Risk of injury from the machine running out.

3. MACHINE DESCRIPTION AND

INCLUDED CONTENTS

Machine description (see pic 1)

1 -

Switch

10 -

Spool with line

2 -

Handle

11 -

Blade for shortening the line

3 -

Adjustable second handle

12 -

Battery pack

4 -

Screw for attaching the second handle

13 -

Wheel assembly

5 -

Telescopic pole for setting the working height

14 -

Joint for setting up the slope of the trimmer

6 -

Locking bolt for fastening the telescopic pole

head

7 -

Trimmer head

15 -

Trigger lock-off button

8 -

Safety guard

16 -

Collapsible distance span for protection of

9 -

Line

plants

ATTENTION: The line cutting blade on the protective cover is sharp!

Supplied contents

Carefully take out the garden tool from the packaging and check whether all the following parts

are present:

Cordless grass trimmer

Distance span

Battery pack

Wheel assembly with screw for tightening

Charger

Charging station

Protective guard

Handle with attachment screw

User´s manual

If there are parts missing or they are damaged, please contact the vendor from whom you bought

the machine.
