ASRock  H61M-PS  Motherboard

English

Copyright Notice:

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identi

fi

 ca-

tion or explanation and to the owners’ bene

fi

 t, without intent to infringe.

Disclaimer:

Speci

fi

 cations and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or

fi

 tness for a particular purpose. In no event shall ASRock, its

directors, of

fi

 cers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of pro

fi

 ts, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1)  this device may not cause harmful interference, and

(2)  this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Published May 2012

Copyright

©

2012 ASRock INC. All rights reserved.

2

ASRock  H61M-PS  Motherboard

Motherboard Layout

English

 1

Power  Fan  Connector  (PWR_FAN1)

13

Chassis  Speaker  Header  (SPEAKER 1, White)

 2

1155-Pin  CPU  Socket

14

System  Panel  Header  (PANEL1, White)

 3

CPU  Fan  Connector  (CPU_FAN1)

15

USB 2.0  Header  (USB4_5, Blue)

 4

ATX  12V  Power  Connector  (ATX12V1

16

USB 2.0  Header  (USB6_7, Blue)

 5

2 x 240-pin  DDR3  DIMM  Slots

17

Chassis  Fan  Connector  (CHA_FAN1)

(Dual Channel: DDR3_A1, DDR3_B1, Blue)

18

Clear  CMOS  Jumper  (CLRCMOS1)

 6

ATX  Power  Connector  (ATXPWR1)

19

Infrared  Module  Header  (IR1)

 7

Intel  H61  Chipset

20

PCI  Slot  (PCI1)

 8

32Mb  SPI  Flash

21

PCI  Express  2.0  x1  Slot  (PCIE2, White)

 9

SATA2  Connector  (SATA2_0, Blue)

22

PCI  Express  2.0  x16  Slot  (PCIE1, Blue)

10

SATA2  Connector  (SATA2_1, Blue)

23

Front  Panel  Audio  Header

11

SATA2  Connector  (SATA2_2, Blue)

(HD_AUDIO1, White)

12

SATA2  Connector  (SATA2_3, Blue)

Intel

H61

A

T

XPWR1

Designed in Taipei

19.8cm (7.8 in)

24.4cm

(9.6

in)

DDR3_A1

(64

bit,

2

40-pin

module)

DDR3_B1

(64

b

it,

2

40-pin

module)

DDR3

PCIE1

Top:

RJ-45

USB 2.0

T: USB2

B: USB3

PS2

Keyboard

USB 2.0

T: USB0

B: USB1

To

p

:

LINE

IN

Center:

FRONT

Bottom:

MIC

IN

Super

I/O

CMOS

Battery

ATX12V1

PWR_F

AN1

CPU_FAN1

H61M-PS

ErP/EuP

R

eady

LAN

PHY

1

HD_AUDIO1

AUDIO

CODEC

Gigabit

LAN

IR1

1

USB4_5

1

CLRCMOS1

1

32Mb

BIOS

1

SATA2_3

HDLED RESET

PLED PWRBTN

PANEL1

1

SPEAKER1

CHA_FAN1

1

2 3

4

5

6

9

10

11

12

8

7

14

13

15

16

22

17

18

19

20

21

23

SATA2_2

PS2

Mouse

SATA2_1

SATA2_0

USB6_7

1

PCIE2

PCI1

P

ARALLEL

P

ORT

COM1

VGA1

X

Fast

LAN

X

Fast

USB

RoHS

3

ASRock  H61M-PS  Motherboard

English

I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

   indications.

LAN Port LED Indications

       Activity/Link LED

SPEED LED

Status        Description            Status           Description

Off           No Link               Off              10Mbps connection

Blinking   Data Activity        Orange      100Mbps connection

On           Link

         Green        1Gbps connection

ACT/LINK

    LED

SPEED

  LED

LAN Port

1

PS/2  Mouse  Port  (Green)

 7

USB 2.0  Ports  (USB23)

2

Parallel  Port

 8

USB 2.0  Ports  (USB01)

      * 3

LAN  RJ-45  Port

 9

D-Sub  Port

4

Line  In  (Light  Blue)

10  COM Port

     ** 5

Front  Speaker  (Lime)

11  PS/2  Keyboard  Port  (Purple)

6

Microphone  (Pink)

1

3

7

8

5

4

6

9

10

11

2

  To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

  panel audio header. After restarting your computer, you will

fi

 nd “VIA HD Audio Deck” tool on

  your system. Please follow below instructions according to the OS you install.

For Windows

®

 XP / XP 64-bit OS:

  Please click “VIA HD Audio Deck” icon               , and click “Speaker”. Then you are allowed to

  select “2 Channel” or “4 Channel”. Click “Power” to save your change.

For Windows

®

 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit OS:

  Please click “VIA HD Audio Deck” icon               , and click “Advanced Options” on the left side

  on the bottom. In “Advanced Options” screen, select “Independent Headphone”, and click

  “OK” to save your change.
