Xoro HTC 2225D: LCD Menu

LCD Menu

For all the buttons mentioned below, you can use those on the front panel, or you can use

those on the remote control. To see the menus, press the LCD MENU button. The first will

show either:

• the VIDEO menu, if the set is switched to TV, AV, S-video, SCART, DVB-T, DVD

• the PC menu, if the set is switched to PC

• The HDMI menu, if the set is switched to HDMI

English

Press the MENU button again, to see the other menus:

• another press to see the AUDIO menu

• another press to see the TV menu (only when switched to TV)

• another press to see the GENERAL menu

• another press to see the menus off.

To select a menu item, for example COLOUR, press the CH+ and CH- buttons to

• scroll up and down the list.

• When a menu item is highlighted, use the VOL+ or VOL-buttons to change the setting.

When you have changed the settings, you can exit from the menu：

• by waiting fifteen seconds without pressing any buttons,

• by pressing the LCD MENU button few times until the menus turn off.

11

LCD Menu

Video Menu

The first press of the LCD MENU button will show the VIDEO menu, if the set is switched to

TV, AV, S-Video, SCART, DVB-T, DVD. In this menu it is possible to change brightness,

contrast, colour and the sharpness.

Brightness

Use the VOL+ or VOL- buttons to adjust the

brightness of the picture.

Contrast

Use the VOL+ or VOL- buttons to adjust the

contrast of the picture.

Colour

English

Use the VOL+ or VOL- buttons to adjust the

colour of the picture.

Sharpness

Use the VOL+ or VOL- buttons to adjust the

sharpness of the picture.

PC Menu

If the LCD is connected by VGA to a personal computer (PC) or to a device with VGA out-

put, so by pressing the LCD MENU button the PC-Menu starts up.

Brightness

Use the VOL+ or VOL- buttons to adjust the

brightness of the picture.

Contrast

Use the VOL+ or VOL- buttons to adjust the

contrast of the picture.

Color setting

Use the VOL+ or VOL- buttons to select from

6500k, 9300k or USER.

If you select USER, you can use the VOL+ or

VOL- buttons to adjust the RED.

Green and blue values individually. Press

MENU button when you have finished adjust-

ing .

Auto configure

Press the VOL+ button to have the following

settings configured automatically.

12

LCD Menu

PC Menu

Horizontal and vertical position

Use the VOL+ or VOL- buttons to adjust the position of the picture on the screen.

Phase

Use VOL+ or VOL- buttons to adjust the phase of the ADC sampling clock relative to the H-

sync signal, until a stable image is obtained.

Clock

English

Use the VOL+ or VOL- buttons to adjust the pixel clock frequency, until the image size is

maximized for the screen.

HDMI Menu

If the LCD is connected by HDMI to a personal computer (PC) or to a device with HDMI

output, so by pressing the LCD MENU button the PC-Menu starts up.

Brightness

Use the VOL+ or VOL- buttons to adjust the

brightness of the picture.

Contrast

Use the VOL+ or VOL- buttons to adjust the

contrast of the picture.

Color setting

Use the VOL+ or VOL- buttons to select from

6500k, 9300k or USER.

If you select USER, you can use the VOL+ or

VOL- buttons to adjust the RED.

Green and blue values individually. Press

MENU button when you have finished adjusting .

Auto configure

Press the VOL+ button to have the following settings configured automatically

Horizontal and vertical position

Use the VOL+ or VOL- buttons to adjust the position of the picture on the screen.

13
