Peg-Perego Adjustable Base: EN•ENGLISH

•   IMPORTANT: read the instructions carefully before

use. Save the instructions for future reference.

•   PEG PEREGO reserves the right to make any

necessary changes or improvements to the products

shown at any time without notice.

  Peg Perego S.p.A. is an ISO 9001 certified

company.

  The fact that we are certified provides

a guarantee of our honesty for our

customers, and fosters trust in the

company

ʼ

s way of working.

CUSTOMER SERVICE

If parts of the model are accidentally lost or damaged,

use only original Peg Perego spare parts. Contact

the Peg Perego Customer Service for all repair work,

replacements, information about products, and sale of

original spare parts and accessories, at the following:

tel.: 0039-039-60.88.213

fax: 0039-039-33.09.992

e-mail: assistenza@pegperego.it,

www.pegperego.com

Peg Perego is at the consumer's service, meeting

every need in the best way possible. This is why our

customers' opinions are so important and valuable

to us. We would be very grateful if you would kindly

fill in the CUSTOMER SATISFACTION QUESTIONNAIRE

after using one of our products. You will find the

questionnaire on the Internet at "www.pegperego.

com/SSCo.html.en-UK".

Please note any observations or suggestions you may

have on the questionnaire.

INSTRUCTIONS FOR USE

   PRIMO VIAGGIO with ADJUSTABLE BASE

   The "Primo Viaggio" car seat has been designed

for Group 0+, or children weighing from 0 - 13

kg. (0 - 12/14 months of age).

   The "Primo Viaggio" car seat has a Ganciomatic

system, which allows fastening and removing the

seat from its car base and Peg Perego strollers

and baby carriages, with a simple flick of the

hand.

 1•   To detach the child car seat from its base, pull

the handle behind the backrest upwards with one

hand while lifting the seat with the other hand.

 2•   To attach the child car seat, line it up with the

hooks and push downwards with both hands until

the seat clicks into place.

   SAFETY BELT

 3•   To fasten the safety belt, cross the two straps and

click the tabs into the buckle.

 4•   To loosen the safety belt, press the red button on

the buckle.

 5•   The child car seat is equipped with three notches

for adjusting the level of the safety belt to match

the child's height. The safety belt should be

neither too high nor too low in relation to the

child's shoulders. In the correct position, the

child's shoulders should be just above the notch.

 6•   To change the height of the safety belt, loosen

it and slip the straps out of the notches on the

back. Insert the straps into the appropriate

notches for the child's height.

 7•   To adjust the safety belt to a looser position, slip

a finger into the opening in the seat, and press

the metal button while pulling the straps upwards

with the other hand, as shown in the figure. To

tighten the safety belt so that it fits the child

snuggly, pull the belt towards you, as shown in

the figure. Be careful not to tighten the belt too

much; leave a slight amount of play in the belt.

   PADDING

 8•   A pillow for the child's head, two shoulder pads,

and a protective cushion for the child's legs are

provided with the car seat. Insert the pillow by

slipping the straps through the openings in the

pillow as shown in the figure. Attach the shoulder

pads using the Velcro fasteners.

 9•   Position the protective leg cushion by slipping the

seat strap with the buckle through the cushion, as

shown in the figure.

   REGULATOR HANDLE

 10•   The car seat regulator handle has four positions.

To incline the seat, press the two buttons on the

handle and simultaneously adjust the seat until it

clicks into the desired position.

   Position A: Set the handle to this position when

the child car seat is mounted in the car.

   Position B: Set the handle to this position when

carrying the child car seat by hand or while

attaching it to its base, to a stroller, or to a baby

carriage.

   Position C: Set the handle to this position to allow

the car seat to rock.

   Position D: Set the handle to this position to

prevent the child car seat from rocking.

EN•ENGLISH

   HOOD

 11•   To fit the hood, push the handle rearwards, place

the hood adjusting couplings onto the handle,

then tie up the fastening strings as shown in the

figure. To remove the hood, reverse operations.

 12•   The hood can be adjusted to two positions: To

raise or lower it, push on the inner sides of the

adjusting couplings and bring the hood up or

down till the next click.

   REMOVABLE LINING

 13•   To remove the lining from the car seat, detach the

hood. Unfasten the safety belt and slip it out of

the sack at the back.

 14•   Slip the fastener tabs on the sack out from under

the car seat.

 15•   Slip the leg-divider belt buckle out of the opening

in the sack.

 •

 The hood is made of plastic, and can be washed

without being removed.

INSTRUCTIONS FOR USE IN THE VEHICLE

   IMPORTANT:

 16•   The "Primo Viaggio" car seat can be fastened

to the front seat of a car that does not have an

air bag system installed, or to the back seat

of the car. The seat may be fastened using

only three-point safety belts (see figure).  It

is forbidden to use a two-point or abdominal

safety belt to attach the child car seat, since

these belts do not guarantee the child's safety.

   FASTENING THE BASE TO THE VEHICLE

 17•   Place the base for the child car seat on the seat

of the vehicle. Since not all vehicle seats slope at

the same angle, the height-adjustable base will

allow you to keep the child car seat in the correct

position, parallel to the ground.

 •

 The position of the base is correct when the

bubble on the gauge is completely visible.

 •

 To adjust the base, use one hand to turn knob A,

and the other hand to push down on point B to

simulate the child

ʼ

s weight. Adjust the base so

that the bubble is completely visible in the gauge.

 18•   Slip the vehicle seat belt through the two side

slots on the base, as shown in the figure.

 19•   Fasten the buckle to the vehicle seat, as shown in

the figure.

 20•   If your vehicle is equipped with a seat belt with a

free-sliding buckle (like most modern vehicles),

you must attach a Surefix Clip to it. Using a

Surefix Clip guarantees correct attachment of the

child car seat to the base.

 •

 Remove the Surefix Clip from its housing, as

shown in the figure.

 21•   Grab the vehicle shoulder strap (the free strap)

just above the buckle, and hold it taut while

slipping the Surefix Clip onto the free strap, as

shown in the figure. The Surefix Clip must hold

the strap taut. (Once the Surefix Clip has been

mounted correctly, it can be left on the vehicle

seat belt to make it easier to fasten the base each

time).

 22•   After mounting the Surefix Clip, check the tilt of

the base again. If the bubble is not completely

visible in the gauge, turn the knob again to

tighten the belt.

 •

 The base is ready for fastening the child car seat

to it.

   FASTENING THE CHILD CAR SEAT TO THE BASE IN

THE VEHICLE

 23•   Place your child in the child car seat, and fasten

the safety belt.

 •

 The car seat must be positioned backwards, in

relation to the direction of the vehicle.

 •

 Fasten the car seat to the base, pressing with

both hands until it clicks into place.

 24•   With the child car seat mounted in the vehicle, the

handle on the seat must be lowered all the way

against the back of the vehicle seat, as shown

in the figure.  Push the handle until it clicks into

place.

 25•   Pass the vehicle seat belt around the backrest of

the child seat.

 26•   Slip the vehicle seat belt through the slot on the

back of the seat, as shown in the figure.

 27•   Check to make sure that the seat belt is taut and

securely fastened, for maximum safety.

 •

 To remove the child car seat from the vehicle,

remove the vehicle seat belt from the back of the

child seat.  Pull the handle until it clicks into place

in an upright position, and unfasten the child

seat from its base. Leave the base mounted in the

vehicle, ready for use.

CLEANING & MAINTENANCE

Your product requires only minimal maintenance.

Cleaning and maintenance operations must be

performed only by adults.

•   Be sure to keep all moving parts clean, lubricating

them with light oil if necessary.

•   Regularly clean the plastic parts with a damp cloth.

Do not use solvents or similar products.

•   Brush the fabric parts to remove dust.

•   Do not use solvents or similar products to clean the

polystyrene bumper.

•   Protect the product against smog, water, rain and

snow. Continued and extended exposure to sunlight

can change the colours of many materials.

•   Store the product in a dry area.

SAFETY

    ATTENTION

•   IMPORTANT WARNING: IT IS FORBIDDEN TO MOUNT

THE CHILD CAR SEAT ON A SEAT WITH AN AIR BAG

SYSTEM INSTALLED.

•   THIS GROUP 0+ CHILD SAFETY CAR SEAT MUST

ALWAYS BE INSTALLED FACING BACKWARDS IN

RELATION TO THE DIRECTION THE CAR TRAVELS.

•   ALWAYS USE THE CHILD CAR SEAT SAFETY BELTS,

AND CHECK TO MAKE SURE THAT THE CHILD DOES

NOT UNLATCH THE BELT BY HIMSELF.

•   THIS PRODUCT WAS NOT DESIGNED FOR CHILDREN

TO SLEEP IN.

•   TO AVOID DANGER OF THE CHILD'S FALLING OUT OF

THE CAR SEAT, THE SAFETY BELT MUST ALWAYS BE

USED TO FASTEN THE CHILD IN THE SEAT.

•   WHEN ATTACHING THE BASE AND THE CHILD CAR

SEAT, PASS THE THREE-POINT CAR SEAT BELT

THROUGH THE SPECIAL SLITS.

•   THIS CAR SEAT MAY BE MOUNTED ON THE CAR

USING ONLY THREE-POINT SAFETY BELTS. IT IS

FORBIDDEN TO USE TWO-POINT OR ABDOMINAL

BELTS TO FASTEN THE CHILD CAR SEAT (see the

Safety Regulations).

•   NEVER REMOVE THE CHILD FROM THE SAFETY CAR

SEAT WHILE THE CAR IS MOVING.

•   NEVER LEAVE YOUR CHILD ALONE IN THE CAR.

•   NEVER LEAVE THE SAFETY CAR SEAT IN A CAR

DIRECTLY EXPOSED TO THE SUN.  BEFORE PLACING

YOUR CHILD IN THE CAR SEAT, CHECK TO MAKE

SURE THAT THE SEAT IS NOT HOT.

•   NEVER PLACE THE SAFETY CAR SEAT ON HIGH

SURFACES (tables or shelves), SOFT SURFACES (beds

or sofas), OR ON SLOPING SURFACES.

•   THE USE OF THE SAFETY CAR SEAT BY PREMATURE

NEWBORN INFANTS MAY CAUSE RESPIRATION

PROBLEMS FOR THE CHILD. CONSULT A PHYSICIAN

ABOUT THIS BEFORE LEAVING THE HOSPITAL.

•   MOUNTING AND/OR ASSEMBLY OF THE CHILD CAR

SEAT SHOULD BE DONE ONLY BY ADULTS.

•   DO NOT USE ACCESSORIES THAT HAVE NOT BEEN

APPROVED BY THE MANUFACTURER OR BY A

COMPETENT AUTHORITY.

•   NEVER INSERT FINGERS INTO THE CHILD CAR SEAT

MECHANISMS.

•   DO NOT MODIFY THE CHILD CAR SEAT.  DO NOT

USE THE CHILD CAR SEAT IF IT IS BROKEN OR IF

PIECES ARE MISSING.

•   CONTACT THE AFTER-SALES DEPARTMENT FOR ANY

NECESSARY REPAIR TO THE CHILD CAR SEAT, TO

OBTAIN SPARE PARTS, OR FOR INFORMATION ABOUT

THE PRODUCT. THE LAST PAGE OF THIS MANUAL

LISTS THE NECESSARY INFORMATION REGARDING

REPAIR AND SPARE PARTS SUPPLY.

•   DO NOT USE SECOND-HAND CHILD CAR

SEATS.  SECOND-HAND PRODUCTS MIGHT HAVE

UNDERGONE SERIOUS STRUCTURAL DAMAGE.

•   DO NOT USE THE CHILD CAR SEAT FOR CHILDREN

BORN MORE THAN FIVE YEARS AFTER THE DATE

PRINTED ON THE SEAT. THE SEAT MIGHT NO

LONGER BE IN CONFORMITY WITH CURRENT SAFETY

REGULATIONS.

•   DO NOT REMOVE THE ADHESIVE AND SEWN-ON

LABELS FROM THE CAR SEAT.  SAFETY REGULATIONS

REQUIRE THESE LABELS, AND REMOVING THEM

MAY CAUSE THE CAR SEAT TO NO LONGER BE IN

CONFORMITY WITH SAFETY REGULATIONS.

SAFETY REGULATIONS

•   Group 0+ child safety car seat. "Universal" category,

inspected in conformity with European Regulation

ECE R44/03, for children weighing from 0 - 13 kg

(0 - 12/14 months of age).  Suitable for general use

in vehicles.  Designed for use with most--but not

all--vehicle seats.

•   The child safety car seat can be correctly installed

if the user's manual for the vehicle states that the

vehicle conforms to the "Universal" requirements for

Group 0+ child car seats.

•   The "Primo Viaggio" car seat has been classified

"Universal" according to stricter inspection criteria

than the criteria used for previous models that do

not carry a safety inspection label.

•   The child safety car seat may be used only on

approved vehicles that are equipped with three-

point stationary or wrap-around belts that have

been inspected in conformity with the UN/ECE

Regulation No. 16 or equivalent regulations.

•   When in doubt, consult the "Primo Viaggio" car seat

manufacturer or retailer.

•   Make sure that the three-point safety belt on the

vehicle, which is used to fasten the base and the

child car seat to the vehicle, is always taut and never

twisted.

•   In the case of accidents where the child car seat

and the three-point safety belt on the vehicle
