3. MACHINE DESCRIPTION AND ITEMS

DELIVERED

Machine Description (See fig. 1)

1 -

ON/OFF switch

2 -

ON/OFF switch lock button

3 -

Rotary speed selector

4 -

Rotation direction selector

5 -

Drill

6 -

Standard/Impact drilling selector

7 -

Auxiliary handle

8 -

Drilling depth indicator

9 -

Quick-release chuck

10 -

Ventilation apertures

11 -

Power cord

Items Delivered

Remove all contents from the box and inspect to ensure no damage was incurred during

shipping, and that the items listed below are included.:

Impact drill

Ergonomic handle

Drilling depth indicator

Warranty card

Instruction Manual

Tool kit - only with the FDV 2002- E model

Should the components be missing or damaged, contact the dealer of the machine.

4. SAFETY INSTRUCTIONS

Before drilling into walls make sure that you are not breaking into an electricity, gas or water

supply line. Use a suitable detector.

Always unplug the drill before changing a drill or bit.

The chuck key should always be stored in the key holder.

To avoid injuries, securely attach the work piece with a vice or clamp.

When drilling or driving a screw: Do not allow the motor to stall under the load.

In the event of an electrical or mechanical malfunction, immediately switch the drill off and

disconnect the plug.
