Graco AquaMax-E 3050: 2 Introduction

6

1)

 Options / model variants

Original instructions

English

2 Introduction

Operating elements and

accessories

1. Handle

2. Hose

reel

1)

3.  Mains power lead

4.  Tank filler for detergent

1)

5.  Filling of pump oil and check

of oil level

6. Detergent

tank

1)

7.  High pressure hose connec-

tion

1)

8.  Supply water connection with

water inlet filter

9. Pressure

gauge

10.  Detergent metering knob

11. Main switch

12.  Pressure regulation on spray

lance

1)

13. Spray lance

14.  Receptacle for Spray lance

15. Spray gun

16.  Detergent intake hose

17.  Receptacle for electrical lead

1

2

3

4

5

6

7

8

15

14

13

12

11

10

9

16

17

7

1)

 Options / model variants

Original instructions

English

Instructions for use

Prior to using the appliance for the first time, be sure to read this docu-

ment through and keep it ready to hand.

Besides the operating instructions and the binding accident prevention

regulations valid in the country of use, observe recognised regulations

for safety and proper use.

Purpose and intended use

This high-pressure cleaner has been designed for professional use. It

can be used for cleaning agricultural and construction equipment, sta-

bles, vehicles, rusty surfaces, etc.

The cleaner has not been approved for cleaning surfaces which comes

into contact with food.

Any other use is considered as improper use. The manufacturer ac-

cepts no liability for any damage resulting from such use. The risk for

such use is borne solely by the user. Proper use also includes proper

operation, servicing and repairs as specified by the manu facturer.

Further support

Before use

For further queries, please contact the GRACO service representative

responsible for your country.

Before starting up your machine, please check it carefully for any de-

fects. If you find any, do not start up your machine.
