Fieldmann FZV 2001-E: 3. MACHINE DESCRIPTION AND DELIVERY CONTENT

10EN Explanation for instruction plates on the machine | Machine description and delivery content

Before carrying out setup or

maintenance of the machine, or if the

power supply cable got caught or was

damaged, always switch-off the engine

and pull the plug out of the power

socket first!

Use protective equipment while

working.

Before carrying out any work on the

mowing equipment, pull the cable out

of the power socket first!

3. MACHINE DESCRIPTION

AND DELIVERY CONTENT

Machine description (see Fig.1)

1 -

Safety combined switch (On / Off) with a

7 - Raking roll (optional)

connector

8 - Collection box (optional)

2 -

Guiding handle

3 -

Safety cover

4 -

Exhauster

5 -

Lawn verticutter N1B-JY-30

6 -

Scarifying roll

FZV 2001-E
