JVC GR-DVX10: 14 EN

TRANSFERRING TITLE/FRAME IMAGES

14 EN

You can transfer Title/Frame Images you created on the PC to the video source unit

that is packaged with MultiMediaNavigator.

Preparation

1. Insert a MultiMediaCard into the video

source unit.

2. Set your video source unit to the PLAY

or PLAY/PC position.

(For more details, refer to the video

source unit’s instruction manual.)

Click the Title Screen Transfer icon in

1

the MultiMediaNavigator window.

• Picture Navigator starts up.

Double-click the TitleScreen album.

2

• A list of all the Title/Frame Images

appears in the window.

Select the Title/Frame Image you wish to

3

transfer.

• The check box in the lower left corner

of the index image changes color.

Click the Transfer icon or select Edit —

4

Transfer.

• The Title/Frame Image is transferred to

the video source unit and stored in the

MultiMediaCard.

Add the Title/Frame Image to a still

5

image in the video source unit.

(For more details, refer to the video

source unit’s instruction manual.)
