Инструкция к Печи-коптильне Weber Pg5
®
PERFORMER
Charcoal Grill Owner’s Guide
Käyttöohje • Mode d’emploi • Manuale dell’utente • Brukerveiledning • Brugervejledning •
Guía del propietario Användarhandbok • Bedienungsanleitung • Handboek van de eigenaar •
Manual do Proprietário nstrukcja użytkownika • Руководство пользователя
Assembly - Pg 5
- p. 24
- p. 37 - p. 50
- p. 63
- p. 76
- p. 89
- p. 102
- p. 115 - p. 128
- p. 141
- p. 154
- p. 167
#88991
WARNING: Follow all leak-check
YOU MUST READ THIS OWNERS GUIDE
procedures carefully in this manual prior
BEFORE OPERATING YOUR GAS GRILL
to barbecue operation. Do this even if
barbecue was dealer assembled.
DANGER
If you smell gas:
®
WARNING: Do not try to light the Weber
1. Shut off gas to the appliance.
gas barbecue without first reading the
2. Extinguish any open flames.
“Lighting” instructions in this manual.
3. Open lid.
4. If odour continues, keep away from the
INFORMATION FOR THE INSTALLER:
appliance and immediately call your gas
This manual must remain with the owner,
supplier or your fire service.
who should keep it for future use.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
ONLY TO BE USED OUTDOORS.
WARNING:
1. Do not store or use petrol or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected for
use should not be stored in the vicinity
of this or any other appliance.
88991 08/17/09 LP
GB - ENGLISH
DANGERS AND WARNINGS
FAILURE TO HEED THESE DANGER, WARNING AND CAUTION STATEMENTS MAY CAUSE SERIOUS BODILY INJURY OR DEATH,
OR A FIRE OR EXPLOSION RESULTING IN DAMAGE TO PROPERTY.
SAFETY SYMBOLS ( ) will alert you to important SAFETY information.
Signal Words DANGER, WARNING, or CAUTION will be used with the SAFETY SYMBOL.
DANGER will identify the most serious hazard.
Please read all safety information contained in this Owner’s Guide before operating this barbecue.
DANGERS
Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or
death, or in a fire or an explosion causing damage to property.
Do not use indoors! This barbecue is designed for outdoor use only. If used indoors, toxic fumes will accumulate and cause
serious bodily injury or death.
Only use this barbecue outdoors in a well-ventilated area. Do not use in a garage, building, breezeway or any other enclosed
area.
Do not use this barbecue under any overhead combustible construction.
Improper assembly may be dangerous. Please follow the assembly instructions in this manual. Do not use barbecue unless all
parts are in place. Make sure either the ash catcher is properly attached to the legs underneath the bowl of the barbecue, or the
high capacity ash catcher is in place, before lighting the grill.
Do not add charcoal starter fluid or charcoal impregnated with charcoal lighter fluid to hot or warm charcoal. Cap starter fluid
after use, and place a safe distance away from the barbecue.
Do not use petrol, liquid fire starter or alcohol on the charcoal at any time. Do not use any form of self-lighting charcoal at any
time.
You should exercise reasonable care when operating your barbecue. It will be hot during cooking and should never be left
unattended during use.
Do not leave infants, children or pets unattended near a hot barbecue.
Do not attempt to move a hot barbecue.
Do not use this barbecue within five feet of any combustible material. Combustible materials include, but are not limited to
wood or treated wood decks, patios and porches.
Combustible materials should never be within 24 inches of the top, bottom, back or sides of barbecue.
Keep the cooking area clear of flammable vapor and liquids, such as gasoline, alcohol, etc., and combustible material.
Do not remove ashes until all charcoal is completely burned out and are fully extinguished and grill is cool.
Always put charcoal in Char-Baskets™ or on top of the lower (charcoal) grate. Do not put charcoal directly in the bottom of the
bowl.
Do not wear clothing with loose flowing sleeves while lighting or using the barbecue.
Never lean over the barbecue when lighting the gas burner.
Do not use barbecue in high winds.
Do not operate the barbecue if a gas leak is present.
Do not use a flame to check for gas leaks.
Should the burner go out at any time during operation, turn tank valve off. Remove lid and wait five minutes before attempting
to relight, using the lighting instructions outlined in this Manual.
Do not attempt to disconnect the gas regulator from the tank or any gas fitting while the barbecue is in use.
Use only the LP gas regulator that is supplied with your barbecue.
WARNINGS
Follow regulator connection instructions for your type of gas grill.
Do not store a spare or disconnected LP disposable cartridge under or near this barbecue.
Keep the barbecue on a secure, level surface at all times, clear of combustible materials.
Do not put a barbecue cover or anything flammable on or in the storage area under the barbecue.
Always remove the lid before lighting the gas burner, either manually or with the igniter. Lid must remain OFF until charcoal is
fully ignited.
Never touch the cooking or charcoal grates, ashes, charcoal or the barbecue to see if they are hot.
Do not use lava or char rocks in this barbecue.
Do not use water to control flare-ups or to extinguish charcoal, as it may damage the porcelain finish. Slightly close bottom air
vents (dampers) and place lid on bowl.
Extinguish coals when finished cooking. Close all vents (dampers) after putting lid on bowl.
Barbecue mitts should always be worn while cooking, adjusting air vents (dampers), adding charcoal and handling the
thermometer or lid.
Use proper barbecue tools, with long, heat-resistant handles.
Some models may include the Tuck-Away™ lid holder feature. The Tuck-Away™ lid holder is used to store the lid while checking
on or turning your food. Do not use the Tuck-Away™ lid holder as a handle to lift or move the grill. Do not place a hot lid on
carpeting or grass. Do not hang the lid on the bowl handle.
Never dump hot coals where they might be stepped on or be a fire hazard. Never dump ashes or coals before they are fully
extinguished. Do not store barbecue until ashes and coals are fully extinguished.
2
COUNTRY GAS TYPE & PRESSURE
Demark, Sweden, Norway, Finland,
I
3B/P
- 29mbar
England, Netherlands, United King-
dom, France, Spain, Portugal, Belgium,
Ireland, Greece, Luxembourg, Italy,
Germany, Austria
CONSUMPTION DATA
Lighting Burner. Max
Propane/
kW(Hs) gm(Hs)
butane mix
2.6 192
WWW.WEBER.COM
®
3
DANGERS AND WARNINGS (CONT’D.)
Handle and store hot electric starters carefully.
Keep electrical wires and cords away from the hot surfaces of the barbecue and away from high traffic areas.
After a period of storage and/or nonuse, check for gas leaks and burner obstructions before using. See instructions in this
manual for correct procedures.
The conversion or attempted use of natural gas in this barbecue is dangerous and will void your warranty.
A dented or rusty LP disposable cartridge may be hazardous and should be checked by your liquid propane supplier. Do not
use an LP disposable cartridge with a damaged valve.
Although your LP disposable cartridge may appear to be empty, it may still contain gas. The LP disposable cartridge should be
transported and stored accordingly.
If you see, smell or hear gas escaping from the LP disposable cartridge:
1. Get away from the LP disposable cartridge.
2. Do not attempt to correct the problem yourself.
3. Call your fire department.
CAUTIONS
Lining the bowl with aluminum foil will obstruct the air flow. Instead, use a drip pan to catch drippings from meat when cooking
by the indirect method.
Using sharp objects to clean the cooking grate or remove ashes will damage the finish.
Using abrasive cleaners on the cooking grates or the barbecue itself will damage the finish.
The barbecue should be thoroughly cleaned on a regular basis.
Weber-Stephen Products Co. (Weber) hereby warrants to the ORIGINAL PURCHASER of this Weber
®
There are no other express warrants except as set forth herein and any applicable implied warranties
gas grill that it will be free of defects in material and workmanship from the date of purchase as follows:
of merchantability and fitness are limited in duration to the period of coverage of this express written
Cooking / Charcoal grates 2 years
Limited Warranty. Some regions do not allow limitation on how long an implied warranty lasts, so this
Stainless Steel One-Touch
®
Cleaning System 10 years
limitation may not apply to you.
Bowl and lid against rust / burn-through 10 years
Weber is not liable for any special, indirect or consequential damages. Some regions do not allow the
Nylon handles 10 years
exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not
Thermoplastic/Thermoset Parts(Performer
®
) 10 years
apply to you.
excluding fading
Weber does not authorise any person or company to assume for it any other obligation or liability in
All remaining parts 2 years
connection with the sale, installation, use, removal, return, or replacement of its equipment; and no
such representations are binding on Weber.
when assembled and operated in accordance with the printed instructions accompanying it.
Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN
This Warranty applies only to products sold at retail.
YOUR SALES RECEIPT OR INVOICE.
WEBER-STEPHEN PRODUCTS CO.
This Limited Warranty shall be limited to the repair or replacement of parts that prove defective under
normal use and service and which on examination shall indicate, to Weber’s satisfaction, they are
Customer Service Center
defective. Before returning any parts, contact the Customer Service Representative in your area
1890 Roselle Road, Suite 308
using the contact information on our website. If Weber confirms the defect and approves the claim,
Schaumburg, IL 60195
Weber will elect to replace such parts without charge. If you are required to return defective parts,
USA
transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage
prepaid.
For replacement parts call:
1-800-446-1071
This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse,
®
misuse, alteration, misapplication, vandalism, improper installation or improper maintenance or
Visit www.weber.com
, select your country of origin, and register your
service, or failure to perform normal and routine maintenance, including but not limited to damage
grill today.
caused by insects within the burner tubes, as set out in this owner’s manual.
Deterioration or damage due to severe weather conditions such as hail, hurricanes, earthquakes or
tornadoes, discolouration due to exposure to chemicals either directly or in the atmosphere, is not
covered by this Limited Warranty.
REPLACEMENT HOSE AND REGULATOR
Country Part#
Hose Belgium 41421
Hose/Reg Holland 41421
Hose/Reg Greece/Italy 41421
Hose/Reg Germany/Austria 41421
Hose/Reg Spain/Denmark/Portugal 41421
Hose/Reg Sweden 41421
Hose/Reg Switzerland 41421
Hose/Reg Ireland 41421
Hose/Reg England 41421
Hose/Reg Australia 41421
Hose/Reg Norway/Finland 41421
WARRANTY
Demark, Sweden, Norway, Finland,
England, Netherlands, United King-
dom, France, Spain, Portugal, Belgium,
Ireland, Greece, Luxembourg, Italy,
Germany, Austria
butane mix
Propane/
COUNTRY GAS TYPE & PRESSURE
kW(Hs) gm(Hs)
2.6 192
CONSUMPTION DATA
Lighting Burner. Max
WWW.WEBER.COM
I
3B/P
- 29mbar
®
3
DANGERS AND WARNINGS (CONT’D.)
Handle and store hot electric starters carefully.
Keep electrical wires and cords away from the hot surfaces of the barbecue and away from high traffic areas.
After a period of storage and/or nonuse, check for gas leaks and burner obstructions before using. See instructions in this
manual for correct procedures.
The conversion or attempted use of natural gas in this barbecue is dangerous and will void your warranty.
A dented or rusty LP disposable cartridge may be hazardous and should be checked by your liquid propane supplier. Do not
use an LP disposable cartridge with a damaged valve.
Although your LP disposable cartridge may appear to be empty, it may still contain gas. The LP disposable cartridge should be
transported and stored accordingly.
If you see, smell or hear gas escaping from the LP disposable cartridge:
1. Get away from the LP disposable cartridge.
2. Do not attempt to correct the problem yourself.
3. Call your fire department.
CAUTIONS
Lining the bowl with aluminum foil will obstruct the air flow. Instead, use a drip pan to catch drippings from meat when cooking
by the indirect method.
Using sharp objects to clean the cooking grate or remove ashes will damage the finish.
Using abrasive cleaners on the cooking grates or the barbecue itself will damage the finish.
The barbecue should be thoroughly cleaned on a regular basis.
Weber-Stephen Products Co. (Weber) hereby warrants to the ORIGINAL PURCHASER of this Weber
gas grill that it will be free of defects in material and workmanship from the date of purchase as follows:
when assembled and operated in accordance with the printed instructions accompanying it.
Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN
YOUR SALES RECEIPT OR INVOICE.
This Limited Warranty shall be limited to the repair or replacement of parts that prove defective under
normal use and service and which on examination shall indicate, to Weber’s satisfaction, they are
defective. Before returning any parts, contact the Customer Service Representative in your area
using the contact information on our website. If Weber confirms the defect and approves the claim,
Weber will elect to replace such parts without charge. If you are required to return defective parts,
transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage
prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse,
misuse, alteration, misapplication, vandalism, improper installation or improper maintenance or
service, or failure to perform normal and routine maintenance, including but not limited to damage
caused by insects within the burner tubes, as set out in this owner’s manual.
Deterioration or damage due to severe weather conditions such as hail, hurricanes, earthquakes or
tornadoes, discolouration due to exposure to chemicals either directly or in the atmosphere, is not
covered by this Limited Warranty.
Country Part#
Hose Belgium 41421
Hose/Reg Holland 41421
Hose/Reg Greece/Italy 41421
Hose/Reg Germany/Austria 41421
Hose/Reg Spain/Denmark/Portugal 41421
Hose/Reg Sweden 41421
Hose/Reg Switzerland 41421
Hose/Reg Ireland 41421
Hose/Reg England 41421
Hose/Reg Australia 41421
Hose/Reg Norway/Finland 41421
Cooking / Charcoal grates 2 years
Stainless Steel One-Touch
Bowl and lid against rust / burn-through 10 years
Nylon handles 10 years
Thermoplastic/Thermoset Parts(Performer
excluding fading
All remaining parts 2 years
REPLACEMENT HOSE AND REGULATOR
®
Cleaning System 10 years
®
) 10 years
WARRANTY
®
There are no other express warrants except as set forth herein and any applicable implied warranties
of merchantability and fitness are limited in duration to the period of coverage of this express written
Limited Warranty. Some regions do not allow limitation on how long an implied warranty lasts, so this
limitation may not apply to you.
Weber is not liable for any special, indirect or consequential damages. Some regions do not allow the
exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not
apply to you.
Weber does not authorise any person or company to assume for it any other obligation or liability in
connection with the sale, installation, use, removal, return, or replacement of its equipment; and no
such representations are binding on Weber.
This Warranty applies only to products sold at retail.
WEBER-STEPHEN PRODUCTS CO.
Customer Service Center
1890 Roselle Road, Suite 308
Schaumburg, IL 60195
USA
For replacement parts call:
1-800-446-1071
Visit www.weber.com
grill today.
®
, select your country of origin, and register your
PARTS LIST
10mmmmm MM
1 -
4 -
2 -
8 -
4
ASSEMBLY
1 2
2 -
3
4
2 -
WWW.WEBER.COM
®
5
ASSEMBLY
5
6
2 -
4 -
7
6
ASSEMBLY
8
Aa
Aa
Ba
Ba
Ca
Ca
WWW.WEBER.COM
®
7
ASSEMBLY
9
10
4 - 4 -
8
ASSEMBLY
11
1 -
A
DANGER
Do not use the gas ignition feature
if the retaining clip (1) locking the
gas orifice (2) into the burner tube is
missing.
A missing retaining clip can cause
serious bodily injury or death, and
damage to property.
Pull regulator hose to test orifice to
burner tube connection.
1
2
(1)
1
2
VAARA
B
Älä käytä kaasusytytystoimintoa,
jos kaasusuuttimen (2) polttimeen
kiinnittävä lukkorengas (2) puuttuu.
Lukkorenkaan puuttuminen voi
aiheuttaa vakavan vamman tai
kuoleman sekä omaisuusvahinkoja.
Testaa suuttimen kiinnitys
poltinputkeen vetämällä säätimen
letkusta.
DANGER
PERICOLO
N’utilisez pas l’allumeur à gaz si
Non utilizzare il sistema di
le clip de retenue (1) verrouillant
accensione se manca il fermo (1)
l’embout de l'orifice de gaz (2) dans
che blocca il foro del gas (2) nel
le brûleur n’est pas présent.
bruciatore.
L'absence de clip de retenue peut
La mancanza del fermo può
provoquer des blessures graves,
provocare lesioni personali gravi o
voire mortelles, et des dommages
mortali e danni alle cose.
matériels.
Tirare il tubo del regolatore
Tirez sur le flexible du détendeur
per testare il collegamento del
pour vérifier le raccordement orifice
bruciatore al foro.
/ brûleur.
WWW.WEBER.COM
®
9
ASSEMBLY
11
1 -
A
FARE
Bruk ikke gasstenningen hvis
festeklipset (1) som låser
gassåpningen (2) på brennerrøret
mangler.
Hvis festeklipset mangler kan det
medføre alvorlig personskade eller
død, og skade på eiendom.
Dra i regulatorslangen for å teste
forbindelsen til brennerrøret.
1
2
(1)
1
2
FARE
B
Brug ikke gastændingssystemet,
hvis systemet mangler
holderklipsen (1), der låser gashullet
(2) til brænderslangen.
En manglende holderklips kan
forårsage alvorlige kvæstelser eller
død og materiel skade.
Træk i regulatorslangen for at
afprøve forbindelsen mellem hullet
og brænderslangen.
PELIGRO
FARA
No utilice la función de encendido
Använd inte
de gas si falta la pinza de retención
gaständningsfunktionen om
(1) que bloquea el orificio del gas (2)
fästklämman (1) som låser
del tubo del quemador.
gasmunstycket (2) i brännarröret
saknas.
La ausencia de la pinza de retención
puede provocar graves daños
En saknad fästklämma kan ge
personales y materiales, e incluso
upphov till livshotande skador och
víctimas mortales.
egendomsskador.
Tire del tubo flexible del regulador
Dra i regulatorslangen för att testa
para comprobar la conexión entre el
anslutningen mellan gasmunstycket
orificio y el tubo del quemador.
och brännarröret.
10
ASSEMBLY
11
1 -
A
GEVAAR
Gebruik het
gasontstekingsmechanisme niet als
de bevestigingsklem (1) ontbreekt
die de gasopening (2) in de
branderslang vergrendeld.
Een ontbrekende bevestigingsklem
kan ernstig lichamelijk letsel of de
dood en schade aan eigendommen
tot gevolg hebben.
1
Trek aan de slang van de regelaar
om de aansluiting tussen de
2
opening en de branderslang te
testen.
(1)
1
2
GEFAHRENHINWEIS
B
Benutzen Sie den Gaszünder nicht,
wenn die Halteklammer (1) zur
Befestigung der Gasdüse (2) im
Brennerrohr fehlt.
Eine fehlende Halteklammer kann
zu schweren und sogar tödlichen
Verletzungen und zu Sachschäden
führen.
Ziehen Sie am Reglerschlauch,
um die Befestigung der Düse am
Brennerrohr zu überprüfen.
NIEBEZPIECZEŃSTWO
ОПАСНО
Nie należy używać funkcji
PERIGO
Не используйте функцию
zapalania gazem, jeśli brakuje
Não utilize a ignição de gás se o
зажигания горелки при
zacisku zabezpieczającego (1)
grampo de retenção (1) que tapa o
отсутствии зажима (1),
blokującego otwór gazu (2) w
orifício de saída de gás (2) no tubo
закрепляющего газовое
rurze palnika.
do queimador não estiver presente.
отверстие (2) и трубку горелки.
Brak zacisku zabezpieczającego
A ausência do grampo de retenção
Отсутствие зажима может стать
może przyczynić się do
pode provocar ferimentos graves ou
причиной тяжелых телесных
poważnych obrażeń ciała, śmierci
morte, bem como danos materiais.
повреждений или смерти, а
i uszkodzenia mienia.
также материального ущерба.
Puxe o tubo do regulador para
Wyciągnąć przewód regulatora
testar o orifício de ligação do tubo
Потяните шланг регулятора
w celu sprawdzenia otworu do
do queimador.
для испытания отверстия на
połączenia rury palnika.
соединении трубки горелки.
WWW.WEBER.COM
®
11
ASSEMBLY
12
2 - 1 - 1 -
10mmmmm MM
13
A
B
14
4 -
33 lbs. Max.
A
B
(15Kg )
12
ASSEMBLY
15
30lb bag
Charcoal
30lb / 13.7kg
16
2 -
WWW.WEBER.COM
®
13
21
1
22
2
3
4
23
5
24
25
26
27
6
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
14
Performer LP Euro - 22 1/2 (57cm) 050609
EXPLODED VIEW
33 lbs. Max.
(15Kg )
28
29
30
31
32
33
34
35
36
37
38
EXPLODED VIEW LIST
Lid 1.
Hub Cap14.
Burner Assembly2 7.
Hinged Cooking Grate 2.
Wheel Cover15.
Hose & Regulator with Orifice Clip 28.
Charcoal Baskets3.
Front Panel16.
Rear Panel29.
Charcoal Grate 4.
Logo Plate17.
Frame Leg30.
One Touch5.
®
Damper Assembly
Tool Holders18.
CharBin™ Hardware31.
Lid Holder & Lower Support Assembly6.
Gas Control Cover19.
CharBin™ 32.
Ash Catcher Ring7.
Igniter20.
Casters33.
Ash Catcher Handle8.
Lid Handle Assembly21.
Caster Inserts34.
High Capacity Ash Catcher9.
Lid Damper Assembly22.
Leg Frame Bracket Clamp35.
Axle10.
Thermometer Assembly23.
Bottom Rack36.
Leg Frame Bracket11.
Bowl24.
Matchlight Holder3 7.
Igniter Wire Stay12.
Table25.
Wheel13.
CharBin™ Retention Chain26.
MAY INCLUDE:
Sear Grate with Hinged Cooking Grate38.
WWW.WEBER.COM
®
15
GENERAL INSTRUCTIONS
If you have questions or need advice regarding your grill or its safe operation, please log onto www.weber.com
®
.
• These instructions will give you the minimum requirements for assembling your Weber
®
barbecue. Please read the instructions carefully before using your Weber
®
barbecue.
Improper assembly can be dangerous.
• Not for use by children.
• This Weber
®
barbecue is designed for use with propane or a propane/Butane gas mix only. Do not use with natural gas. The valve and regulator are for Propane or a propane/
Butane gas mix only.
• This Weber
®
gas barbecue is not intended for commercial use.
• The use of alcohol and/or prescription or non-prescription drugs may impair the consumers ability to properly assemble or safely operate the appliance.
• This Weber
®
barbecue is not intended for and should never be used as a heater.
• Do not leave the Weber
®
barbecue unattended. Keep children and pets away from the Weber
®
barbecue at all times.
• Check that the area under the control panel and the bottom tray are free from debris that might obstruct the flow of combustion or ventilation air.
• Any parts sealed by the manufacturer must not be altered by the user.
• Any modification of the appliance may be dangerous.
FEATURES
a) Exclusive Touch-N-Go
™
Gas Ignition System takes the hassle out of lighting
g
charcoal briquets. Simply push a button and the system’s gas burner ignites,
ij
c
starting the charcoal for you. No dangerous liquid starters to use or store, and no
more liquid starter aftertaste.
b) CharBin
™
Storage Container holds a bag of charcoal with a maximum weight of
30 lbs./13.7 kg. The bag of charcoal should be placed directly in the CharBin
™
h
Storage Container.
c) Thermoset work surface serves as a great work area and covers the CharBin
™
Storage Container to keep briquets dry.
d) Convenient bottom rack for storage.
e) High-capacity ash catcher locks in place, eliminating blowing ashes.
f) One-Touch
®
Cleaning System easily sweeps out ashes, or opens and closes the
vents.
g) Thermometer monitors the cooking temperature inside the grill.
h) Tuck-Away
™
Lid slides back into the stainless steel lid holder and acts as a
windshield when lighting briquets.
i) Hinged access flaps swing open on cooking grate for easy addition of briquets or
wood chips during cooking.
j) Char-Basket
™
Fuel Holders allow convenient indirect and concentrated direct
cooking flexibility with wood or charcoal.
a
e
f b
d
OPERATING AREA
WARNING: Only use this barbecue outdoors in a well-
ventilated area. Do not use in a garage, building, breezeway
or any other enclosed area.
WARNING: Accessible parts may be very hot. Keep young
children away.
Never operate the barbecue under any overhead combustible
construction.
®
Your Weber
Barbecue is not intended to be installed in or on
recreational vehicles and/or boats.
Do not use combustible materials within 60cm of the top,
bottom, back or sides of the grill.
The entire barbecue gets hot when in use. Do not leave
unattended.
Keep any electrical supply cord and the fuel supply hose
Maximum 30 lbs. / 13.7 kg.
away from any heated surface.
bag of charcoal.
Keep the cooking area clear of flammable vapours and
Bag of charcoal should be
liquids, such as petrol, alcohol, etc., and combustible
™
placed directly in CharBin
materials.
Storage Container.
Do not move the appliance during use. Allow the grill to cool
before moving.
This appliance is not intended for and should never be used
as a heater.
16
GAS INSTRUCTIONS
CONNECTING THE LP DISPOSABLE CARTRIDGE
Use LP disposable cartridges with a minimum capacity of 430g and a maximum
capacity of 460g. The cartridge must have a EN417 valve as illustrated. One type
of cartridge that can be used is a Primus model 2202 or a Weber Q Gas disposable
cartridge.
1
CAUTION: Use cylinders that are marked Propane fuel or
Propane-Butane mix only.
Push LP disposable cartridge into regulator and turn clockwise until tight.
WARNING: Hand tighten only. Using excessive force could
damage the regulator coupling and could cause a leak or
lack of gas flow.
CHECK FOR GAS LEAKS:
DANGER
1
Do not use an open flame to check for gas leaks. Be sure
there are no sparks or open flames in the area while you
check for leaks. Sparks or flames will result in a fire or
explosion which can cause serious bodily injury or death as
well as damage to property.
You will need: LP disposable cartridge, a soap-and-water solution and a rag or brush to
apply it.
A) Mix the soap and water.
B) Turn the gas control to on by turning anti-clockwise.
C) Check for leaks by wetting the fitting with the soap-and-water solution and
watching for bubbles. If bubbles form, or if a bubble grows, there is a leak.
CHECK:
A) Regulator-to-LP disposable cartridge connection.
WARNING: If there is a leak at connection (1), remove LP
disposable cartridge. Do not operate grill. Use a different LP
disposable cartridge and recheck for leaks with soap-and-
water solution. If a leak persists after retightening the LP
cartridge, turn OFF the gas. DO NOT OPERATE THE GRILL.
2
Contact the Customer Service Representative in your area
using the contact information on our web site.
®
Log onto www.weber.com
.
CHECK:
B) Valve-to-regulator connections.
WARNING: If there is a leak at connection (2) turn OFF the
gas. DO NOT OPERATE THE GRILL. Contact the Customer
Service Representative in your region using the contact
®
information on our web site. Log onto www.weber.com
.
When leak checks are complete, turn gas supply OFF at the source and rinse
connections with water.
DANGER
Do not store a spare LP cartridge under or near this
appliance.
WWW.WEBER.COM
®
17
OPERATING
LIGHTING
1
DANGER
Open lid before lighting. Do not use any flammable liquids
such as starting fluid, gasoline, alcohol or any form of
self-lighting charcoal at any time, including when manually
lighting. Failure to do so will cause serious bodily injury or
death.
A) Remove grill lid before operating gas feature.
DANGER: Failure to do so can cause a gas build-up that can
cause a fire or explosion which can cause serious bodily
injury or death, or damage to property.
B) Open bottom bowl dampers (1).
C) Position charcoal baskets over burner (2).
D) Push in tabs on gas control cover (3) and lift to open.
E) Turn gas supply on (counter-clockwise) at least one full turn (4).
2
WARNING: Do not lean over open barbecue while lighting.
F) Push igniter button until burner ignites (5).
CAUTION: Flame may be hard to see on a bright day.
G) After charcoal has ignited, (approximately 5 minutes), turn gas control OFF
(clockwise) until it is closed.
CAUTION: Ensure cover is closed completely.
Note - Prolonged tank run time lessens tank life.
H) You can begin cooking when briquets have a light coating of grey ash
(approximately 25-30 minutes).
TO EXTINGUISH
Close gas supply by turning gas control clockwise until closed.
3
4
5
18
OPERATING
MANUAL LIGHTING
WARNING: Do not attempt to light manually without using
1
the match holder.
DANGER
Open lid before lighting. Do not use any flammable liquids
such as starting fluid, petrol, alcohol or any form of self-
lighting charcoal at any time, including when manually
lighting. Failure to do so will cause serious bodily injury or
death.
A) Remove grill lid before operating gas feature.
DANGER: Failure to do so can cause a gas build-up that can
cause a fire or explosion which can cause serious bodily
injury or death, or damage to property.
B) Open bottom bowl dampers (1).
C) Move Char-Baskets away from the burner (2).
2
D) Push in tabs on gas control cover (3) and lift to open.
E) Put a match in the match holder (4). Light match.
F) Turn gas supply on (counter-clockwise) at least one full turn (5).
G) Position match flame at rear of burner slot (6).
WARNING: Do not hold hand directly above burner when
manually lighting.
4
WARNING: Do not lean over open barbecue while lighting.
CAUTION: Flame may be hard to see on a bright day.
H) Wear barbecue mitts and use tongs to reposition Char-Baskets over burner.
6
I) After charcoal has ignited, (approximately 5 minutes), turn gas control OFF
(clockwise) until it is closed.
J) You can begin cooking when briquets have a light coating of grey ash
(approximately 25-30 minutes).
TO EXTINGUISH
Close gas supply by turning gas control clockwise until closed.
3
5
WWW.WEBER.COM
®
19
TROUBLESHOOTING
PROBLEM CHECK CURE
Burner burns with a yellow or orange flame, in
Inspect Burner for possible obstructions. Clean Burner.
conjunction with the smell of gas.
(See “Maintenance” section)
Burner does not light, or flame is low. Is LP fuel low or empty? Replace LP cylinder.
Is fuel hose bent or kinked? Straighten fuel hose.
Does the burner light with a match? If you can light the burner with a match, then check
the ignition system.
Is the hose to burner tube connection properly
Connect the gas hose to the burner tube using the
secured?
metal retaining clip provided.
DANGER: Do not use the gas ignition feature
if the retaining clip is missing. A missing
retaining clip can cause serious bodily injury
or death, and damage to property.
Contact Customer Service for a replacement retainer
clip.
Burner flame pattern is erratic. Is burner clean? Clean burner.
(See “Maintenance” section)
Inside of lid appears to be “peeling”. (Resembles
What you are seeing is baked on grease that has
Clean thoroughly.
paint peeling.)
turned to carbon and is flaking off.
(See “Cleaning” section)
THIS IS NOT A DEFECT.
If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our
web site. Log onto www.weber.com
®
.
20
