Planet POE-151S: 6. Especicación de Producto

6. Especicación de Producto: Planet POE-151S

6. Especicación de Producto

Producto POE-151S POE-152S POE-162S

Especicación de Hardware

Puerto de Salida de

1 x RJ-45 STP

“Datos”

“PoE (Data + Energía)”

Interface

1 x RJ-45 STP

Puerto de Entrada

Conector de Enchufe de

1

Salida CC

Indicador LED Sistema: PoE en Uso x 1 (Verde)

Cable de Red UTP Cat. 5/5e/6, hasta 100m (328pies)

Ratio de Data 10/100Mbps 10/100/1000Mbps 10/100/1000Mbps

Dimensión (Ancho x Profundidad

73 x 55 x 24 mm 73 x 55 x 24 mm 95 x 70 x 25 mm

x Altura)

Peso 50g 50g 111g

Energía sobre Ethernet

IEEE 802.3at /

IEEE 802.3af Energía sobre Ethernet

Estándar PoE

af Energía sobre

/ DE

Ethernet / DE

Entrada de Energía PoE 802.3af 48V CC 802.3at 52~56V CC

Voltaje de Salida

Voltaje de Salida

Voltaje de Salida

Enchufe DIP

5V / 12V CC

5V / 12V CC

12V / 24V CC

Número de dispositivos que pueden

1 1 1

ser encendidos

Estándares de Conformidad

IEEE 802.3 10 Base-T Ethernet

IEEE 802.3u 100 Base-TX

Fast Ethernet

IEEE 802.3ab 1000Base-T

Español

-

Gigabit Ethernet

IEEE 802.3af Energía sobre Ethernet

IEEE 802.3at Energía sobre Ethernet - -

FCC Clase B,

FCC Clase A,

FCC Clase A,

Cumplimiento de Reglamento

marca CE

marca CE

marca CE

Medio Ambiente

Temperatura Operativa 0 ~ 50 Grados C

Temperatura de Almacenamiento -10 ~ 70 Grados C

Humedad 5 ~ 95% (Sin condensación)

7-7

EC Declaration of Conformity

For the following equipment:

*Type of Product :

IEEE802.3af Power over Ethernet Splitter

*Model Number : POE-151S, POE-152S

* Produced by:

Manufacturer‘s Name : Planet Technology Corp.

Manufacturer‘s Address: 10F., No.96, Minquan Rd., Xindian Dist.,

New Taipei City 231, Taiwan (R.O.C.).

Is here with confirmed to comply with the requirements set out in the Council Directive

on the Approximation of the Laws of the Member States relating to Electromagnetic

Compatibility (2004/108/EC).

For the evaluation regarding the EMC, the following standards were applied:

EN 55022 (Class B : 2006)

EN 61000-3-2 (2006)

EN 61000-3-3 (1995+A1:2001+A2:2005)

EN 55024 (1998+A1:2001+A2:2003)

IEC 61000-4-2 (2001)

IEC 61000-4-3 (2008)

IEC 61000-4-4 (2004)

IEC 61000-4-5 (2005)

IEC 61000-4-6 (2008)

IEC 61000-4-8 (2001)

IEC 61000-4-11 (2004)

Responsible for marking this declaration if the:

Manufacturer Authorized representative established within the EU

Authorized representative established within the EU (if applicable):

Company Name: Planet Technology Corp.

Company Address: 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan

(R.O.C.)

Person responsible for making this declaration

Name, Surname Kent Kang

Position / Title : Product Manager

Taiwan

29th, Sep., 2009

Place Date Legal Signature

PLANET TECHNOLOGY CORPORATION

e-mail: sales@planet.com.tw http://www.planet.com.tw

10F., No.96, Minquan Rd., Xindian Dist., New Taipei City, Taiwan, R.O.C. Tel:886-2-2219-9518 Fax:886-2-2219-9528
