Eizo FlexScan HD2441W: Adjusting Brightness

English

15

Adjusting Brightness

BrightRegulator

The screen brightness is automatically adjusted corresponding to both the brightness of the image and the environmental

brightness detected by the sensor at the lower side of the monitor.

Manual Setting

Touch .

1

The Setting menu appears.

Select the <Color> icon and tap the slide bar.

2

The <Color> menu appears.

Color menu

Select the <Brightness> icon and tap the slide

3

bar.

The <Brightness> menu appears.

Trace the slide bar left and right to adjust the

4

Brightness menu

brightness.

Tracing the slide bar to the left makes the brightness dark and

right does it bright.

Tap the slide bar at the desired brightness.

5

The specified brightness is saved.

Touch .

6

The Setting menu quits.

Attention

• Do not cover the sensor.

The basic settings and adjustments are completed. For advanced settings/adjustments,

refer to the User’s Manual on the CD-ROM.
