ASSEMBLING AND PREPARING

15

ENGLISH

Stand Assys

Stand Front

Stand Supporters

(Stand Body/Stand Base)

(Only LB70**, LB72**,

(Only LB70**, LB72**,

(Only 70LB65**-ZA, LB67**,

LB73**-ZD/ZE)

LB73**-ZD/ZE)

LB68**, LB69**, LB73**-ZA)

(See p. A-6)

(See p. A-6)

(See p. A-3)

Stand Assys

Sound Bar

Sound Bar Supporters

(Only LB86**, LB87**)

(Only LB86**, LB87**)

(Only LB86**, LB87**)

(See p. A-7)

(See p. A-7, A-8)

(See p. A-8)

Screw Covers

Component Gender

Composite Gender

(Only LB86**, LB87**)

Cable

Cable

(See p. A-7, A-9)

(Only LB86**, LB87**)

(Only LB86**, LB87**)

(See p. A-27)

(See p. A-27, A-30)

Scart Gender Cable

Wall Mount Spacers

(Only LB86**, LB87**)

2EA

(See p. A-49)

(Only 42LB63**, 42LB65**)

(See p. 23)

16

ASSEMBLING AND PREPARING

ENGLISH

Separate purchase

Separate purchase items can be changed or modied for quality improvement without any notication.

Contact your dealer to buy these items.

These devices only work with certain models.

AG-F***DP

AG-F***

AN-MR500

Dual Play Glasses

Cinema 3D Glasses

Magic Remote

AN-VC5**

Video Call Camera LG Audio Device Tag on

LB67**, LB68**,

LB69**, LB70**,

Compatibility

LB63** LB65**

LB87**

LB72**, LB73**,

LB86**

AG-F***DP

• • •

Dual Play Glasses

AG-F***

• • •

Cinema 3D Glasses

AN-MR500

• • • •

Magic Remote

AN-VC5**

• • •

Video Call Camera

LG Audio Device

• • • •

Tag On

• • • •

The model name or design may be changed depending on the upgrade of product functions,

manufacturer’s circumstances or policies.

ASSEMBLING AND PREPARING

17

Parts and buttons

ENGLISH

A type : LB63**-ZA, LB65**-ZA B type : LB63**-ZL, LB65**-ZK

Screen

Screen

Speakers

Speakers

Remote control and

Remote control and

1

1

Intelligent

sensors

Intelligent

sensors

Power Indicator

Power Indicator

2

2

Joystick Button

Joystick Button

C type : LB65**-ZE/ZN D type : LB67**, LB68**, LB69**,

LB73**-ZA

Screen

Screen

Speakers

Speakers

Remote control and

1

Remote control and

Intelligent

sensors

1

Intelligent

sensors

Power Indicator

Power Indicator

2

Joystick Button

2

Joystick Button

18

ASSEMBLING AND PREPARING

ENGLISH

F type : LB86**, LB87**E type : LB70**, LB72**, LB73**-ZE/ZD

Screen

Built-in Camera

Screen

(Only LB87**)

Speakers

Speakers

Remote control and

LG Logo light

1

Intelligent

sensors

Remote control and

Power Indicator

1

Intelligent

sensors

2

Joystick Button

2

Joystick Button

1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.

2 Joystick Button - This button is located below the TV screen.

NOTE

y

You can set the LG Logo Light or Power Indicator Light to on or off by selecting General in the

main menus. (Depending on model)

ASSEMBLING AND PREPARING

19

Using the Joystick button

ENGLISH

You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right.

Basic Functions

When the TV is turned off, place your finger on the joystick button

Power On

and press it once and release it.

When the TV is turned on, place your finger on the joystick

Power Off

button and press it once for a few seconds and release it.

Volume

If you place your finger over the joystick button and move it left or

Control

right, you can adjust the volume level you want.

Programmes

If you place your finger over the joystick button and move it up or

Control

down, you can scrolls through the saved programmes you want.

NOTE

y

When your finger over the joystick button and push it to the up, down, left or right, be careful not to

press the joystick button. If you press the joystick button first, you can not adjust the volume level

and saved programmes.

Adjusting the Menu

When the TV is turned on, press the joystick button one time.

You can adjust the Menu items( , , ) by moving the joystick button left or right.

TV OFF Turns the power off.

CLOSE Clears on-screen displays and returns to TV viewing.

INPUT Changes the input source.

20

ASSEMBLING AND PREPARING

y

When transporting a large TV, there should

ENGLISH

Lifting and moving the TV

be at least 2 people.

y

When transporting the TV by hand, hold the

Please note the following advice to prevent the

TV as shown in the following illustration.

TV from being scratched or damaged and for safe

transportation regardless of its type and size.

CAUTION

y

Avoid touching the screen at all times, as

this may result in damage to the screen.

y

It is recommended to move the TV in the

box or packing material that the TV originally

came in.

y

Before moving or lifting the TV, disconnect

the power cord and all cables.

y

When holding the TV, the screen should face

y

When transporting the TV, do not expose the

away from you to avoid damage.

TV to jolts or excessive vibration.

y

When transporting the TV, keep the TV

upright, never turn the TV on its side or tilt

towards the left or right.

y

Do not apply excessive pressure to cause

exing /bending of frame chassis as it may

damage screen.

y

When handling the TV, be careful not to

damage the protruding joystick button.

y

Hold the top and bottom of the TV frame

rmly. Make sure not to hold the transparent

part, speaker, or speaker grill area.

ASSEMBLING AND PREPARING

21

Securing the TV to a wall

Mounting on a table

ENGLISH

(This feature is not available for all models.)

1 Lift and tilt the TV into its upright position on a

table.

- Leave a 10 cm (minimum) space from

the wall for proper ventilation.

10 cm

10 cm

10 cm

10 cm

10 cm

1 Insert and tighten the eye-bolts, or TV brackets

and bolts on the back of the TV.

2 Connect the power cord to a wall outlet.

- If there are bolts inserted at the eye-

bolts position, remove the bolts first.

2 Mount the wall brackets with the bolts to the

CAUTION

wall.

Match the location of the wall bracket and the

y

Do not place the TV near or on sources

of heat, as this may result in fire or other

eye-bolts on the rear of the TV.

damage.

3 Connect the eye-bolts and wall brackets tightly

with a sturdy rope.

Make sure to keep the rope horizontal with the

at surface.

Using the Kensington security system

(This not available for all models.)

CAUTION

y

Image shown may differ from your TV.

The Kensington security system connector is

y

Make sure that children do not climb on

located at the rear of the TV. For more information

or hang on the TV.

of installation and using, refer to the manual

provided with the Kensington security system or

visit

http://www.kensington.com.

NOTE

y

Use a platform or cabinet that is strong

Connect the Kensington security system cable

and large enough to support the TV

between the TV and a table.

securely.

y

Brackets, bolts and ropes are not

provided. You can obtain additional

accessories from your local dealer.

22

ASSEMBLING AND PREPARING

Make sure to use screws and wall mount

ENGLISH

Mounting on a wall

bracket that meet the VESA standard. Standard

dimensions for the wall mount kits are described

Attach an optional wall mount bracket at the rear

in the following table.

of the TV carefully and install the wall mount

bracket on a solid wall perpendicular to the

oor. When you attach the TV to other building

Separate purchase(Wall Mounting Bracket)

materials, please contact qualied personnel.

LG recommends that wall mounting be performed

Model

32/39LB65**

42/47/55LB63**

by a qualied professional installer.

42/47/50/55LB65**

49/55LB86**

We recommend the use of LG’s wall mount

49/55LB87**

bracket.

VESA (A x B) 200 x 200 400 x 400

When you do not use LG’s wall mount bracket,

Standard screw M6 M6

please use a wall mount bracket where the

Number of

4 4

device is adequately secured to the wall with

screws

enough space to allow connectivity to external

Wall mount

LSW240B

LSW440B

devices.

bracket

MSW240

MSW240

Model

60LB65**

70LB65**

42/47/50/55LB67**

42/47/55/60/65LB68**

42/47/55LB69**

10 cm

42/47/55LB70**

42/47/55/60/65LB72**

10 cm

42/47/55/60/65LB73**

10 cm

60LB86**

60LB87**

10 cm

VESA (A x B) 400 x 400 600 x 400

Standard screw M6 M8

Number of

4 4

screws

Wall mount

LSW440B LSW640B

bracket

Wall mount bracket

MSW240 LSW240B LSW440B LSW640B

A

B

ASSEMBLING AND PREPARING

23

Using Built-in Camera

ENGLISH

CAUTION

(Only LB87**)

y

Disconnect the power first, and then

You can make a Skype video call or use the

move or install the TV. Otherwise electric

motion recognition function using the built-in

shock may occur.

camera of the TV.

y

If you install the TV on a ceiling or slanted

This TV does not support the use of an external

wall, it may fall and result in severe injury.

camera.

Use an authorised LG wall mount and

contact the local dealer or qualified

personnel.

NOTE

y

Do not over tighten the screws as this

may cause damage to the TV and void

y

Before using the built-in camera, you

your warranty.

must recognize the fact that you are

y

Use the screws and wall mounts that

legally responsible for the use or misuse

meet the VESA standard. Any damages

of the camera by the relevant national

or injuries by misuse or using an

laws including the criminal law.

improper accessory are not covered by

y

The relevant laws include the Personal

the warranty.

Information Protection law which

regulates the processing and transferring

of personal information and the law which

regulates the monitoring by camera in a

NOTE

workplace and other places.

y

Use the screws that are listed on the

y

When using the built-in camera,

VESA standard screw specifications.

avoid questionable, illegal, or immoral

y

The wall mount kit includes an installation

situations. Other than at public places or

manual and necessary parts.

events, consent to be photographed may

y

The wall mount bracket is not provided.

be required. We suggest avoiding the

You can obtain additional accessories

following situations:

from your local dealer.

(1) Using the camera in areas where the

y

The length of screws may differ

use of camera is generally prohibited

depending on the wall mount. Make sure

such as restroom, locker room, fitting

to use the proper length.

room and security area.

y

For more information, refer to the manual

(2) Using the camera while causing the

supplied with the wall mount.

infringement of privacy.

y

When attaching a wall mounting

(3) Using the camera while causing the

bracket to the TV, insert the wall

violation of the relevant regulations or

mount spacers into the TV wall mount

laws.

holes to adjust the vertical angle of

the TV. (Only 42LB63**, 42LB65**)

Wall Mount Spacer

30

MAINTENANCE / TROUBLESHOOTING

ENGLISH

MAINTENANCE

Cleaning your TV

Clean your TV regularly to keep the best performance and to extend the product lifespan.

CAUTION

y

Make sure to turn the power off and disconnect the power cord and all other cables first.

y

When the TV is left unattended and unused for a long time, disconnect the power cord from the

wall outlet to prevent possible damage from lightning or power surges.

Screen, frame, cabinet and stand

y

To remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.

y

To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild

detergent. Then wipe immediately with a dry cloth.

CAUTION

y

Avoid touching the screen at all times, as this may result in damage to the screen.

y

Do not push, rub, or hit the screen surface with your fingernail or a sharp object, as this may result

in scratches and image distortions.

y

Do not use any chemicals as this may damage the product.

y

Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or

malfunction.

Power cord

Remove the accumulated dust or dirt on the power cord regularly.

TROUBLESHOOTING

Problem Solution

Cannot control

y

Check the remote control sensor on the product and try again.

the TV with the

y

Check if there is any obstacle between the product and the remote control.

remote control.

y

Check if the batteries are still working and properly installed ( to ,

to ).

No image display

y

Check if the product is turned on.

and no sound is

y

Check if the power cord is connected to a wall outlet.

produced.

y

Check if there is a problem in the wall outlet by connecting other products.

The TV turns off

y

Check the power control settings. The power supply may be interrupted.

suddenly.

y

Check if the Automatic Standby(Depending on model) / Sleep Timer /

Timer Power Off is activated in the Timers settings.

y

If there is no signal while the TV is on, the TV will turn off automatically after

15 minutes of inactivity.

When connecting

y

Turn the TV off/on using the remote control.

to the PC (HDMI/

y

Reconnect the HDMI cable.

DVI), ‘No signal’

y

Restart the PC with the TV on.

or ‘Invalid Format’

is displayed.

SPECIFICATIONS

31

SPECIFICATIONS

ENGLISH

Wireless module(LGSBW41) Specifications

Wireless LAN Bluetooth

Standard

IEEE 802.11a/b/g/n Standard

Bluetooth Version 3.0

2400 to 2483.5MHz

Frequency

5150 to 5250 MHz

Frequency

2400 to 2483.5MHz

Range

5725 to 5850 MHz(for Non

Range

EU)

802.11a: 13 dBm

Output

802.11b: 15 dBm

Output

Power

802.11g: 14 dBm

Power

10dBm or Lower

(Max.)

802.11n - 2.4GHz: 16 dBm

(Max.)

802.11n - 5GHz: 16 dBm

y

Because band channel used by the country could be different, the user can not change or adjust the

operating frequency and this product is set for the regional frequency table.

y

This device should be installed and operated with minimum distance 20 cm between the device and

your body. And this phrase is for the general statement for consideration of user environment.

HASZNÁLATI ÚTMUTATÓ

*

LED TV

* Az LG LED TV megnevezés a LED

háttérfénnyel ellátott LCD képernyőkre

vonatkozik.

Válassza!

Felhasználói Útmutató

A készülék használatbavétele előtt figyelmesen olvassa el az útmutatót,

és őrizze meg, mert később szüksége lehet rá.

www.lg.com

2

TARTALOMJEGYZÉK

TARTALOMJEGYZÉK

29 A HASZNÁLATI ÚTMUTATÓ

3 LICENCEK

HASZNÁLATA

MAGYAR

3 NYÍLT FORRÁSKÓDÚ

30 KARBANTARTÁS

SZOFTVEREKRE VONATKOZÓ

30 A TV-készülék tisztítása

MEGJEGYZÉSEK

30 - Képernyő,keret,készülékházés

állvány

30 - Tápkábel tisztítása

3 KÜLSŐVEZÉRLŐESZKÖZ

BEÁLLÍTÁSA

30 HIBAELHÁRÍTÁS

4 BIZTONSÁGI TUDNIVALÓK

31 MŰSZAKIADATOK

10 - 3D képek megtekintése (Csak 3D

típusoknál)

12 ÖSSZESZERELÉSIFOLYAMAT

12 ÖSSZESZERELÉSÉS

ELŐKÉSZÍTÉS

12 Kicsomagolás

16 Külön megvásárolható tartozékok

17 A készülék részei és gombjai

19 - A joystick gomb használata

20 A TV felemelése és szállítása

VIGYÁZAT
