ASRock E35LM1 Motherboard
English
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documentation
by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identi
fi
ca-
tion or explanation and to the owners’ bene
fi
t, without intent to infringe.
Disclaimer:
Speci
fi
cations and information contained in this guide are furnished for informational use
only and subject to change without notice, and should not be constructed as a commit-
ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may
appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or condi-
tions of merchantability or
fi
tness for a particular purpose. In no event shall ASRock, its
directors, of
fi
cers, employees, or agents be liable for any indirect, special, incidental, or
consequential damages (including damages for loss of pro
fi
ts, loss of business, loss of
data, interruption of business and the like), even if ASRock has been advised of the pos-
sibility of such damages arising from any defect or error in the guide or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
Published May 2012
Copyright
©
2012 ASRock INC. All rights reserved.

2
ASRock E35LM1 Motherboard
Motherboard Layout
English
1
CPU Fan Connector (CPU_FAN1)
13
Chassis Speaker Header
2
Chassis Fan Connector (CHA_FAN1)
(SPEAKER 1, White)
3
CPU Fan
14
Chassis Fan Connector (CHA_FAN2)
4
CPU Heatsink
15
32Mb SPI Flash
5
2 x 240-pin DDR3 DIMM Slots
16
PCI Express 2.0 x16 Slot (PCIE1, Blue)
(DDR3_A1, DDR3_A2, Blue)
17
Consumer Infrared Module Header (CIR1)
6
Clear CMOS Jumper (CLRCMOS1)
18
USB 2.0 Header (USB8_9, Blue)
7
ATX Power Connector (ATXPWR1)
19
USB 2.0 Header (USB6_7, Blue)
8
System Panel Header (PANEL1, White)
20
Front Panel Audio Header
9
SATA3 Connector (SATA3_4, White)
(HD_AUDIO1, White)
10
SATA3 Connector (SATA3_2, White)
21
COM Port Header (COM1)
11
SATA3 Connector (SATA3_3, White)
22
AMD A50M Chipset
12
SATA3 Connector (SATA3_1, White)
SPEAKER1
1
PANEL 1
HDLED RESET
PLED PWRBTN
1
CMOS
Battery
32Mb
BIOS
17.0cm (6.7 in)
17.0cm
(6.7
in)
Super
IO
FSB800
DDR3_A1
(64
bit,
2
40-pin
module)
FSB800
DDR3_A2
(64
bit,
2
40-pin
module)
1
USB6_7
PCIE1
1
USB8_9
CHA_FAN2
SA
T
A
3_1
SA
T
A
3_2
SA
T
A
3_3
SA
T
A
3_4
HD_AUDIO1
1
AUDIO
CODEC
LAN
PHY
1
COM1
CHA_FAN1
RoHS
SA
TA
3
6Gb/s
USB 2.0
T: USB0
B: USB1
PS2
Keyboard/Mouse
VGA1
USB 2.0
T: USB4
B: USB5
Top:
RJ-45
T
op:
CTR
B
ASS
Center:
REAR
SPK
Bottom:
Optical
SPDIF
T
op:
LINE
IN
Center:
FRONT
Bottom:
MIC
IN
CLRCMOS1
1
E35LM1
DX1
1
CPU_F
A
N1
1 2
4
3
5
7
6
8
9
10
11
12
13
14
15
16
17
18
19
20
22
DDR3
CIR1
1
21

3
ASRock E35LM1 Motherboard
English
I/O Panel
**
If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.
See the table below for connection details in accordance with the type of speaker you use.
TABLE for Audio Output Connection
Audio Output Channels Front Speaker Rear Speaker
Central / Bass
Line In or
(No. 8)
(No. 5)
(No. 4) Side Speaker
(No.
7)
2
V
-- -- --
4 V
V
--
--
6
V
V V --
8
V
V V V
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED
SPEED LED
Status Description Status Description
Off No Link Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link
Green 1Gbps connection
ACT/LINK
LED
SPEED
LED
LAN Port
1
PS/2 Keyboard/Mouse Port (Purple/Green) 7 Line In (Light Blue)
2
VGA Port ** 8
Front Speaker (Lime)
* 3
LAN RJ-45 Port
9 Microphone (Pink)
4
Central / Bass (Orange)
10 USB 2.0 Ports (USB45)
5
Rear Speaker (Black)
11 USB 2.0 Ports (USB01)
6
Optical SPDIF Out Port
1
2
4
3
5
6
7
8
9
10
11

4
ASRock E35LM1 Motherboard
To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. After restarting your computer, you will
fi
nd “Mixer” tool on your system.
Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and click
“ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA
Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek
HDA Audio 2nd output” to use front panel audio.
English
