1

ASRock  H61iCafe  Motherboard

English

Copyright Notice:

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identi

fi

 ca-

tion or explanation and to the owners’ bene

fi

 t, without intent to infringe.

Disclaimer:

Speci

fi

 cations and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or

fi

 tness for a particular purpose. In no event shall ASRock, its

directors, of

fi

 cers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of pro

fi

 ts, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1)  this device may not cause harmful interference, and

(2)  this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Published February 2011

Copyright

©

2011 ASRock INC. All rights reserved.



2

ASRock  H61iCafe  Motherboard

Motherboard Layout

English

 1

1155-Pin  CPU  Socket

17

SATA2  Connector  (SATA2_3, Blue)

 2

CPU  Fan  Connector  (CPU_FAN1)

18

Chassis  Speaker  Header  (SPEAKER 1, White)

 3

CPU  Fan  Connector  (CPU_FAN2)

19

SATA2  Connector  (SATA2_1, Blue)

 4

ATX  12V  Power  Connector  (ATX12V1)

20

Chassis  Fan  Connector  (CHA_FAN1)



 5

2 x 240-pin  DDR3  DIMM  Slots

21

USB 2.0  Header  (USB8_9, Blue)





(Dual Channel: DDR3_A1, DDR3_B1, Blue)

22

USB 2.0  Header  (USB6_7, Blue)

 6

2 x 240-pin  DDR3  DIMM  Slots

23

Infrared  Module  Header  (IR1)

(Dual Channel: DDR3_A2, DDR3_B2, White)

24

COM  Port  Header  (COM1)

 7

ATX  Power  Connector  (ATXPWR1)

25

PCI  Slots  (PCI1-2)

 8

Chassis  Fan  Connector  (CHA_FAN2)

26

PCI  Express  2.0  x1  Slot  (PCIE3, White)

 9

32Mb  SPI  Flash

27

PCI  Express  2.0  x1  Slot  (PCIE2, White)

10

Clear  CMOS  Jumper  (CLRCMOS1)

28

Front  Panel  Audio  Header

11

Intel  H61  Chipset

(HD_AUDIO1, White)

12

SATA2  Connector  (SATA2_0, Blue)

29

HDMI_SPDIF  Header

13

SATA2  Connector  (SATA2_2, Blue)

(HDMI_SPDIF1, White)

14

SATA3  Connector  (SATA3_1, White)

30

PCI  Express  2.0  x16  Slot  (PCIE1, Blue)

15

SATA3  Connector  (SATA3_2, White)

31

Chassis  Fan  Connector  (CHA_FAN3)

16

System  Panel  Header  (PANEL1, White)

32

Power  Fan  Connector  (PWR_FAN1)

Intel

H61

CMOS

Battery

A

TXPWR1

DDR3_A1

(64

bit,

240-pin

module)

DDR3_A2

(64

bit,

240-pin

module)

DDR3_B1

(64

bit,

240-pin

module)

DDR3_B2

(64

bit,

240-pin

module)

H61iCafe

32Mb

BIOS

PCIE1

PCIE2

PCIE3

PCI1

PCI2

Super

I/O

RoHS

ATX12V1

PCI Express 2.0

21.8cm (8.6 in)

30.5cm

(12.0

in)

ErP/EuP Ready

USB6_7

1

1

1

1

USB8_9

SPEAKER1

1

IR1

1

HD_AUDIO1

1

HDLED RESET

PLED PWRBTN

PANEL1

1

COM1

1

CLRCMOS1

1

SATA2_2

SATA3_1

SATA2_3

SATA3_2

SATA2_0

SATA2_1

Dual

Channel

DDR3

CPU_FAN1

CPU_FAN2

CHA_FAN1

CHA_FAN3

PWR_FAN1

CHA_FAN2

USB 2.0

T: USB0

B: USB1

PS2

Keyboard

VGA1

DVI_CON1

HDMI1

USB 2.0

T: USB4

B: USB5

Top:

RJ-45

T

op:

CTR

BASS

Center:

REAR

SPK

Bottom:

Optical

SPDIF

T

op:

LINE

IN

Center:

FRONT

Bottom:

MIC

IN

USB 3.0

T: USB2

B: USB3

LAN

PHY

AUDIO

CODEC

HDMI_SPDIF_1

1

Designed in Taipei

DX10.1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

24

25

23

22

26

27

28

29

30

31

32

3

ASRock  H61iCafe  Motherboard

English

I/O Panel

1

USB 2.0  Ports  (USB01)                                         ** 8

Front  Speaker  (Lime)

2

VGA/D-Sub  Port

 9

Microphone  (Pink)

      * 3

LAN  RJ-45  Port

10  USB 2.0  Ports  (USB45)

4

Central / Bass  (Orange)

11  USB 3.0  Ports  (USB23)



5

Rear  Speaker  (Black)

12  VGA/HDMI  Port

6

Optical  SPDIF  Out  Port

13  VGA/DVI-D  Port

7

Line  In  (Light  Blue)

14  PS/2  Keyboard  Port  (Purple)

1

2

5

3

6

7

8

9

10

11

13

14

12

4

**

If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.

     See the table below for connection details in accordance with the type of speaker you use.

TABLE for Audio Output  Connection

Audio Output Channels   Front Speaker  Rear Speaker

Central / Bass

 Line In or

(No. 8)

(No. 5)

(No. 4)          Side Speaker

  (No.

7)

2

V

-- -- --

4 V

V

--

--

6

V

V V --

8

V

V V V

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

   indications.



LAN Port LED Indications

       Activity/Link LED

SPEED LED

Status        Description            Status           Description

Off           No Link               Off              10Mbps connection

Blinking   Data Activity        Orange      100Mbps connection

On           Link

         Green        1Gbps connection

ACT/LINK

    LED

SPEED

  LED

LAN Port



To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

  panel audio header. After restarting your computer, you will

fi

 nd “Mixer” tool on your system.

  Please select “Mixer ToolBox”               , click “Enable playback multi-streaming”, and click

  “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA

  Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek

  HDA Audio 2nd output” to use front panel audio.
