

• Hold the unit by using the handles on both sides when moving.

Do not move when the unit is in operation.

• Do not move or change the direction of the main unit while dragging the casters.

• Lift it up and move such as a tatami mat, a fl oor which gets damaged easily, an uneven place, and

thick-poled carpet.

• When moving by the caster, move it in a horizontal direction.

• Turn the appliance off and remove the water tank before moving, take care not to catch your

fi ngers.

• Do not operate the unit without the filters, Water Tank, and Humidifying Tray properly

installed.

• Do not wash and reuse the HEPA fi lter.

Not only does it not improve fi lter performance, it may cause electric shock or malfunction.

• Clean the exterior with a soft cloth only.

Do not use volatile fl uids and/or detergents.

The unit surface may be damaged or cracked.

In addition, the sensors may malfunction as a result.

• Frequency of maintenance required (descaling) will depend on the hardness or the

impurities of the water that you use; the harder the water the more often descaling will be

necessary.

• Keep the unit away from water.

INSTALLATION GUIDELINES

• When using the unit, place at least 2m away from equipment utilizing electric waves such

as televisions or radios to avoid electrical interference.

• Avoid a location where the sensor is exposed to direct wind.

The unit may not operate properly.

• Avoid use in locations where furniture, fabrics or other items may come in contact with and

restrict the air intake and/or air outlet.

• Avoid use in locations where the unit is exposed to condensation or drastic temperature

changes. Appropriate conditions are when room temperature is between 5 – 35 ºC.

• Place on a stable surface with suffi cient air circulation.

When placing the unit on a heavily carpeted area, the unit may vibrate slightly.

Place the unit on an even surface to avoid water leakage from the Water Tank and/or Humidifying

Tray.

• Avoid locations where grease or oily smoke is generated.

The unit surface may crack or the sensor may malfunction as a result.

• Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper airfl ow.

The wall directly behind the air outlet may become dirty over time. When using the unit for an

extended period of time in the same location, periodically clean the wall and protect the wall with a

vinyl sheet, etc. to prevent the wall from becoming dirty.

FILTER GUIDELINES

• Follow the instructions in this manual for correct care and maintenance of the fi lters.

E-3

OM_KC-A60EU_EN.indd Sec1:3OM_KC-A60EU_EN.indd Sec1:3 12/4/12 9:42 AM12/4/12 9:42 AM

PART NAMES

FRONT / BACK

1

1 Main Unit Display

(Ref.E-5)

2

2

Front Monitor

3

Main Unit

3

1

9

2

3

10

4

11

5

12

6

7

13

8

(Shape of plug depends on country.)

1 Air Outlet 6 Float

2 Handle

(2 Locations)

7 Humidifying Tray

3 Sensor

(Internal)

8 Caster

(4 Locations)

•Dust Sensor

9 HEPA Filter

(white)

•Temperture / Humidity Sensor

10 Deodorizing Filter

(black)

•Odour Sensor

11 Back Panel

(Pre-Filter)

(KC-A60EU•KC-A50EU ONLY)

12 Air Inlet

4 Water Tank 13 Power Cord / Plug

5 Humidifying Filter

INCLUDED

• Operation manual

• Slipper

×4

E-4

OM_KC-A60EU_EN.indd Sec1:4OM_KC-A60EU_EN.indd Sec1:4 12/4/12 9:42 AM12/4/12 9:42 AM

MAIN UNIT DISPLAY

2

3

1

678

ENGLISH

4

5

a

b

c

1 POWER ON Button

a CLEAN AIR MODE Button / INDICATOR LIGHT

(green)

b CLEAN AIR & HUMIDIFY MODE Button / INDICATOR LIGHT

(green)

c CLEAN ION SHOWER MODE Button / INDICATOR LIGHT

(green)

2 LIGHT CONTROL Button 5 CHILD-LOCK Button /

INDICATOR LIGHT

(green)

3 Plasmacluster Ion ON / OFF Button /

6 Plasmacluster Sign

INDICATOR LIGHT

(green)

4 FILTER RESET Button /

7 FAN SPEED Button /

INDICATOR LIGHT

(red)

INDICATOR LIGHT

(green)

8 POWER OFF Button

ILLUSTRATIVE DIAGRAM

Humidity Monitor

Odour Monitor*

Indicates approximate humidity level

Indicates the odour intensity of the

in the room.

room in 3 stages colours.

Humidity setting cannot be adjusted.

green

red

Faint Strong

* KC-A60EU, KC-A50EU ONLY

Dust Monitor

Indicates the air purity of the room

Humididify Light

in 5 stages colours.

Clean

green

green

Humidity ON

off

Humidity OFF

red

need to supply water

(Flash

ing)

Impure

red

E-5

OM_KC-A60EU_EN.indd Sec1:5OM_KC-A60EU_EN.indd Sec1:5 12/4/12 9:42 AM12/4/12 9:42 AM

Be sure to remove the power

PREPARATION

plug from the wall outlet.

FILTER INSTALLATION

Remove the Back Panel.

1

1

2

HEPA fi lter (White)

Deodorizing fi lter (Black)

Remove the Filters from the

2

plastic bag.

Install the Filters in the correct

3

order as shown.

Deodorizing fi lter (Black)

HEPA fi lter (White)

Click

Install the Back Panel.

4

Fill in the usage start date on the

5

Date Label.

E-6

OM_KC-A60EU_EN.indd Sec1:6OM_KC-A60EU_EN.indd Sec1:6 12/4/12 9:42 AM12/4/12 9:42 AM

REFILLING THE WATER TANK

When using the Clean Air & Humidify Mode, or the Clean ION Shower Mode.

2

Remove the Water Tank.

3

ENGLISH

1

1

Fill the Water Tank with tap Water.

2

MAX

CAUTION

•

Check to see that there is no water leaking.

• Be sure to wipe off any excess water on

the outside of the Water Tank.

• When carrying the Water Tank, hold it

with both hands so that the Water Tank

Tighten

opening is facing up.

Install the Water Tank.

3

2

Click

1

CAUTION

• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.

• Do not use hot water (40 ºC), chemical agents, aromatic substances, dirty water, or other

damaging substances, deformation and/or malfunction may occur.

• Use only fresh tap water. Use of other water sources may promote the growth of mold, fungus and/

or bacteria.

E-7

OM_KC-A60EU_EN.indd Sec1:7OM_KC-A60EU_EN.indd Sec1:7 12/4/12 9:42 AM12/4/12 9:42 AM

CARE AND MAINTENANCECARE AND MAINTENANCE

DEODORIZIING FILTER

HAND WASH ONLY!

DO NOT DRY IN CLOTHES DRYER!

Remove the dust on the DEODORIZING FILTER.

1

Rinse the DEODORIZING FILTER with water.

2

CAUTION

• When washing the filter for the first time, the rinse water may

be brown.

This does not affect deodorization performance.

• Avoid bending or folding the filter when washing.

Remove as much of the moisture as possible.

3

Dry fi lter completely in a well ventilated area.

4

When possible, dry outdoors.

(about 6 hours to dry out)

CAUTION

• Avoid drying filter outdoors during inclement weather (e.g.

rain or cold temperatures).

• Do not allow filter to freeze.

•

If filter is dri

e

d indoors, take precautions, such as placing

towels, etc under the filter to prevent water damage to the floor.

Wipe with a dry, soft cloth.

UNIT

CAUTION

•

Do not use volatile fl uids

Benzine paint thinner, polish powder, may damage the

surface.

•

Do not use detergents

Detergent ingredients may damage the unit.

E-14

OM_KC-A60EU_EN.indd Sec1:14OM_KC-A60EU_EN.indd Sec1:14 12/4/12 9:42 AM12/4/12 9:42 AM

FILTER REPLACEMENT

Replacement timing

Filter life will vary depending on the room environment, usage, and location of the unit. If dust or

odour persists, replace the fi lter.

(Refer to “Please read before operating your new Air Purifi er”)

ENGLISH

The following filter life and replacement period is based on the condition of smoking 5 cigarettes per

day and the dust collection/deodorization power is reduced by half compared wirh that of new fi lter.

We recommend to replace the filter more frequently if the product is used in a condition significantly

severer than normal household use.

•HEPA fi lter About 10 years after opening

•Deodorizing fi lter* About 10 years after opening

•Humidifying fi lter About 10 years after opening

* Washable deodorizing fi lter can be repeatedly used after washing,

or it can be replaced.

Replacement Filter Model

Humidifying Filter

Please consult your dealer for purchase of replacement filter.

Filter Frame (white)

REPLACEMENT FILTER MODEL

HEPA Filter :

Deodorizing

Humidifying

AIR PURIFIER MODEL

1 unit

Filter : 1 unit

Filter : 1unit

KC-A40EU FZ-A41HFR FZ-A41DFR

FZ-A61MFRKC-A50EU FZ-A51HFR FZ-A51DFR

KC-A60EU FZ-A61HFR FZ-A61DFR

NOTE

Use the date label as a reminder for next replacement.

Filter Frame (gray)

Disposal of Filters

Please dispose of used filters according to any local laws and

regulations.

HEPA Filter material :

• Filter : Polypropylene

• Frame: Polyester

Deodorizing Filter material :

• Deodorizer : Activates charcoal

• Filter : Polyester, Rayon

Humidifying Filter material :

• Filter : Rayon, Polyester

HEPA fi lter

Deodorizing fi lter

E-15

OM_KC-A60EU_EN.indd Sec1:15OM_KC-A60EU_EN.indd Sec1:15 12/4/12 9:42 AM12/4/12 9:42 AM

TROUBLESHOOTING

Before calling for service, please review the Troubleshooting chart below, since the problem may not

be a unit malfunction.

SYMPTOM REMEDY (not a malfunction)

Odours and smoke are not

• Clean or replace the fi lters if they appear to be heavily soiled.

removed.

(Ref. E-11,E-12,E-14)

The Front Monitor illuminates

• The air could be impure at the time the unit was plugged in.

green even when the air is

Unplug the unit, wait one minute, and plug the unit in again.

impure.

The Front Monitor illuminates

• Sensor operation is affected if the dust sensor openings are

orange or red even when the air

dirty or clogged. Gently clean the dust sensors. (Ref. E-4).

is clean.

A clicking or ticking sound is

• Clicking or ticking sounds may be audible when the unit is

heard from the unit.

generating ions.

The discharged air has an

• Check to see if the fi lters are heavily soiled.

odour.

• Clean or replace the fi lters.

• Plasmacluster Air Purifi ers emit small traces of ozone which

may produce an odour.

The unit does not operate when

• Is the unit installed in a location that is diffi cult for the sensor to

cigarette smoke is in the air.

detect cigarette smoke?

• Are the dust sensor openings blocked or clogged?

(In this case, clean the openings.) (Ref. E-4)

Filter Indicator Light is

• After replacing fi lters, connect the power cord to an outlet and

illuminated.

press the Filter Reset Button. (Ref. E-11)

The Front Monitor are turned off.

• Check to see if the Lights OFF Mode selected. If so, then press

the Lights Control Button to activate the indicator lights.

(Ref. E-10)

The Water Supply Indicator

• Check Styrofoam fl oat for impurities. Clean the HumidifyingTray.

Light does not illuminate when

Ensure unit is located on a level surface.

the tank is empty.

Water lever in the tank does not

• Check to see if the Humidifying Tray and Water Tank are

decrease or decreases slowly.

correctly installed. Check the Humidifying Filter.

• Clean or replace the fi lter when it is heavily soiled.

(Ref. E-14 and E-15).

The Front Monitor lights change

• The Front Monitor lights automatically change colours as

colour frequently.

impurities are detected by the dust sensor and odour sensor.

E-16

OM_KC-A60EU_EN.indd Sec1:16OM_KC-A60EU_EN.indd Sec1:16 12/4/12 9:42 AM12/4/12 9:42 AM

SYMPTOM REMEDY (not a malfunction)

When the Roller / Float was removed.

• Install the Roller / Float in order below.

FLOAT

ROLLER

ENGLISH

Fix the roller in the tray from side way.

1. Insert the fl oat under

Float

this tab.

2. Inner the tab

of fl oat into

the hole.

Tab

NOTE

Check the direction

Float

3. Insert the tab on the other

of the roller.

side of the fl oat into the

hole.

Cross-Section view

AUTO RESTART

After a power failure, automatically resume

Auto Restart can be set.

the operation when the power recovers.

• Even when the plug is unplugged or the breaker is

thrown during the operation, the operation resumes

at the previous operation mode and settings if the

power recovers.

ON

CANCELLATION

(with the unit OFF)

(with the unit OFF)

(simultaneously for more 3 sec.)

(simultaneously for more 3 sec.)

If the , , lamp lights up

for 10 seconds, the setting is

complete.

E-17

OM_KC-A60EU_EN.indd Sec1:17OM_KC-A60EU_EN.indd Sec1:17 12/4/12 9:42 AM12/4/12 9:42 AM

TROUBLESHOOTING

ERROR DISPLAY

If error occurs again, contact the Sharp Service Centre.

DIGITAL

LAMP INDICATION ERROR DETAILS REMEDY

INDICATION

Flashing of the Clean Air &

Abnormal humidity fi lter. Verify if the Humidifying

Humidify Indicator Light.

Filter, Humidifying Tray and

Water Tank are properly

installed and then turn

power ON again.

Flashing of the Fan Speed

Abnormal fan motor.

Turn power OFF to cancel

Indicator Light '

'.

the error display, wait one

minute, and then turn power

ON.

- Abnormal temperature-

Unplug the unit, wait one

humidity sensor.

minute, and plug the unit in

again.

-

Flashing of the Clean Ion

Problem in circuit board.

Shower Indicator Light.

Flashing of the Clean Air

Indicator Light.

Flashing of the Fan Speed

Indicator Light ' '.

Flashing of the Fan Speed

Indicator Light ' '.

E-18

OM_KC-A60EU_EN.indd Sec1:18OM_KC-A60EU_EN.indd Sec1:18 12/4/12 9:42 AM12/4/12 9:42 AM
