3. Product Outlook

POE-151S / POE-152S

English

There are two RJ-45 Twisted-Pair jack , one LED indicator, one DC 5V /

2A, 12V / 1A DIP switch and one DC Plug connector.

1-2

Figure 1: POE-151S / POE-152S

POE-162S

There are two RJ-45 Twisted-Pair jack, one LED indicator, one DC 12V /

2A, 24V / 1A DIP switch and one DC Plug connector.

Figure 2: POE-162S Overview

4. LED Indication

LED Color Function

Lights to indicate the port is connected with IEEE 802.3af

PoE In Green

/ at PSE device.
