Grandstream GVR3550 Quick Installation Guide: инструкция

Grandstream Networks, Inc.

126 Brookline Ave, 3rd Floor

Boston, MA 02215. USA

Tel : +1 (617) 566 - 9300

Fax: +1 (617) 249 - 1987

www.grandstream.com

TM

HDMI, the HDMI Logo, and High-Denition Multimedia

Interface are trademarks or registered trademarks of

GVR3550

HDMI Licensing LLC in the United States and other

countries.

Network Video Recorder

Quick Installation Guide

For Warranty and RMA information, please visit www.grandstream.com

Content

EN

PRECAUTIONS: OVERVIEW:

• Do not expose this device to temperatures outside the range of 0°C to +50°C

GVR3550 is a NVR device with high performance and large HDD capacity. It pro-

for operating or -20°C to +60°C for storage.

vides a set of unied remote monitor system solution for small and medium-sized

• Do not expose this device to environments outside of the following humidity

enterprises at low cost. It is equipped with HDD detection and management, net-

range: 10-90% RH (non-condensing).

work conguration, alarm event list, remote/local quick search, integrated local

• Do not install HDD while device is powered on.

and remote preview, multiple screen display and alarm record. It also supports

• Do not power cycle the device during system bootup or rmware upgrade. It may

quick operation using mouse, keyboard, remote controller and front panel buttons.

corrupt rmware and damage the device.

• Only use supplied power adapter. Other adapter may damage the product and

INSTALL THE HDD:

void the warranty.

1. Install the supplied screws to the 4 holes on the bottom of the HDD loosely.

• Please follow this guide before operating the device.

CHANGE OR MODIFICATIONS TO THIS PRODUCT NOT EXPRESSLY AP-

PROVED BY GRANDSTREAM NETWORKS, INC., OR PERATION OF THE

PRODUCT IN ANY WAY OTHER THAN AS DESCRIBED BY THIS GUIDE

COULD VOID THE FACTORY WARRANTY.

REPRODUCTION OR RETRANSMITTAL OF THE ENTIRE OR ANY PART OF

THIS DOCUMENT, IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR

PRINT, FOR ANY PURPOSE WITHOUT THE EXPRESS WRITTEN PERMIS-

SION FROM GRANDSTREAM NETWORKS, INC. IS NOT PERMITTED.

2. Remove the 8 screws on back and side panel of the device then open the

cover panel.

PACKAGE CONTENT:

1 x Power Adapter1 x Main Case

2 x SATA

4 x SATA

2 x Wire

1 x Remote Controller

Power Cable

Data Cable

Clamper

18 x HDD

4 x Mount Bracket

1 x Ethernet Cable

1 x Quick Installation Guide

Screws

with 12 Screws

1 2
