Xoro HTC 1925D: Remote Control

Remote Control

Insert battery into the remote control

Insert the batteries in the remote control:

1. Open the cover.

2. Insert the batteries. Make sure to match - and +.

3. Close the cover

English

Notes on batteries:

Improper use may cause battery leakage and corrosion.

Please follow the instructions below:

• Do not insert the batteries in the wrong direction

• Do not use different types of batteries together

• If you do not use the remote control for a long time, remove the batteries

• If the remote control operates not correctly, replace the batteries

• lf battery leakage occurs, wipe the battery liquid from the battery compartment, then

insert new batteries

• Make sure that the used batteries are disposed properly according to you local regu-

lations.

Operation range

Point the remote control at the IR:

1. Within about 5 m with angle about 30 grade in both direction.

Notes:

• Do not expose the IR of the device to a strong light source or direct sunlight.

• Direct the remote control at the infrared receiver (IR) of the player

• Do not drop the remote control.

• Do not spill water or put anything wet on it.

• Do not disassemble the remote control.

8

Remote Control

Buttons of the remote control:

20.

ATV: Analogue TV Tuner

1.

DVB-T: Digital TV Tuner

21.

DVD: DVD Player

2.

22.

1. POWER button

3.

23.

2. Picture mode (PMODE)

English

3. Sound mode (SMODE)

4. Numeric buttons (0—9)

5. LCD settings (LCD MENU)

4.

24.

6. DVD settings (DVD SETUP)

7. Navigation cross

25.

8. ENTER button

9. Volume (Vol- / Vol+)

10. ATV: Red Teletext button; DVB-T:

5.

26.

Red Teletext button and subtitle;

6.

27.

DVD: subtitle button

11. ATV: Green Teletext button and

NICAM; DVB-T: Green Teletext and

Audio button; DVD: Audio button

7.

12. ATV: Teletext Index button; DVD:

8.

Play / Pause

13. ATV: Teletext sub page button;

DVD: Stop

14. DVD: Open / Close

28.

15. DVD: Zoom

16. DVD: Video DVD Menu

9.

17. DVD: Video DVD Title menu

29.

18. DVB-T: Favorite -; DVD: Angle

10.

19. DVB-T: Favorites; DVD: A-B Seg-

30.

11.

ment Playback

31.

20. MUTE button

12.

21. SOURCE button

13.

32.

22. Aspect Ratio LCD 4:3 / 16:9 (SIZE)

23. Source information (Display)

14.

33.

24. One or two digits of channel num-

15.

bers (-/—)

34.

25. Last TV channel (RECALL)

16.

35.

26. Teletext in ATV and DVB-T

17.

27. DVB-T settings (DVB MENU)

36.

18.

37.

More button description on the next

19.

page.

9

Remote Control

Buttons of the remote control:

20.

ATV: Analogue TV Tuner

1.

21.

DVB-T: Digital TV Tuner

DVD: DVD Player

2.

22.

28. Channel ATV und DVB-T (CH- /

3.

23.

CH+)

29. ATV: Yellow Teletext button; DVB-

T: EPG and yellow Teletext button

4.

24.

30. ATV: Blue Teletext button; DVB-T:

English

Information and blue Teletext but-

ton; DVD: Information

25.

31. ATV: Teletext Mix displaying; DVD:

Previous chapter / track

32. ATV: Teletext exit; DVD: Next chap-

5.

26.

ter / Track

6.

27.

33. DVD: Fast back– or Forward (<< /

>>)

34. DVD: GOTO button

7.

35. DVB-T: Exit of DVB-T settings

36. DVB-T: Switch to TV and Radio

8.

channels

37. DVB-T: Favorites +; DVD: Program

28.

9.

29.

10.

30.

11.

31.

12.

13.

32.

14.

33.

15.

34.

16.

35.

17.

36.

18.

37.

19.

10
