Xoro HTC 2225D: SPÉCIFICATIONS

SPÉCIFICATIONS

HTC 1525D HTC 1925 HTC 2225D

Screen Size 39 cm (15,4 pouses) 48 cm (19 pouces) 56 cm (22 pouces)

Display Type TFT LCD

Resolution 1280 x 800 1440 x 900 1680 x 1050

Aspect Ratio 16:10

2

2

2

Brightness 200 cd/m

300 cd/m

400 cd/m

Contrast 300:1 1000:1 1000:1

Response Time 25 ms 6,5 ms 5 ms

Viewing Angle 90 ° 160 ° 160 °

TV System PAL BG / DK / I

SECAM BG / DK / L / L‘

Stereo NICAM / A2

Interface

Français

CVBS Video 1,0 V p-p 75 Ohm

S-Video Y: 1,0 V p-p +/- 3 dB

C: 0,3 V p-p +/- 3 dB

Scart CVBS: 1,0 V p-p 75 Ohm

RGB: 1,0 V p-p 75 Ohm

PC VGA 640 x 480 bei 60 Hz / 800 x 600 bei 60 Hz / 1024 x 768 bei 60 Hz

Antenna RF Antennenanschluss, 75 Ohm

Speaker 2 x 3 Watt 2 x 3 Watt 2 x 5 Watt

Video System PAL / NTSC

AC / DC Adapter AC: 110—260 V 50 / 60 Hz

DC: 12 V bei max. 5 A

Comsumption

60 W / Standby 3 W

Dimension

385 x 175 x 336 mm 465 x 210 x 410 mm 540 x 210 x 460 mm

(LxTxH)

Weight 5,5 kg 6,5 kg 7,0 kg
