Xoro HSD 8550: SETUP
SETUP: Xoro HSD 8550
SETUP
Press the SETUP button to enter the player's setup menu. Setup menu is a facility for the owner to
adjust the detail setting of the player. For the detail of Setup menu see "SET UP MENU" of this
instruction manual. Various features of the player can be adjusted in the SETUP menu.
1. Press SETUP button SETUP menu appears.
2. Press the LEFT/RIGHT button to highlight the desired menu.
3. Press the UP/DOWN button to enter the desired menu.
System Setup
English
The options in the System Setup page are: TV
SYSTEM, SCREEN SAVER, HD OUTPUT,
VIDEO, TV TYPE, PASSWORD, RATING and
DEFAULT.
TV Type
Selecting the colour system that corresponds to your TV when AV outputs. This DVD Player is
compatible with both NTSC and PAL. In order for a DVD disc to play on this Player, the colour
system of the Disc, the TV and the DVD Player should match.
PAL
Select this if the connected TV is PAL system. It will change the video signal of a NTSC disc and
output in PAL format.
NTSC
Select this if the connected TV is NTSC system. It will change the video signal of a PAL disc and
output in NTSC format.
Screen Saver
This function is used to turn the screen saver On or Off.
On: In STOP, PAUSE or No DISC mode, if no actions are performed about 3 minutes, the
Screen Saver will be activated.
Off: Screen Saver is disabled.
HD OUTPUT
In this option, you can select different resolution (Off, 720p, 1080i or 1080p). The default set is HD
OFF.
When you change to the HDMI output with different resolution from the normal video output, a
interface will be displayed. Select “yes” to confirm change, select “no” to exit.
HSD 8550 31
SETUP
System Setup
Video
The setting component specify the kind of video output.
TV-RGB
This setting is useful, when you connect the DVD player with your TV set and the TV set has a
SCART connector which supports RGB signals. With RGB signals on SCART you can get a better
picture quality compare to FBAS signals (YUV setting).
INTERLACE-YUV
If you connect the DVD player with a 3-wire component cable to your TV set and can use only
Interlace mode (Y Cb Cr), than please choose the INTERLACE-YUV setting.
English
P-SCAN YPBPR
If you connect the DVD player with a 3-wire component cable to your TV set and can use
Progressive Scan mode (Y Pb Pr), than please choose the P-SCAN YPBPR setting.
S-VIDEO
If you connect the DVD player by S-VIDEO cable with your TV set, than uses the setting S-Video.
TV Type
Set the aspect ratio of the DVD Player according to the TV you have connected.
Normal/PS
If you have a normal TV and want both sides of the picture to
be trimmed or formatted to fit your TV screen.
Normal/LB
If you have a normal TV. In this case , a wide picture with
black bands on the upper and lower portions of the TV
screen will be displayed.
Wide
If you have a wide-screen TV.
Password
Move the cursor the PASSWORD item and press OK button to confirm and then input the secret
code “0 0 0 0” (if it is the first use). After confirmation, you are required to input new secret code and
then press OK button to confirm.
Warning:
Please remember the new secret code, otherwise you will not be able to change the parental
control. Please contact the agent or our company if you forget the secret code.
32 HSD 8550
SETUP
System Setup
RATING
There are total eight levels of this control. Eight levels as follow::
1. KID-SAFE
2. G
3. PG
4. PG13
5. PG-R
6. R
7. NC-17
English
8. ADULT
The first level discs are open to people of average and eight level only suitable for the adult . If you
want to change the Parental control setting, enter the user’s age control item and then enter four
digital secret code. The default secret code is 0000 (if you are using this player for the first time, just
input this code). If the input code has been confirmed, the level setting up menu will appear. Move
the cursor to choose the expected level and press ENTER button to confirm and store it.
Default
This is the factory default setting up . When choose “RESTORE”, the previous setting up, by the
user will be cancelled and the player will come to the factory setting up state.
Caution!
When this function is activated, all settings will be reset to factory defaults.
HSD 8550 33
SETUP
Language Setup
In STOP mode, press DVD SETUP button and Highlight LANGUAGE.
• Press UP/DOWN button
• Press OK button, the screen displays
submenu.
• Press UP/DOWN button to highlight the
desired item in the LANGUAGE menu.
The options are: OSD LANGUAGE, AUDIO
LANGUAGE, SUBTITLE LANGUAGE, MENU
LANGUAGE and MPEG-4 SUBTITLE.
English
OSD Lang
You can select your own preferred language settings. This DVD system will automatically switch to
the selected language whenever you load a disc. If the language selected is not available on the
disc, the disc's default language will be used instead. The OSD language in the system menu will
remain once selected.
Audio, Subtitle and Disc menu
These options set the Audio, Subtitle and Disc menu language fit for you.
• Audio (disc 's soundtrack / languages)
• Subtitle (disc 's subtitles / languages)
• Disc Menu (disc 's menu / languages)
MPEG4 Subtitle
With this option, you specify the language of external subtitles in AVI files.
With the setting Western EU German, French or for example Spanish special characters supported.
With the setting Central EU Czech, Hungarian, Slovene characters will be displayed.
With the setting Russian Cyrillic characters are supported.
34 HSD 8550
SETUP
Audio Setup
This menu includes the options for AUDIO OUT
and KEY.
Audio Out
The setting is responsible for the digital audio
output like Dolby Digital or DTS by the coaxial or
optical audio output to the AV Receiver or AV
Amplifier.
English
SPDIF OFF: Deactivates the digital output
SPDIF/PCM: Output of digital audio in the PCM format
SPDIF/RAW: Output of all kind of digital audio formats.
Key
The setting “KEY” adjust the bass audio output.
Positive values for decreasing the bass.
Negative values for increasing the bass.
HSD 8550 35
SETUP
Video Setup Page
The Video settings included options for
SHARPNESS, BRIGHTNESS, CONTRAST,
HUE, SATURATION and DEEPCOLOR.
Brightness and Contrast
The two settings can use the UP / DOWN keys to change and allow individual settings.
English
The LEFT button will take you to the settings of the video quality
Hue
The setting can use the UP / DOWN keys to change and allow individual settings.
Positive value produces more powerful red colours and negative value produces more
powerful blue colours in the picture.
The LEFT button will take you to the settings of the video quality.
Saturation
The setting can use the UP / DOWN keys to change and allow individual settings.
Higher value produces more powerful colours in the picture.
The LEFT button will take you to the settings of the video quality.
Sharpness
The setting can use the UP / DOWN keys to change and allow individual settings.
Higher value produces more shaprness in the picture.
The LEFT button will take you to the settings of the video quality.
DEEPCOLOR
The Standard Deep Colour is an extension of the depth of the previously used 8 bits per colour
channel. The specification for HDMI 1.3 supports this standard, which requires, above all, a much
higher bandwidth. While true colour can represent at a depth of 24 bits 16,777,216 colours, it brings
Deep Colour with 30 bit colour depth, 36-bit and 48 bit to much higher colour resolutions. Achieved
at 36-bit Deep Colour, a colour resolution from 68.7 x 10exp9 (Giga) colours and 48-bit colour can
theoretically be shown as high as 281.4 x 10exp12 (Tera) shades. With this high colour resolution,
for example, HDTV colours of unsurpassed quality and naturalness of pose with high contrast. Due
to the infinite number of shades represent interpolations between individual pixels. Even in the
shade of gray tones and Deep Colour offer a much nuances representation over the 16 bits of the
24-bit High Colour or True Colour.
The options are: Off, 30bit and 36bit.
36 HSD 8550
SETUP
Digital Setup Page
The Digital Setup Page includes the options for
OP MODE, DYNAMIC and DUAL MONO.
English
Dual Mono
To select the setting that matches the number of speakers you have connected.
Stereo: Left mono sound will send output signals to Left speaker and Right mono sound will
send output signals to Right speaker.
L-Mono: Left mono sound will send output signals to Left speaker and Right speaker.
R-Mono: Right mono sound will send output signals to Left speaker a. Right speaker.
Mix-Mono: Left and Right mixed mono sound will send output signals to Left and Right
speakers.
OP Mode
This option includes the settings LINE OUT and RF REMOD.
Line Out
This setting (a kind of night mode) is suitable for playing at night, because the volume setting is
limited.
RF Remod
This option reduces not the volume output.
Dynamic
Here you can change the audio compression. If you choose the setting
“FULL” than the audio gets the biggest limitation. A kind of “NIGHT
MODE”. By using the setting “OFF”, the audio gets no compression.
HSD 8550 37
SETUP
Speaker Setup Page
The Speakr Setup Page has only the option for
DOWNMIX.
Downmix
This options allows you to set the stereo analogue output of your DVD Player.
English
LT/RT
Select this option if your DVD Player is connected to a Dolby Pro Logic decoder.
Stereo
Select this option when output delivers sound from only the two front speakers.
VSS
With this option creates the player a surround sound on two speakers.
38 HSD 8550
