JVC KD-PDR51: Remote controller — RM-RK50

Main elements and features

Remote controller — RM-RK50

Installing the lithium coin battery

(CR2025)

ENGLISH

1 (standby/on/attenuator) button

Aim the remote controller directly at the remote

• Turns the power on if pressed briefly or

sensor on the unit. Make sure there is no obstacle

attenuates the sound when the power is on.

in between.

• Turns the power off if pressed and held.

2 5 U (up) / D (down) ∞ buttons

• Changes the FM/AM bands with 5 U.

Warning:

• Changes the preset stations with D ∞.

• Changes the folder of the MP3/WMA discs.

• Do not install any battery other than CR2025 or

• While listening to an Apple iPod:

its equivalent; otherwise, it may explode.

– Pauses or resumes playback with D ∞.

• Do not leave the remote controller in a place

– Enters the main menu with 5 U.

(such as dashboards) exposed to direct sunlight

(Now 5 U/D ∞/2 R/F 3 work as the menu

for a long time; otherwise, it may explode.

selecting buttons.)*

• Store the battery in a place where children

3

VOL – / VOL + buttons

cannot reach to avoid risk of accident.

• Adjusts the volume level.

• To prevent the battery from over-heating,

4 SOUND button

cracking, or starting a fire:

•

Selects the sound mode (iEQ: intelligent equalizer).

– Do not recharge, short, disassemble, heat the

5 SOURCE button

battery, or dispose of it in a fire.

• Selects the source.

– Do not leave the battery with other metallic

6 2 R (reverse) / F (forward) 3 buttons

materials.

• Searches for stations if pressed briefly.

– Do not poke the battery with tweezers or similar

• Fast-forwards or reverses the track if pressed and

tools.

held.

– Wrap the battery with tape and insulate when

• Changes the tracks if pressed briefly.

throwing away or saving it.

• While listening to an iPod (in menu selecting

mode):

– Selects an item if pressed briefly. (Then, press

This unit is equipped with the steering wheel

D ∞ to confirm the selection.)

remote control function.

– Skips 10 items at a time if pressed and held.

• See the Installation/Connection Manual (separate

volume) for connection.

* 5 U : Returns to the previous menu.

D ∞ : Confirms the selection.

5
