ASRock E35LM1: 1. Introduction

5

ASRock  E35LM1  Motherboard

1. Introduction

Thank you for purchasing ASRock

E35LM1

motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock

E35LM1

 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock

E35LM1

 Quick Installation Guide

ASRock

E35LM1

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

English

6

ASRock  E35LM1  Motherboard

English

1.2 Specifications

 Platform

- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm

 CPU

- AMD Zacate E-240 APU

- Supports AMD’s Cool ‘n’ Quiet

TM

 Technology

- UMI 2.5 GT/s

 Chipset

- AMD A50M Chipset

 Memory

- 2 x DDR3 DIMM slots

- Supports DDR3 1333(OC)/1066/800 non-ECC, un-buffered

  memory

- Max. capacity of system memory: 8GB (see

CAUTION 1

)

 Expansion Slot

- 1 x PCI Express 2.0 x16 slot (blue @ x4 mode)

 Graphics

- Integrated AMD Radeon HD 6310 graphics

- DX11 class iGPU, Pixel Shader 5.0

- Max. shared memory 512MB (see

CAUTION 2

)

- Supports D-Sub with max. resolution up to 2560x1600 @

  60Hz

 Audio

- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

- Supports THX TruStudio

TM

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Keyboard/Mouse Port

- 1 x VGA Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

  Speaker/Microphone (see

CAUTION 3

)

 SATA3

- 4 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and

  “Hot Plug” functions

Connector

- 4 x SATA3 6.0Gb/s connectors

- 1 x CIR header

- 1 x COM port header

- CPU/Chassis FAN connector

- 24 pin ATX power connector

7

ASRock  E35LM1  Motherboard

English

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature

- 32Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, FCH, +1V, +1.8V Voltage Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

  Multimedia Suite - OEM

 Unique Feature

- ASRock Instant Boot

- ASRock Instant Flash (see

CAUTION 4

)

- ASRock APP Charger (see

CAUTION 5

)

- ASRock SmartView (see

CAUTION 6

)

- ASRock XFast USB (see

CAUTION 7

)

- ASRock XFast LAN (see

CAUTION 8

)

- ASRock XFast RAM (see

CAUTION 9

)

- ASRock Crashless BIOS (see

CAUTION 10

)

- ASRock OMG (Online Management Guard)

  (see

CAUTION 11

)

- ASRock Internet Flash (see

CAUTION 12

)

- Hybrid Booster:

    - ASRock U-COP (see

CAUTION 13

)

    - Boot Failure Guard (B.F.G.)

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

  CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-bit

  / XP / XP 64-bit compliant (see

CAUTION 14

)

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 15

)

 * For detailed product information, please visit our website: http://www.asrock.com

8

ASRock  E35LM1  Motherboard

English

CAUTION!

1.  Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

®

 7 /

Vista

TM

 / XP. For Windows

®

 OS with 64-bit CPU, there is no such limita-

tion.

2.  The maximum shared memory size is de

fi

 ned by the chipset vendor and

is subject to change. Please check AMD website for the latest informa-

tion.

3.  For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 3

for proper connection.

4.  ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems

fi

 rst like MS-DOS or Windows

®

. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS

fi

 le to your USB

fl

 ash drive,

fl

 oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional

fl

 oppy diskette or other complicated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or hard drive must

use FAT32/16/12

fi

 le system.

5.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful so-

lution for you - ASRock APP Charger. Simply install the APP Charger

driver, it makes your iPhone charge much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

 WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

9

ASRock  E35LM1  Motherboard

English

6.  ASRock SmartView, a new function for internet browsers, is the smart

start page for IE that combines your most visited web sites, your history,

your Facebook friends and your real-time newsfeed into an enhanced

view for a more personal Internet experience. ASRock motherboards are

exclusively equipped with the ASRock SmartView utility that helps you

keep in touch with friends on-the-go. To use ASRock SmartView feature,

please make sure your OS version is Windows

®

 7 / 7 64 bit / Vista

TM

 /

Vista

TM

 64 bit, and your browser version is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

7.  ASRock XFast USB can boost USB storage device performance. The

performance may depend on the properties of the device.

8.  ASRock XFast LAN provides a faster internet access, which includes

the bene

fi

 ts listed below. LAN Application Prioritization: You can con

fi

 g-

ure your application’s priority ideally and/or add new programs. Lower

Latency in Game: After setting online game’s priority higher, it can lower

the latency in games. Traf

fi

 c Shaping: You can watch Youtube HD videos

and download simultaneously. Real-Time Analysis of Your Data: With

the status window, you can easily recognize which data streams you are

transferring currently.

9.  ASRock XFast RAM fully utilizes the memory space that cannot be used

under Windows

®

 OS 32-bit CPU. ASRock XFast RAM shortens the load-

ing time of previously visited websites, making web sur

fi

 ng faster than

ever. And it also boosts the speed of Adobe Photoshop 5 times faster.

Another advantage of ASRock XFast RAM is that it reduces the frequen-

cy of accessing your SSDs or HDDs in order to extend their lifespan.

10.  ASRock Crashless BIOS allows users to update their BIOS without fear

of failing. If power loss occurs during the BIOS update process, ASRock

Crashless BIOS will automatically

fi

 nish the BIOS update procedure after

regaining power. Please note that BIOS

fi

 les need to be placed in the

root directory of your USB disk. Only USB2.0 ports support this feature.

11.  Administrators are able to establish an internet curfew or restrict internet

access at speci

fi

 ed times via OMG. You may choose from [Everyday], [Day

of the week] or [Weekdays and weekends], then schedule the starting

and ending hours of internet access granted to other users. In order to

prevent users from bypassing OMG, guest accounts without permission

to modify the system time are required.

12.  ASRock Internet Flash searches for available UEFI firmware updates

from our servers. In other words, the system can auto-detect the latest

UEFI from our servers and

fl

 ash them without entering Windows

®

 OS.

Please note that you must be running on a DHCP con

fi

 gured computer in

order to enable this function.

10

ASRock  E35LM1  Motherboard

English

13.  While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

14.  ASRock XFast RAM is not supported by Microsoft

®

Windows

®

 XP / XP

64-bit.

15.  EuP stands for Energy Using Product, was a provision regulated by the

European Union to define the power consumption for the completed

system. According to EuP, the total AC power of the completed system

should be under 1.00W in off mode condition. To meet EuP standards,

an EuP ready motherboard and an EuP ready power supply are required.

According to Intel’s suggestion, the EuP ready power supply must meet

the standard of 5v, and the standby power ef

fi

 ciency should be higher

than 50% under 100 mA current consumption. For EuP ready power sup-

ply selection, we recommend you to check with the power supply manu-

facturer for more details.
