Sennheiser MKE 600: Specifications
Specifications: Sennheiser MKE 600
MKE 600 |5
ENFRITPTNLRUZH ES DE
Specifications
Pick-up pattern super-cardioid/lobar
Frequency response 40 Hz to 20 kHz
Sensitivity with P48 powering: 21 mV/Pa
with battery powering: 19 mV/Pa
Max. SPL with P48 powering: 132 dB SPL
with battery powering: 126 dB SPL
Equivalent noise level
with P48 powering: 15 dB (A)
A-weighted
with battery powering: 16 dB (A)
Power supply 48 V ± 4 V (P48, IEC 61938) via XLR-3
or battery/rechargeable battery
(AA size, 1.5 V/1.2 V)
Current consumption with P48 powering: 4.4 mA
Operating time with
battery approx. 150 h
“Low Batt” indicator < 1.05 V; approx. 8 h of remaining oper-
ating time after initial display
Diameter 20 mm
Length 256 mm
Weight 128 g (without battery)
Operating temperature –10°C to +60°C
Polar diagram
0°
0
30°30°
5
10
60°60°
15
20
25
dB
90°90°
120°120°
150°150°
180°
125 Hz
2000 Hz
250 Hz
4000 Hz
500 Hz
8000 Hz
1000 Hz
16000 Hz
Frequency response curve
dB V
-20
-30
-40
-50
-60
-70
100
1.00
50 Hz
100 Hz
200 Hz 500 Hz 1 kHz 2 kHz 5 kHz 10 kHz 20 kHz
Linear
“Low Cut”
MKE 600_SP9.book Seite 5 Donnerstag, 10. Mai 2012 12:47 12
