Fieldmann FDV 2002-E: 7. TECHNICAL SPECIFICATIONS

Adjustment and operation | Technical specifications

To loosen the screw, turn it in a clockwise direction.

The chuck can be equipped with all standard drills and extensions manufactured in

compliance with the business standards up to dia. XX mm.

The power tool is fitted with the quick-release chuck to facilitate exchange of the extensions

during manual drilling without a key.

Automated lock

The chuck can be equipped with all standard drills and extensions manufactured in compliance

with the business standards up to dia. 10 mm.

7. TECHNICAL SPECIFICATIONS

Power supply...................................................................................................................................... 230V~ / 50Hz

Power input........................................................................................................................................................... 810W

Speed.................................................................................................................................................... 0-3000 ot./min

Protection class............................................................................................................................................................. II

Maximum drilling capacity ................................................................................................................... dia. 13 mm

Power supply cable length............................................................................................................................... 1.8 m

Declared noise level: ................................................................................................................................ 98,8 dB(A)

Instructions Manual - language version only.
