41

a) Tisztítsa meg a sütő ajtaját és a szigetelés felületét.

b) Helyezze a rádió, TV készüléket, egyéb berendezést a mikrohullámú sütőtől a

lehető legtávolabb.

c) Használjon megfelelő, erős jelvételt biztosító antennát a rádió vagy televízió

készüléken.

ÖSSZEÁLLÍTÁS

1. Távolítson minden csomagolóanyagot, nyissa ki az ajtót és ürítse ki a

sütőteret.

2. Ellenőrizze a mikrohullámú sütő alábbi egységeit:

- Lógó ajtó

- Sérült ajtó

- Horpadások, lyukak az ajtó üvegén és a kijelzőn

- Horpadások a sütőtérben

- Amennyiben a fenti hibák valamelyikét észleli NE HASZNÁLJA a sütőt.

3. Ez a mikrohullámú sütő 10.5 kilogramm súlyú, így olyan vízszintes konzolra

kell helyezni, amely elbír ekkora terhelést.

4. A sütőt ne tegye ki magas hőmérsékletnek vagy gőz hatásának.

5. NE HELYEZZEN semmit a sütő tetejére.

6. A sütő elhelyezésekor mindkét oldalon legalább 8 cm, a hátfalnál pedig 10 cm

távolságot a megfelelő szellőzés érdekében.

7. NE SZERELJE ki a forgótányér meghajtó tengelyét.

8. Amikor gyermekek használják a készüléket fokozott körültekintéssel járjon el.

– A KÉSZÜLÉKET FÖLDELNI KELL.

A készüléket könnyen elérhető fali aljzat közelében helyezze el. A sütő

tápfeszültség bemeneti

teljesítménye 1.1 KVA így a használatbavétel előtt mindenképpen lépjen

kapcsolatba a szakszervizzel.

FIGYELEM: A sütő 250V 8 Amp biztosítékkal van ellátva.

– A tápkábelben használt erek színkódja:

Zöld és sárga: földelés

Kék: semleges

Barna: élő

Elképzelhető, hogy a tápkábelben használt vezetékek színe és a villásdugó

jelölései eltérőek, így az alábbi módszerrel azonosítsa a különböző

terminálokat:

A zöld-sárga színű vezetéket csatlakoztatni kell a villásdugó E jelű, vagy

földelés jelöléssel ellátott termináljához.

A kék színű vezetéket az N jelölésű vagy fekete színű terminálhoz kell

csatlakoztatni- A barna színű vezetéket az L jelölésű, vagy piros terminálra

kell csatlakoztatni.

48

9. Lépjen kapcsolatba a legközelebbi márkaszervizzel amikor a sütő lámpája

kiégett.

KIZÁRÓLAG HÁZTARTÁSI FELHASZNÁLÁSRA!

A mikrohullámú sütéssel kapcsolatos kérdésekről, ötletekről és javaslatokról

bővebben olvashat a gyártó weboldalán:

http://microwave.gorenje.com

SOK ÖRÖMÖT KÍVÁN A KÉSZÜLÉK HASZNÁLATÁHOZ

49

MICROWAVE OVEN EN

Before operating this oven, please read these instructions completely.

SPECIFICATIONS

Power consumption: ............................................................230 V ~ 50 Hz, 1080W

Output: ............................................................................................................700W

Operating Frequency:..............................................................................2450 MHz

Outside Dimensions:...............................454 mm (L) x 330 mm (W) x 262 mm (H)

Oven Cavity Dimensions:........................315 mm (L) x 296 mm (W) x 211 mm (H)

Oven Capacity: ............................................................................................20 litres

Cooking Uniformity:....................................................Turntable system (ø245 mm)

Uncrated Weight:............................................................................Approx. 10.5 kg

This appliance is marked according to the European directive 2002/96/EC

on Waste Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a European-wide validity of return and

recycling on Waste Electrical and Electronic Equipment.

BEFORE YOU CALL FOR SERVICE

1. If the oven will not perform at all, the display does not appear or the display

disappeared:

a) Check to ensure that the oven is plugged in securely. If it is not, remove the

plug from the outlet, wait 10 seconds and plug it in again securely.

b) Check the premises for a blown circuit fuse or a tripped main circuit

breaker. If these seem to be operating properly, test the outlet with another

appliance.

2. If the microwave power will not function:

a) Check to see whether the timer is set.

b) Check to make sure that the door is securely closed to engage the safety

interlocks. Otherwise, the microwave energy will not flow into the oven.

IF NONE OF THE ABOVE RECTIFY THE SITUATION, THEN CONTACT THE

NEAREST

AUTHORIZED SERVICE AGENT

.

RADIO INTERFERENCE

Microwave oven may cause interference to your radio, TV, or similar equipment.

When interference occurs, it may be eliminated or reduced by the following

procedures.

50

a) Clean the door and sealing surface of the oven.

b) Place the radio, TV, etc. as far away from your microwave oven as possible.

c) Use a properly installed antenna for your radio, TV, etc. to get a strong signal

reception.

INSTALLATION

1. Make sure all the packing materials are removed from the inside of the door.

2. Inspect the oven after unpacking for any visual damage such as:

- Misaligned Door

- Damaged Door

- Dents or Holes in Door Window and Screen

- Dents in Cavity

- If any of the above are visible, DO NOT use the oven.

3. This Microwave Oven weighs 10.5 kg and must be placed on a horizontal

surface strong enough to support this weight.

4. The oven must be placed away from high temperature and steam.

5. DO NOT place anything on top of the oven.

6. Keep the oven at least 8 cm away from both sidewalls and 10 cm away from

rear wall to ensure the correct ventilation.

7. DO NOT remove the turn -table drive shaft.

8. As with any appliance, close supervision is necessary when used by children.

WARNING

- THIS APPLIANCE MUST BE EARTHED.

The plug socket should be within easy reach of the power cord

This oven requires 1.1 KVA for its input, consultation with service engineer is

suggested when installing the oven.

CAUTION:

This oven is protected internally by a 250V 8 Amp Fuse.

IMPORTANT

- The wires in this mains lead are colored in accordance with the

following code:

Green-and-yellow Earth

Blue Neutral

Brown Live

As the colors of the wires in the mains leads of the appliance may not

correspond with the colored markings identifying the terminals in your plug,

proceed as follows:

The wire which is colored green-and-yellow must be connected to the terminal

in the plug which is marked with the letter

E

or by the earth symbol colored

green of green-and-yellow.

The wire which is colored blue must be connected to the terminal which is

marked with the letter

N

or colored black. The wire which is colored brown must

be connected to the terminal which is marked with the letter

L

or colored red.

51

IMPORTANT INSTRUCTIONS

WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or

excessive microwave energy:

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety. Children should be

supervised to ensure that they do not play with the appliance.

1. Read all instructions before using microwave oven.

2. Some products such as whole eggs and sealed containers - (for example,

closed glass jars and sealed baby bottles with teat) - may explode and should

not be heated in microwave oven, Refer to cookbook for more details.

3. Use this microwave oven only for its intended use as described in this manual.

4. As with any appliance, close supervision is necessary when used by children.

5. Do not operate this microwave oven, if it is not working properly or if it has

been damaged or dropped.

6. To reduce the risk of fire in the oven cavity:

a) Do not overcook food. Carefully attend microwave oven if paper, plastic, or

other combustible materials are placed inside the oven to facilitate cooking.

b) Remove wire twist-ties from bags before placing bag in oven.

c) lf materials inside the oven should ignite, keep oven door closed, turn the

oven off at the wall switch, or shut off power at the fuse or circuit breaker

panel.

SAFETY INSTRUCTIONS FOR GENERAL USE

Listed below are, as with all appliances, certain rules to follow and safeguards to

assure top performance from this oven:

1. Always have the glass tray, roller arms, coupling and roller track in place when

operating the oven.

2. Do not use the oven for any reason other than food preparation, such as for

drying clothes, paper, or any other non-food items, or for sterilizing purposes.

3. Do not operate the oven when empty. This could damage the oven.

4. Do not use the oven cavity for any type of storage, such a papers, cookbooks,

etc.

5. Do not use the oven for home canning, Microwave ovens are not designed to

permit proper canning.

Improperly canned food may spoil and be dangerous to consume.

6. Do not cook eggs in the shell, as they will burst.

Occasionally a poached egg may burst during cooking. Be sure to cook

covered and let stand one minute after cooking before removing the cover.

7. Do not cook any food surrounded by a membrane, such as egg yolks,

potatoes, chichen livers, etc without first being pierced several times with a

fork.

52

8. Do not insert any object into the openings on the outer case.

9. Do not at any time remove parts from the oven such as the feet, coupling,

screws, etc.

10. Do not cook food directly on the glass tray. Place food in/on proper cooking

utensil before placing in the oven.

IMPORTANT

- COOKWARE NOT TO USE IN YOUR MICROWAVE OVEN

- Do not use metal pans or dishes with metal handles.

- Do not use anything with metal trim.

- Do not use paper covered wire twist-ties on plastic bags.

- Do not use melamine dishes as they contain a material which will absorb

microwave energy. This may cause the dishes to crack or char and will slow

down the cooking speed.

- Do not use Centura Tableware. The glaze is not suitable for microwave use.

Corelle Living ware closed handle cups should not be used.

- Do not cook in a container with a restricted opening, such as a pop bottle or

salad oil bottle, as they may explode if heated in a microwave oven.

- Do not use conventional meat or candy thermometers. There are the

thermometers available specifically for microwave cooking. These may be

used.

11. Microwave utensils should be used only in accordance with manufacturer's

instructions.

12. Do not attempt to deep-fry foods in this oven.

13. Please remember that a microwave oven only heats the liquid in a container

rather than the container itself. Therefore, even though the lid of a container is

not hot to the touch when removed from the oven, please remember that the

food/liquid inside will be releasing the same amount of steam and/or spitting

when the lid is removed as in conventional cooking.

14. Always test the temperature of cooked food yourself especially if you are

heating or cooking food/liquid for babies. It is advisable never to consume

food/liquid straight from the oven but allow it to stand for a few minutes and

stir food/liquid to distribute heat evenly.

15. Food containing a mixture of fat and water, e.g. stock, should stand for 30-60

seconds in the oven after it has been turned off. This is to allow the mixture to

settle and to prevent bubbling when a spoon is placed in the food/liquid or a

stock cube is added.

16. When preparing/cooking food/liquid and remember that there are certain

foods, e.g. Christmas puddings, jam and mincemeat, which heat up very

quickly.

When heating or cooking foods with a high fat or sugar content do not use

plastic containers.

17. Cooking utensil may become hot because of heat transferred from the heated

food. This is especially true if plastic wrap has been covering the top and

handles of the utensil. Potholders may be needed to handle the utensil.

53

FEATURE DIAGRAM

1 -

Door Safety Lock System

2 -

Oven Window

3 -

Oven Air Vent

4 -

Roller Ring

5 -

Glass Tray

6 -

Control Panel

54

CONTROL PANEL

55

OPERATION INSTRUCTION ON COMPUTERIZED

CONTROL PANEL

SIMPLE COOKING

You only need press one button for operating cooking 1 min with 100%

microwave power, each pres one time means increase one min cooking time

means increase one min cooking time, the maximum time is 30 min.

After cooking finished you will sound five beeps for remind.

MICROWAVE COOKING

There are 10 power levels, and how to set each level

is shown on the table below.

Micro button Power setting Display shows

Press one time 100% P10

Press two times 70% P7

Press three times 50% P5

Press four times 30% P3

Press five times 10% P1

Press six times -- DEF

1. Fast cooking method

(For example: Select 100% power for cooking foods 5 minutes.)

a) Set the time "5:00"

b) Touch "START/RESET" button

2. Control by hand

(For example: select 70% power for heating foods 10 minutes)

a) Touch "MICRO/DEFROST" button select 70% power.

b) Touch time button to set cooking time "10:00"

c) Touch "START/RESET" button.

The oven will stop working when you press "START/RESET" button during

the operation. You can press "MICRO/DEFROST" button to select power.

AUTO DEFROST FUNCTION

You need to press "1 Min" (1.0 kg) and "10 Sec" (0.1 kg) according to the weight

of the food. The oven can select defrost program and auto start defrosting.

For example: defrost 0.4 kg frozen goods

1. press "MICRO/DEFROST" to choose defrost function.

2. set weight indicate "0.4 kg"

3. press "START/RESET" button.

Remark: the maximum weight is 2 kg.

56

START and RESET

1. Open the door status press "START/RESET" button to cancel setting or

cooking program.

2. close the door status

press "START/RESET" button to start cooking after setting cooking program.

press "START/RESET" button to continue cooking when the cooking is in

pause status.

press "START/RESET" button to stop working when the Microwave oven is

operating.

CHILDREN SAFETY LOCK

To activate the child safety lock, press "1 Min" and "10 Sec" at the same time for

2 seconds. Press press "1 Min" and "10 Sec" at the same time for 2 seconds

again, it will unlock the machine.

57

CARE OF YOUR MICROWAVE OVEN

1. Turn the oven off and remove the power plug from the wall socket before

cleaning.

2. Keep the inside of the oven clean. When food splatters of spilled liquids

adhere to oven walls, wipe with a damp cloth. The use of harsh detergent or

abrasives is not recommended.

3. The outside oven surface should be cleaned with a damp cloth. To prevent

damage to the operating parts inside the oven, water should not be allowed to

seep into the ventilation openings.

4. Do not allow the Control Panel to become wet. Clean with a soft, damp cloth,

Do not use detergents, abrasives or spray-on cleaners on the control Panel.

5. If steam accumulates inside or around the outside of the oven door, wipe with

a soft cloth. This may occur when the microwave oven is operated under high

humidity conditions and in no way indicates malfunction of the unit.

6. It is occasionally necessary to remove the glass tray for cleaning. Wash the

tray in warm sudsy water or in a dishwasher.

7. The roller ring and oven cavity floor should be cleaned regularly to avoid

excessive noise. Simply wipe the bottom surface of the oven with mild

detergent, water or window cleaner and dry. The roller ring may be washed in

mild sudsy water or sish washer. Cooking vapours collect during repeated use

but in no way affect the bottom surface or roller ring wheels.

When removing the roller ring from cavity floor for cleaning, be sure to replace

it in the proper position.

8. Remove odors from your oven by combining a cup of water with the juice and

skin of one lemon in a deep microwaveable bowl. Microwave for 5 minutes,

wipe thoroughly and dry with a soft cloth.

9. When it becomes necessary to replace the oven light, please consult a dealer

to have it replaced.

For personal use only!

Additional recommendations for cooking with microwave and useful advices

c

c

a

a

n

n

b

b

e

e

f

f

o

o

u

u

n

n

d

d

o

o

n

n

w

w

e

e

b

b

s

s

i

i

d

d

e

e

:

:

http://microwave.gorenje.com

WISHES YOU A LOT OF PLEASURE WHILE USING YOUR

APPLIANCE
