Appearance
Unit: mm (inch)
R90
(R3-17/32)
125 (4-29/32)
225 (8-27/32)
175 (6-7/8)
90 (3-17/32) 108 (4-1/4)
180 (7-3/32)
220 (8-21/32)
3 (1/8) 53 (2-3/32)
22
