Planet POE-151S: 6. Product Specication

6. Product Specication

English

Product POE-151S POE-152S POE-162S

Hardware Specication

“Data” Output Port 1 x RJ-45 STP

“PoE (Data + Power)”

Interface

1 x RJ-45 STP

Input Port

DC Out Plug Connector 1

LED Indicator System: PoE in Use x 1 (Green)

Network Cable UTP Cat. 5/5e/6, up to 100m (328ft)

Data Rate 10/100Mbps 10/100/1000Mbps 10/100/1000Mbps

Dimension (W x D x H) 73 x 55 x 24 mm 73 x 55 x 24 mm 95 x 70 x 25 mm

Weight 50g 50g 111g

Power over Ethernet

IEEE 802.3at / af

PoE Standard IEEE 802.3af Power over Ethernet / PD

Power over Ethernet

/ PD

PoE Power Input 802.3af 48V DC 802.3at 52~56V DC

5V / 12V DC

5V / 12V DC

12V / 24V DC

DIP Switch

Output voltage

Output voltage

Output voltage

Number of device can be powered 1 1 1

Standards Conformance

IEEE 802.3 10Base-T Ethernet

  

IEEE 802.3u 100Base-TX

  

Fast Ethernet

IEEE 802.3ab 1000Base-T

-

 

Gigabit Ethernet

IEEE 802.3af Power over Ethernet

  

IEEE 802.3at Power over Ethernet - -



FCC Class B, CE

FCC Class A, CE

FCC Class A, CE

Regulation Compliance

mark

mark

mark

Environment

Operating Temperature 0 ~ 50 Degree C

Storage Temperature -10 ~ 70 Degree C

Humidity 5 ~ 95% (Non-condensing)

1-7
