Xoro HSD 7150: SETUP

SETUP

General Operation

1. Press SETUP to enter the Setup Menu.

2. Press ENTER to the next level submenu or confirm your selection.

3. Press to enter the submenu or return to the previous menu

4. Press to highlight the desired menu.

5. To exit from the menu

6. Press SETUP again and the settings will be stored in the player's memory even if the

player is switched off.

English

Navigate through the options:

1. Press to highlight 'TV Display'.

2. Enter its submenu by pressing .

3. Move the cursor by pressing to highlight the selected item.

The Setup is divided into four different section: General Setup, Speaker Setup, Dolby Digital

Page and the Preference Page.

General Setup Page

The options included in General Setup page

are:" TV Display", "Angle Mark", "OSD lang",

"Captions", "Screen Saver".

TV Display

Set the aspect ratio of the DVD Player according to the TV you have connected.

Normal/PS

If you have a normal TV and want both sides of the picture

to be trimmed or formatted to fit your TV screen.

Normal/LB

If you have a normal TV. In this case , a wide picture with

black bands on the upper and lower portions of the TV

screen will be displayed.

Wide

If you have a wide-screen TV.

HSD 7150 27

SETUP

Angle Mark

Displays current angle setting information on the right hand corner of the TFT screen if avail-

able on the disc. The options are:

On: Enable Angle Mark.

Off: Disable the current angle setting display.

OSD Lang

You can select your own preferred language settings. This DVD system will automatically

switch to the selected language whenever you load a disc. If the language selected is not

English

available on the disc, the disc's default language will be used instead. The OSD language in

the system menu will remain once selected.

SPDIF Output

The setting is responsible for the digital audio output like Dolby Digital or DTS by the coaxial

or optical audio output to the AV Receiver or AV Amplifier. The options are:

SPDIF OFF: Deactivates the digital output

SPDIF/PCM: Output of digital audio in the PCM format

SPDIF/RAW: Output of all kind of digital audio formats.

Closed Captions

Closed captions are data that are hidden in the video signal of some discs. Captions are

different from subtitles because captions hearing are impaired by showing the sound effects

(e.g. "phone ringing" and “footsteps"), while subtitles do not. Before you select this function,

please ensure that the disc contains closed captions information and your TV set also has

this function.

On: Enable Closed Captions.

Off: Disable Closed Captions.

Screen Saver

This function is used to turn the screen saver On or Off.

On: In STOP, PAUSE or No DISC mode, if no actions are performed about 3 minutes,

the Screen Saver will be activated.

Off: Screen Saver is disabled.

28 HSD 7150

SETUP

Speaker Setup Page

The options included in Speaker

Setup Page is 'Downmix'.

English

Downmix

This options allows you to set the stereo analog output of your DVD Player.

LT/RT :Select this option if your DVD Player is connected to a Dolby Pro Logic decoder.

Stereo :Select this option when output delivers sound from only the two front speakers.

Dolby Digital Setup

The options included in Dolby Digital Setup are: 'Dual Mono ' and 'Dynamic '.

Dual Mono

To select the setting that matches the number of speakers you have connected.

Stereo: Left mono sound will send output signals to Left speaker and Right mono

sound will send output signals to Right speaker.

L-Mono: Left mono sound will send output signals to Left speaker and Right speaker.

R-Mono: Right mono sound will send output signals to Left speaker a. Right speaker.

Mix-Mono: Left and Right mixed mono sound will send output signals to Left and Right

speakers.

HSD 7150 29

SETUP

Dynamic

To optimize the dynamic sound output high volume outputs are softened, enabling you to

watch your favourite movie without disturbing others.

The levels for dynamic selection: Full, 7/8, 3/4, 5/8, 1/2, 3/8, 1/4, 1/8 and Off.

Video Settings

The Video Settings includes

options for “SHARPNESS”,

English

“BRIGHTNESS”, “CONTRAST”

and “SATURATION”.

These settings are for adjust-

ment the individual displaying of

the picture on the screen.

Sharpness

The options are “High”, “Middle” and “Low”. By the setting “Low” the DVD player produces a

very soften picture. By the setting “High” the picture is very sharp.

Brightness

The settings for brightness can be changes by using the scroll bar, which are displayed,

when you want to change to settings.

Contrast

The settings for contrast can be changes by using the scroll bar, which are displayed, when

you want to change to settings.

Saturation

The settings for saturation can be changes by using the scroll bar, which are displayed,

when you want to change to settings.

30 HSD 7150

SETUP

Preference Page

The options included in Preference page are : 'Audio', 'Subtitle', 'Disc Menu', 'Parental',

'Password', and 'Default'.

Note:

Some Preference features can be selected only during 'No Disc' condition or STOP mode.

English

Audio, Subtitle and Disc menu

These options set the Audio, Subtitle and Disc menu language fit for you.

• Audio (disc 's soundtrack / languages)

• Subtitle (disc 's subtitles / languages)

• Disc Menu (disc 's menu / languages)

HSD 7150 31

SETUP

Parental

DVD video discs equipped with the parental lock function are rated according to their con-

tent. The contents allowed by a parental lock level and the way a DVD video disc can be

controlled may vary from disc to disc. For example, if the disc allowed, you could edit out

violent scenes unsuitable for children and replace them with more suitable scenes, or lock

out playback of the disc all together.

1. Press stop twice during playback

2. Press SETUP

3. The SETUP MENU appears on the screen.

4. Select Preference Page, press ENTER.

English

5. Select Parental, press ENTER.

6. Select ratings, press ENTER

7. Enter your password then press ENTER. The pre-set password is 3308

8. Press SETUP to exit setup.

Ratings

• KID Safe - Kids material. Recommended especially for children and viewers of all

ages.

• 2 G - General Audience. Recommended as acceptable for viewers of all ages.

• 3 PG - Parental Guidance suggested.

• 4 PG13 - Material is unsuitable for children under age 13.

• 5-6 PG-R - Parental Guidance-Restricted. Recommended that parents restrict chil

dren under 17 from viewing or allow to view only when supervised by a parent or

adult guardian.

• 7 NC17 - No children under age 17. Not recommended viewing for children under

age 17.

• 8 ADULT - Mature material. Should be viewed only by adults due to graphic sexual

material,violence or language.

• OFF - It will play all discs.

Note:

Some DVDs are not encoded with a rating though the movie rating may be printed on the

Disc cover. The rating level feature does not work for such Discs.

32 HSD 7150

SETUP

Password

This feature is used for Parental Control. Enter your four digit password when a hint is dis-

played on the screen. The default password is 3308.

1. Press STOP twice during playback

2. Press SETUP

3. The SETUP MENU appears on the screen.

4. Select Preference Page, press ENTER.

English

5. Select password change.

6. Enter old password.

7. Enter new password.

8. Re-enter to confirm your new password.

9. Press ENTER.

10. Press SETUP to exit.

Default

Setting the 'Default ' function will reset all options and your personal settings to the factory

defaults and all your personal settings will be erased.

Caution!

When this function is activated, all settings will be reset to factory defaults.

HSD 7150 33
