Peg-Perego IGED1091: ENGLISH

the axle into one of the two rear wheels: make

sure you use the wheel shown in Figure A.

10 • Insert the axle with the wheel into the hole of

the gearmotor, pressing to be sure it exits from

the opposite side of the vehicle.

11 • Turn the wheel slightly to match up the

gearmotor pentagon with the one on the

wheel (Figure shows incorrect fastening of the

wheel).

12 • Insert the bushing as shown in the figure,

working from the other side of the shaft until it

is hooked to the body.

13 • Insert an iron washer as shown in the figure.

14 • Reposition the tool (used previously to insert

the self-locking washer - see Figure 7) on the

axle from the wheel side. Place the vehicle on

one side, keeping the wheel underneath. Make

sure the tool cannot shift.

15 •

(1)

Position the remaining wheel end insert an

iron washer.

(2)

Insert a self-locking washer on

the provided tool (shown in the figure).

Caution: The tabs of the self-locking washer

must face the inside of the tool (see small

picture A).

(3)

Fasten the wheel as shown in the

figure, pushing the self-locking washer down

completely.

16 • Snap on the remaining stud covers on both

sides.

17 • Position the handle support.

18 • Slide on the handle, orienting it as shown in the

figure.

19 • Fasten the handle with a washer and screw.

20 • Position the cap by inserting the tongue (1)

into the rear notch of the support. Turn the cap

(2).

21 • Apply the silver decal.

22 • Apply the glass on the front light till it clicks.

23 • Place the trunk support on the vehicle, and

fasten it with the 4 screws that come with it.

24 • Place the trunk on the support, fitting it into

the special hooks, as shown in the figure. Pull

the trunk all the way towards you, to fit it into

place (detail A).

25 • Rotate the red catch behind the saddle until

bringing it to the position shown on figure. A:

the saddle is locked. B: the saddle can be lifted.

Lift up the saddle.

26 • Connect the two plugs.

27 • Reposition the saddle by sliding the two pins

into the holes on the tank. Turn the red catch

behind the saddle in order to fasten it. The

vehicle is ready to use.

VEHICLE FEATURES AND INSTRUCTIONS FOR

USE

28 • GEARSHIFT LEVER: Your child will have fun

pretending to change gears using this gearshift

lever, which can be rotated into two positions.

29 • ACCELERATOR/ELECTRIC BRAKE PEDAL: The

vehicle brakes automatically when your child

lift his/her foot off the pedal.

REPLACING THE BATTERY

30 • Rotate the red catch behind the saddle until

bringing it to the position shown on figure 25

(figure B). Lift up the saddle. Unplug the

terminals. Unscrew the battery fastener.

31 • Lower the catch (1) and, at the same time, push

the battery fastener as indicated by the arrow

(2) to release it. Remove the battery fastener.

32 • Replace the battery. (NOTE: The replacement

battery – separately available – is a 6v/ 8Ah

battery pack). Replace and screw back on the

battery fastener. Connect the two plugs.

CAUTION: When you have finished, remember

to close and fix down the seat.

BATTERY RECHARGE

WARNING: BATTERY CHARGING AND EVERY OTHER

OPERATION ON THE ELECTRICAL SYSTEM MUST BE

CARRIED OUT BY ADULTS ONLY.

THE BATTERY CAN ALSO BE CHARGED WITHOUT

REMOVING IT FROM THE TOY.

33 • Unplug vehicle wiring terminal A from battery

terminal B, by pressing terminals on side and

pulling apart.

34 • Plug the battery charger terminal to a wall

outlet following the instructions enclosed.

Connect the plug B to the battery charger plug

C.

35 • Once the charge is completed unplug

recharger from wall outlet. Unplug recharger

cord terminal C from battery terminal B.

36 • Plug battery terminal A into vehicle wiring

terminal B. Close saddle.

Before riding, charge your batteries for 18 hours to

• PEG PEREGO® thanks you for choosing this

product. For over 50 years, PEG PEREGO has been

taking children for an outing: first with its famous

baby carriages and strollers, later with its pedal and

battery operated toy vehicles.

• Read this instruction manual carefully to learn the

use of this vehicle and to teach your child safe and

enjoyable driving. Please keep this manual for use

as a reference in the future.

• Our toys conform with the safety requirements

provided by the Council of the EEC, of the T.Ü.V.; of

the I.I.S.G. Istituto Italiano Sicurezza Giocattoli, and

the U.S. Consumer Toy Safety Specification F963.

Peg Perego S.p.A. is an ISO 9001

certified company.

The fact that we are certified provides

a guarantee of our honesty for our

customers, and fosters trust in the

company’s way of working.

• Peg Perego reserves the right to modify or change

their product. Price, literature, manufacturing

processes or locations or any combination of these

above mentioned entities may change at any time

for any reason without notice with impunity.

Years 2-4

PEG PEREGO offers after-sales services, directly or

with a network of authorized service centers for

repairs or replacement parts. See the back cover of

this instruction manual for a list of service centers.

Peg Perego is at the consumer's service, meeting

every need in the best way possible. This is why our

customers' opinions are so important and valuable

to us. We would be very grateful if you would kindly

fill in the CUSTOMER SATISFACTION

QUESTIONNAIRE after using one of our products.

You will find the questionnaire on the Internet at

"www.pegperego.com/SSCo.html.en-UK".

Please note any observations or suggestions you

may have on the questionnaire.

ADULT ASSEMBLY REQUIRED.

USE CARE WHEN UNPACKING AS COMPONENTS TO

BE ASSEMBLED MAY POSE A SMALL PARTS/SHARP

EDGE HAZARD.

BATTERY ALREADY INSTALLED IN VEHICLE.

ASSEMBLY

1 • Check the forecarriage to be sure it is correctly

fastened at points (A). Remove the protective

caps (B).

2 • Insert an iron washer on the pin of the

forecarriage, as shown in the figure.

3 •

(1)

Insert one of the two front wheels: make

sure you use the wheel shown in Figure A.

(2)

Insert an iron washer.

4 • Insert a self-locking washer on the provided

tool (shown in the figure). Caution: The tabs of

the self-locking washer must face the inside of

the tool (see small picture A). NOTE: the bag

contains 8 self-locking washers. Keep 4 of them

apart as spare washers.

5 • Fasten the wheel as shown in the figure,

pushing the self-locking washer down

completely.

6 • Snap on the stud cover. Perform the same

operations as the ones in Figure 2 for the other

front wheel.

7 • Insert a self-locking washer on the provided

tool (shown in the figure). Caution: The tabs of

the self-locking washer must face the inside of

the tool (see small picture A).

8 • Remove the grey protective caps at the ends of

the rear axle. Insert the axle on the tool as

shown in the figure.

9 •

(1)

Insert an iron washer on the axle.

(2)

Insert

ENGLISH

CUSTOMER SERVICE

ASSEMBLY INSTRUCTIONS

dell’impianto elettrico.

• Non lasciare le batterie o il veicolo vicino a fonti di

calore come caloriferi, caminetti, etc.

• Proteggere il veicolo da acqua, pioggia, neve etc.;

usarlo su sabbia o fango potrebbe causare danni

a pulsanti, motori e riduttori.

• Se il veicolo agisce in condizioni di sovraccarico,

come su sabbia soffice, fango o terreni molto

sconnessi, l’interruttore di sovraccarico toglierà

immediatamente potenza. L’erogazione di

potenza riprenderà dopo alcuni secondi.

• Lubrificare periodicamente (con olio leggero)

parti semovibili come cuscinetti, sterzo etc.

• Le superfici del veicolo possono essere pulite con

un panno umido e, se necessario, con prodotti di

uso domestico non abrasivi.

• Le operazioni di pulizia devono essere effettuate

solo da adulti.

• Non smontare mai i meccanismi del veicolo o i

motori, se non autorizzati dalla PEG PEREGO.

Conforme a EN 50088

Batteria ricaricabile da 6V 4,5Ah al piombo sigillata.

1 motore da 60 W

SICUREZZA

ATTENZIONE! LA SUPERVISIONE DI UN ADULTO É

SEMPRE NECESSARIA.

• Non adatto ai bambini di età inferiore ai 24 mesi

per caratteristiche funzionali.

• Non usare il veicolo su strade pubbliche, dove c’è

traffico e macchine parcheggiate, su pendenze

ripide, vicino a gradini e scale, corsi d’acqua e

piscine.

• I bambini devono sempre indossare scarpe

durante l’uso del veicolo.

• Quando il veicolo è operativo fare attenzione

affinché i bambini non mettano mani, piedi o altre

parti del corpo, indumenti o altre cose, vicino alle

parti in movimento.

• Non bagnare mai componenti del veicolo come

motori, impianti, pulsanti, etc.

• Vicino al veicolo non usare benzine o altre

sostanze infiammabili.

• Il veicolo deve essere usato esclusivamente da un

solo bambino.

DIVERTIMENTO SENZA INTERRUZIONI: tenete

sempre un set-batterie carico di ricambio pronto

all’uso.

Per la sicurezza del bambino: prima di azionare il

veicolo, leggere e seguire attentamente le seguenti

istruzioni.

• ATTENZIONE:

Controllare che tutte le borchie di fissaggio delle

ruote siano ben salde.

• MARCIA AVANTI:

Con entrambe le mani sul manubrio premere il

pedale dell’ acceleratore;

il veicolo si mette in moto ad una velocità di circa

4 Km/h.

• FRENO:

Per frenare alzare il piede dal pedale acceleratore,

il freno entrerà in funzione automaticamente.

Insegnate al vostro bambino un uso corretto del

veicolo per una guida sicura e divertente.

• Prima di partire assicurarsi che il percorso sia

sgombro da persone o cose.

• Guidare con le mani sul manubrio e guardare

sempre la strada.

• Frenare per tempo per evitare scontri.

• ATTENZIONE! se il veicolo agisce in condizioni

di sovraccarico, come su sabbia soffice, fango o

terreni molto sconnessi, l’interruttore di

sovraccarico toglierà immediatamente

potenza. L’erogazione di potenza riprenderà

dopo alcuni secondi.

IL VEICOLO NON FUNZIONA?

• Verificare che non ci siano cavi scollegati sotto la

piastra dell’ acceleratore.

• Controllare il funzionamento del pulsante

dell’acceleratore ed eventualmente sostituirlo.

• Controllare che la batteria sia attaccata all’

impianto elettrico.

IL VEICOLO NON HA POTENZA?

• Caricare le batterie. Se dopo la ricarica il problema

persiste far controllare le batterie ed il

REGOLE PER UNA GUIDA SICURA

PROBLEMI?

BATTERY MAINTENANCE AND SAFETY

caricabatterie da un centro assistenza.
