Grandstream GXV3240 Quick Installation Guide: 3 4

OVERVIEW:

Installing The Phone (Phone Stand):

GXV3240 represents the future in personal IP multimedia communication, featur-

Attach the phone stand to the back of the phone where there is a slot for the

ing Android™ Operating System 4.2 and its vast number of 3rd party applications,

phone stand. Upper part and bottom part are available for two angels.

a 4.3” (480x272) capacitive touch screen, a tiltable mega-pixel CMOS sensor,

dual Gigabit network ports, integrated Wi-Fi, PoE and Bluetooth. The GXV3240

delivers superior HD audio & video, leading edge telephony features and integra-

CONNECTING THE PHONE:

tion of rich Web content with access to the rapidly growing Android™ applications

base and automated provisioning. GXV3240 redenes the desktop communica-

tion experience with a raised level of innovation and integration of state-of-art real

1. Connect the handset and main phone case with the phone cord;

time video conferencing, personalized rich media presentation & delivery, popular

2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a rou-

Web and social networking applications and advanced business productivity tools.

ter (LAN side of the router) using the Ethernet cable;

3. Connect the 12V DC output plug to the power jack on the phone; plug the power

PHONE SETUP:

adapter into an electrical outlet. If PoE switch is used in step 2, this step could

be skipped;

4. The LCD will display booting up or rmware upgrading information. Before con-

tinuing, please wait for the main screen display to show up;

5. Using the web conguration interface or from the menu of the touch screen, you

can further congure network connection using static IP, DHCP and etc.

Slots for the wall mount

and phone stand

USB Port

Installing The Phone (Wall Mount):

1. Attach the wall mount to the slots on the back of the phone;

SD Card Slot

2. Attach the phone to the wall via the wall mount hole;

3. Pull out the tab from the handset cradle (see gure below);

HDMI Port

4. Rotate the tab and plug it back into the slot with the extension up to hold the

handset while the phone is mounted on the wall.

Handset Rest

Tab with extension up

EXT

Power

PC

LAN

Headset

Handset

Port

Port

Port

Port

Port

Tab with extension down

3 4
